Combination meter Overview
HBF054BB
1 SRS airbag system warning light (page 3-10)
2 Brake system warning light (page 3-14)
3 Seatbelt warning light (page 3-10)
4 Turn signal indicator light (page3-16)
5 Door ajar warning light (page 3-15)
6 High beam indicator light (page 3-16)
7 CHECK ENGINE warning light/Malfunction indicator lamp (page 3-11)
8 Charge warning light (page 3-12)
9 OIL pressure warning light (page 3-12)
Q AT OIL temperature warning light(page 3-13)
W Front-wheel drive warning light (page 3-15) E
Temperature gauge (page 3-9)
R Clock setting knob (page 3-17)
T Clock (page 3-17)
Y Outside temperature indicator (page 3-8)
U Tachometer (page 3-8)
I Switchback door indicator (page3-15)
O Security system indicator lamp(page 3-16)
P Shift position indicator (page 3-16)
A Cargo lamp indicator (page 3-16)
S Trip meter A/B selection and trip
meter reset knob (page 3-7)
D Trip meter (page 3-7)
F Odometer (page 3-7)
G Speedometer (page 3-7)
H Low fuel warning light (page 3-15)
J Fuel gauge (page 3-9)
K ABS warning light (page 3-13)

Instruments and controls3-17
–
CONTINUED –
Clock
HB2013BA
To set the time, turn the setting knob clockwise to advance and counter-
clockwise to retard the time.
Light control switch
WARNING
To prevent battery discharge resulting from accidentally leaving your lights on when your vehicle is parked, the light switch oper-ates only when the ignition switch is in the “ON” position. In any
other position, the vehicle ’s lights will be out.
If you park your vehicle on a roadside at night, use the hazardwarning flasher to alert the other drivers.

Audio5-5
–
CONTINUED –
Choose desired volume level for each mode by turning the volume
control dial. The control function returns to volume control mode after
about 5 seconds.
To change control modes: Each brief press of the “AUDIO” button
5 changes control modes in the following sequence starting from vol-
ume control mode. (When the radio is first turned on, the control mode
is in the volume control.)
Volume Bass Treble Balance Fader
(VOL) (BAS) (TRE) (BAL) (FAD)
The “AUDIO” button 5 is used for selecting the following control
modes:
Display
Control mode
HB5036BA
Turn counterclockwiseTurn clockwise
BASBass controlFor less bassFor more bass
TRETreble controlFor less trebleFor more treble
FA DFader controlTo increase rear speaker
volume and decrease front
speaker volumeTo increase front speaker
volume and decrease rear
speaker volume
BALBalance controlTo increase left speaker
volume and decrease right
speaker volumeTo increase right speakervolume and decrease left
speaker volume
VOLVolume controlFor less volumeFor more volume
Waveband selection
n FM/AM selection
Push the “BAND” button 2 to select FM1, FM2 or AM reception. The

Maintenance and service11-55
–
CONTINUED –
Low beam light bulbs
HBB042BA
HBB041BB
1. Disconnect the electrical connector for the black cable.
2. Remove the retainer spring.
3. Replace the bulb, then set the retainer spring securely.
4. Reconnect the electrical connector for black cable.
5. Install the headlight bulb cover. High beam light bulbs
HBB044BB
HBB043BA
1. Disconnect the electrical connector from the bulb.
2. Remove the bulb from the headlight assembly by turning it coun-
terclockwise.
3. Replace the bulb with new one.
4. Reconnect the electrical connector. At this time, use care not to
touch the bulb surface.

Maintenance and service11-57
–
CONTINUED –
HBB039CBHBB020BA
3. Remove the bulb socket from the headlight assembly by turning it
counterclockwise.
4. Remove the bulb from the socket by pushing it and turning counter-clockwise. Install a new bulb in the socket.
5. Set the bulb socket into the headlight assembly and turn it clockwise
until it locks.
6. Set the headlight assembly into the vehicle body. Tighten the mount-
ing screws. Rear combination lights
Rear combination lights are composed of the rear turn signal/brake/tail
light and back up lights.
Rear turn signal/Brake/Tail and Back up lights
The rear turn signal/brake/tail light is one bulb with two filament types.
If any one of them malfunctions, replace the bulb with a new one.

11-58
HBB084BAHBB083BA
1. Open the tailgate.
2. Pry the cover from the side of the rear combination light.
3. Remove the rear combination light mounting bolts. Then, slide the
rear combination light assembly to the rear and remove it from thevehicle.
HBB085BB
4. Remove the bulb socket from the rear combination light assembly by
turning it counterclockwise.
5. Remove the bulb from the socket by pulling it.
6. Install a new bulb into the socket by pushing it.
7. Set the bulb socket into the rear combination light assembly and turnit clockwise until it stops.
8. Mount the rear combination light assembly into the vehicle body withtwo mounting bolts.

11-64
HBB048BA
3. Remove the bulb from the socket by pulling it.
4. Install a new bulb in the socket by pushing it.
5. Set the socket into the light assembly and turn it clockwise until itclicks.
6. Mount the light assembly with the mounting screws. Sport activity lights (if equipped)
HBB082AAHBB081BA
1. Remove front lamp screw and remove the lens and reflector.
2. Disconnect the two wires from the lamp electrical connector.
3. Squeeze the bulb retainer spring to remove.
4. Replace the bulb, then reset the retainer spring securely.
5. Reconnect the bulb wire to the electrical connector.
6. Install the lens and reflector in the housing and secure with the screw.
