2003 SUBARU BAJA Service

Maintenance and service11-55
–
CONTINUED –
Low beam light bulbs
HBB042BA
HBB041BB
1. Disconnect the electrical connector for the black cable.
2. Remove the retainer spring.
3. Replace the bulb, then set the retainer spring securely.
4. Reconnect the electrical connector for black cable.
5. Install the headlight bulb cover. High beam light bulbs
HBB044BB
HBB043BA
1. Disconnect the electrical connector from the bulb.
2. Remove the bulb from the headlight assembly by turning it coun-
terclockwise.
3. Replace the bulb with new one.
4. Reconnect the electrical connector. At this time, use care not to
touch the bulb surface.

Maintenance and service11-57
–
CONTINUED –
HBB039CBHBB020BA
3. Remove the bulb socket from the headlight assembly by turning it
counterclockwise.
4. Remove the bulb from the socket by pushing it and turning counter-clockwise. Install a new bulb in the socket.
5. Set the bulb socket into the headlight assembly and turn it clockwise
until it locks.
6. Set the headlight assembly into the vehicle body. Tighten the mount-
ing screws. Rear combination lights
Rear combination lights are composed of the rear turn signal/brake/tail
light and back up lights.
Rear turn signal/Brake/Tail and Back up lights
The rear turn signal/brake/tail light is one bulb with two filament types.
If any one of them malfunctions, replace the bulb with a new one.

Maintenance and service11-59
–
CONTINUED –
9. Install the cover by inserting the knobs into the places. Tail light (on the tailgate)
HBB087BAHBB086BA
1. Open the tailgate.
2. Remove the tailgate trim by loosening the installation screws.
3. Remove the tail light cover by loosening the installation screws.
HBB048BAHBB088BA
4. Remove the bulb socket from the tail light by turning it counterclock- wise.
5. Remove the bulb from the socket by pulling it.
6. Install a new bulb into the socket by pushing it.
7. Install the bulb socket into the tail light by turning it clockwise until itstops.
8. Install the tail light cover and the tailgate trim.

Maintenance and service11-61
–
CONTINUED –
HBB093BA
7. Remove the bulb socket from the license plate bracket by turning it
counterclockwise.
8. Pull the bulb out of the socket.
9. Install a new bulb in the socket by pushing it.10. Install the bulb socket into the license plate bracket.
11. Install the covers by reversing procedures for removal. Map light, dome light and door step light
HBB068BE

Maintenance and service11-63
–
CONTINUED –
High mount stop and cargo light assembly
HBB089BA
1. Remove the high mount stop light mounting screws.
HBB090BB
2. Remove the bulb socket from the light assembly by turning it counter- clockwise.

Maintenance and service11-65
–
CONTINUED –
NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer
replace these bulbs if necessary.

13-2
For U.S.A.
The following information has been compiled according to Code of Fed-eral Regulations “Title 49, Part 575 ”.
Uniform tire quality grading standards
This information indicates the relative performance of passenger car tires
in the area of treadwear, traction, and temperature resistance. This is to
aid the consumer in making an informed choice in the purchase of tires.
Quality grades can be found where applicable on the tire sidewall be-
tween tread shoulder and maximum section width. For example:
Treadwear 200 Traction AA Temperature A
The quality grades apply to new pneumatic tires for use on passenger
cars. However, they do not apply to deep tread, winter type snow tires,
space-saver or temporary use spare tires, tires with nominal rim diame-
ters of 12 inches or less, or to some limited production tires.
All passenger car tires must confirm to Federal Safety Requirements in
addition to these grades. Treadwear
The treadwear grade is a comparative rating based on the wear rate of
the tire when tested under controlled conditions on a specified govern-
ment test course.
For example, a tire graded 150 would wear one and one-half (1-1/2)
times as well on the government course as a tire graded 100. The rela-
tive performance of tires depends upon the actual conditions of their
use, however, and may depart significantly from the norm due to varia-
tions in driving habits, service practices and differences in road charac-teristics and climate. Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B and C. Those
grades represent the tire ’s ability to stop on wet pavement as measured
under controlled conditions on specified government test surfaces of as-
