2003 SUBARU FORESTER open hood

2-14
Keys and doors
Security system (if equipped)
The security system helps to protect your vehicle and
valuables from theft. The horn sounds and the turn
signal lights flash if someone attempts to break into
your vehicle. The starter motor is also interrupted to
prevent starting the vehicle without a key.
The system can be armed and disarmed with the re-
mote transmitter.
The system does not operate when the key is inserted
into the ignition switch.
System operation
The security system will give the following alarm indi-
cations when triggered: The turn signal lights will flash and the horn will
sound intermittently. In addition, the starter motor will
not operate. The alarm automatically resets after 30 seconds;
however, the alarm will reactivate if the vehicle is tam-
pered with again. The alarm will continue for six times
if any sensor continues to be activated.
The alarm is triggered by: Opening a door or the rear gate.
Application of physical shock to the vehicle (e.g. breaking glass or forced entry). Note that there are two
alarm levels for shock: warning and alarm. In warning
mode, the alarm detects lower level vibrations and
triggers 2 warning chirps on the horn and two flashes
on the lights as a deterrent to would be vandals. In
alarm mode, higher levels of shock are detected and
the system will go into full alarm.
Ignition switch being turned on while in armed state.
NOTE
With the valet mode selected, the security system
does not operate when the remote transmitter is
used for locking and unlocking. The security sys-
tem indicator light in the combination meter flash-
es twice per second to show that the valet mode is
selected. For details, refer to “Valet mode” in this section. Arming the system
To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood is locked.
5. Close all doors and the rear gate.

2-16
Keys and doors

To arm the system using power door locking
switches
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood is locked.
5. Close the doors and the rear gate but leave only the
driver’s door or the front passenger’s door open.
6. Push the front side (“LOCK” side) of the power door
locking switch to set the door locks.
7. Close the door. An electronic chirp will sound one
time, the turn signal lights will flash one time and the
indicator light will start flashing slowly (approximately
once every two seconds) to inform you that the system has armed.
NOTE
The system can be armed even if the engine hood,
the windows and/or mo
onroofs are opened. Al-
ways make sure that they are fully closed before
arming the system. Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The driv-
er’s door will unlock, an electronic chirp will sound two
times, the turn signal lights will flash two times and the
indicator light will go off.
To unlock all other doors and the rear gate, briefly
press the “UNLOCK/DISARM” button a second time. Emergency disarming
If you cannot disarm the system using the transmitter
(i.e. the transmitter is lost, broken or the transmitter
battery is too weak), you can disarm the system with-
out using the transmitter.
To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
6
7
HS2013CB

9-12
In case of emergency
Engine overheating
Never attempt to remove the radiator cap until
the engine has been shut off and has fully
cooled down. When the engine is hot, the cool-
ant is under pressure. Removing the cap while
the engine is still hot could release a spray of
boiling hot coolant, which could burn you very
seriously.
If the engine overheats, safely pull off the road and
stopthevehicleinasafeplace. If steam is coming from the engine compartment
Turn the engine off and get everyone away from the
vehicle until it cools down. If no steam is coming from the engine compartment
1. Keep the engine running at idling speed.
2. Open the hood to ventilate the engine compart- ment. Confirm that the cooling fan is turning. If the fan is not
turning, immediately turn the engine off and contact
your authorized dealer for repair.
3. After the engine coolant temperature has dropped,
turn off the engine.
If the temperature gauge stays at the overheated
zone, turn the engine off.
4. After the engine has fully cooled down, check the
coolant level in the reserve tank.
If the coolant level is below the “LOW” mark, add cool-
ant up to the “FULL” mark.
5. If there is no coolant in the reserve tank, add cool-
ant to the reserve tank. Then remove the radiator cap
and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator, first
wrap a thick cloth around the radiator cap, then turn
the cap counterclockwise slowly without pressing
down until it stops. Release the pressure from the ra-
diator. After the pressure has been fully released, re-
move the cap by pressing down and turning it.

11 - 5
Maintenance and service
–CONTINUED –
even when the engine is stopped.
When you do checking or servicing in
the engine compartment while the en-
gine is running
A running engine can be dangerous. Keep your
fingers, hands, clothing, hair and tools away
from the cooling fan, belts and any other mov-
ing engine parts. Removing rings, watches and
ties is advisable.
Engine hood
0
To open the hood:
1. Pull the hood release knob under the instrument
panel.
HSB014BA

11 - 7
Maintenance and service
–CONTINUED –
higher position. Do not push the hood forcibly to close
it. It could deform the metal.
Always check that the hood is properly locked
before you start driving. If it is not, it might fly
open while the vehicle is moving and block
your view, which may cause an accident and
serious bodily injury.

14-3
Index
Center console ............................................... 6-5
Charge warning light ...................................... 3-11
CHECK ENGINE warning light/Malfunction
indicator lamp ............................................. 3-10
Child restraint systems ................................... 1-30 Installation with seatbelt ............................ 1-33
Top tether anchorages .............................. 1-38
Child safety locks ........................................... 2-20
Chime Key ............................................................ 3-3
Seat belt .............................................. 1-15, 3-9
Cigarette lighter socket ................................... 6-11
Clock .............................................................. 3-16
Clutch (MT)
Fluid ........................................................... 11-31
Pedal ......................................................... 11-34
Coat hook ....................................................... 6-16
Coil tray .......................................................... 6-7
Convenience net ............................................ 6-7
Coolant ........................................................... 11-15
Cooling system ............................................... 11-14
Corrosion protection ....................................... 10-4
Cruise control ................................................. 7-31
Cruise control indicator light ........................... 3-15
Cup holders ..................................................... 6-8 D
Dashboard storage compartment ................... 6-6
Daytime running light system ......................... 3-19
Differential gear oil
Front (AT vehicles) .................................... 11-26
Rear ........................................................... 11-27
Dimensions ..................................................... 12-2
Disarming the system ..................................... 2-16
Disc brake pad wear warning indicators ......... 7-22
Dome light ...................................................... 6-2
Door locks ...................................................... 2-3
Door open warning light ................................. 3-14
Drive belt ........................................................ 11-21
Driving in foreign country ................................ 8-5
Driving tips............................................... 7-13, 8-6 E
Electronic brake force distribution (EBD) system 7-25
Emergency locking retractor (ELR) ................ 1-14
Engine Compartment overview .............................. 11-8
Exhaust gas (carbon monoxide) ................ 8-3
Hood .......................................................... 11-5
Oil .............................................................. 11-9
Coolant ...................................................... 11-15
Overheating ............................................... 9-12
Starting ...................................................... 7-9
