2003 TOYOTA TACOMA Owners Manual (in English)

’03 Tacoma U (L/O 0209)
672003 MY TACOMA (OM35800U)
3. To remove the convertible seat, pressthe bucklerelease button.WHEN INSTALLING ON THE REAR SEAT
(xtracab models):
Raise the bottom cushion before instal-
ling the child restraint system.
If your child restraint system is too large,
you can use the folding table as an auxil-
iary support. For instructions about how to
stand the table, see “Rear cup holder
(xtracab models)” in Section 19.(A) INFANT SEAT INSTALLATION
An infant seat is used in rearfacing
position only.
—Installation with 3point type
seat belt
(vehicles with passenger
airbag manual onoff switch)

’03 Tacoma U (L/O 0209)
682003 MY TACOMA (OM35800U)
CAUTION
Never install a rearfacing child re-
straint system on the right front seat
with the passenger airbag manual on
off switch in the “ON” position. In
the event of an accident, the force of
the rapid inflation of the front pas-
senger airbag can cause death or se-
rious injury to the child.
When you install a rearfacing child re-
straint system which belongs to a pas-
senger risk group on the right front
seat, turn the passenger airbag manual
onoff switch counterclockwise to the
“OFF” position. (For details, see “SRS
driver and front passenger airbags” in
this section.)
The indicator light comes on when the
system is off.
CAUTION
If you must install a rearfacing child
restraint system on the right front
seat, make sure the front passenger
airbag manual onoff switch is in the
“OFF” position and that the indicator
light is on.

’03 Tacoma U (L/O 0209)
692003 MY TACOMA (OM35800U)
CAUTION
Do not install a child restraint sys-
tem on the rear seat if the child
restraint system interferes with the
front seat lock mechanism or with
your proper driving position. This
can cause death or serious injury
to the child and front passenger in
case of sudden braking or a colli-
sion.
If the driver ’s seat position does
not allow sufficient space for safe
installation, install the child re-
straint system on the rear right
seat.
1. Run the lap and shoulder belt throughor around the infant seat following the
instructions provided by its manufactur-
er and insert the tab into the buckle
taking care not to twist the belt. Keep
the lap portion of the belt tight.
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the child restraint system until
the seat belt is fixed.

’03 Tacoma U (L/O 0209)
702003 MY TACOMA (OM35800U)
2. Fully extend the shoulder belt to put itin the lock mode. When the belt is
then retracted even slightly, it cannot
be extended.
To hold the infant seat securely, make
sure the belt is in the lock mode before
letting the belt retract.3. While pressing the infant seat firmly against the seat cushion and seatback,
let the shoulder belt retract as far as
it will go to hold the infant seat secure-
ly.CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.

’03 Tacoma U (L/O 0209)
712003 MY TACOMA (OM35800U)
4. To remove the infant seat, press thebucklerelease button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.(B) CONVERTIBLE SEAT INSTALLATION
A convertible seat is used in forward
facing and rearfacing position depend-
ing on the child’s age and size. When
installing, follow the manufacturer’s
instruction about the applicable child’s
age and size as well as directions for
installing a child restraint system.CAUTION
Rearfacing child restraint system:
Never install a rearfacing child re-
straint system on the right front seat
with the passenger airbag manual on
off switch in the “ON” position. In
the event of an accident, the force of
the rapid inflation of the front pas-
senger airbag can cause death or se-
rious injury to the child.

’03 Tacoma U (L/O 0209)
722003 MY TACOMA (OM35800U)
When you install a rearfacing child re-
straint system which belongs to a pas-
senger risk group on the right front
seat, turn the passenger airbag manual
onoff switch counterclockwise to the
“OFF” position. (For details, see “SRS
driver and front passenger airbags” in
this section.)
The indicator light comes on when the
system is off.
CAUTION
If you must install a rearfacing child
restraint system on the right front
seat, make sure the passenger airbag
manual onoff switch is in the “OFF”
position and that the indicator light is
on.
CAUTION
Forwardfacing child restraint system:
A forwardfacing child restraint sys-
tem which belongs to a passenger
risk group should never be installed
on the right front seat with the pas-
senger airbag manual onoff switch
in the “ON” position, because the
force of the deploying airbag could
cause death or serious injury to the
child in forward seating position. (For
details, see “SRS driver and front
passenger airbags” in this section.)

’03 Tacoma U (L/O 0209)
732003 MY TACOMA (OM35800U)
CAUTION
Do not install a child restraint sys-
tem on the rear seat if the child
restraint system interferes with the
front seat lock mechanism or with
your proper driving position. This
can cause death or serious injury
to the child and front passenger in
case of sudden braking or a colli-
sion.
If the driver ’s seat position does
not allow sufficient space for safe
installation, install the child re-
straint system on the rear right
seat.
1. Run the lap and shoulder belt throughor around the convertible seat following
the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
belt. Keep the lap portion of the belt
tight.
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the child restraint system until
the seat belt is fixed.

’03 Tacoma U (L/O 0209)
742003 MY TACOMA (OM35800U)
2. Fully extend the shoulder belt to put itin the lock mode. When the belt is
then retracted slightly, it cannot be ex-
tended.
To hold the convertible seat securely,
make sure the belt is in the lock mode
before letting the belt retract.3. While pressing the convertible seat firmly against the seat cushion and
seatback, let the shoulder belt retract
as far as it will go to hold the convert-
ible seat securely.CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
