2003 SUBARU BAJA ESP

2-8
LOCK/DISARM” button (for unlocking of all of the doors is ex-
tremely short, the system may not respond. Illuminated entry
The interior (dome) light will illuminate when the “UNLOCK/DISARM”
button is pressed. These lights stay illuminated for approximately 30 seconds if any of the doors is not opened.If the “LOCK/ARM” button is pressed before 30 seconds have
elapsed, these lights will go out. Also, these lights will go out if the key
is inserted in the ignition switch. The interior light must be set to the
middle position in order for this function to operate.
Vehicle finder function
Use this functon to find your vehicle parked among many vehicles in a
large parking lot. Provided you are within 30 feet (10 meters) of the ve-
hicle, pressing the “LOCK/ARM” button three times in a five-second peri-
od will cause your vehicle ’s horn to sound one time and its turn signal
lights to flash three times.
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button pressed for more
than two seconds .
The horn will sound and the turn signal lights will flash.
To deactivate it, press the “LOCK/ARM” button or “UNLOCK/DISARM”
button. Unless a button on the remote is pressed, the alarm will be
deactivated after approximately 30 seconds. Selecting audible signal operation
Using an electronic chirp, the system will give you an audible signal
when the doors lock and unlock. If desired, you may turn the audible
signal off.
To turn the audible signal off, unlock the doors by pushing “UNLOCK/
DISARM” button and then simultaneously depress “LOCK/ARM” and
“UNLOCK/DISARM” buttons for more than two seconds. An electronic
chirp will sound two times and the turn signal lights will flash two
times to inform you that the audible signal has been turned off.
To turn the audible signal on, unlock the doors by pushing “UNLOCK/

3-10
avoided.
Warning and indicator lights
Several of the warning and indicator lights come on momentarily and
then go out when the ignition switch is initially turned to the “ON” posi-
tion. This permits checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to the “ON” position.
The following lights come on:
Seatbelt warning light
SRS airbag system warning light
CHECK ENGINE warning light / Malfunction indicator lamp
Charge warning light
Oil pressure warning light
AT OIL temperature warning light (AT vehicles)
ABS warning light
Brake system warning light
If any lights fail to come on, it indicates a burned-out bulb or a malfunc-
tion of the corresponding system.
Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime
When the ignition switch is turned to the “ON” position, the seatbelt
warning light will come on and the reminder chime will sound for about
six seconds to remind the driver to fasten the seatbelt.
The seatbelt warning light remains on for about six seconds and turns off
automatically after six seconds.
The seatbelt reminder chime will turn off when the driver ’s side seatbelt is
buckled or it will turn off automatically after six seconds. SRS airbag system warning light AIRBAG
When the ignition switch is turned to the “ON” position, the SRS airbag
system warning light will come on for about six seconds and go out. This
shows the SRS frontal airbag and seatbelt pretensioners are in normaloperation.

Climate control4-7
–
CONTINUED –
Heater operation Defrosting or defogging the windshield
HB5011AA
To direct warm air to the windshield and front door windows:
1. Set the air flow control dial to “
”.
2. Turn the temperature control dial all the way to the right.
3. Set the fan speed control dial to the highest speed. NOTE
Warm air also comes out from the right and left air outlets. To
stop warm air flow from these outlets, turn the correspondingthumb-wheel to the “
” position.
Heating and defrosting
HB5012AA

4-8
To direct warm air toward the floor and the windshield:
1. Set the air flow control dial to “
”.
2. Set the temperature control dial to the desired temperature level.
3. Set the fan speed control dial to the desired speed. NOTE
Warm air also comes out from the right and left air outlets. To
stop warm air flow from these outlets, turn the correspondingthumb-wheel to the “
” position.
Heating
HB5013AA
To direct warm air toward the floor:
1. Set the air inlet selection button to the “OFF” position
2 Set the air flow control dial to “
”.
3. Set the temperature control dial to the desired temperature level.
4. Set the fan speed control dial to the desired speed. NOTE
Warm air also comes out from the right and left air outlets. To
stop warm air flow from these outlets, turn the correspondingthumb-wheel to the “
” position.

5-14
To insert a disc
1. Press one of the “Disc select ” buttons 3 (numbered from 1 to 6)
for which the disc indicator light 2 is “OFF”.
The Disc indicator lights are located directly above the corresponding “ Disc select ” buttons.
2. The indicator will begin blinking. The blinking will last for 15 se-conds.
During this period, insert a desired disc, and the disc will begin to
play. (If any disc is not inserted during this period, the “Disc slot ”
1
door will close. Repeat step 1.)
Be sure to hold a disc with the label side (the side where titles areprinted) up.
3. To insert another disc, repeat step 1 and 2 choosing a differentdisc select button. To insert six discs at a time
1. Press and hold the “Disc select ” button number 1 until all disc indi-
cators begin blinking (about 1.5 seconds).
2. The indicators will blink for 15 seconds. During this period, insert
desired six discs.
3. When all discs are loaded, the first disc will begin to play. (If no
disc is inserted within this 15 seconds, the entire disc load sequencewill be canceled.) To remove a disc
1. Press the desired one of the “Disc select ” buttons
3 (numbered
from 1 to 6) for which the disc indicator light is on.
2. Press the “Eject button ”
4 . The selected disc will be ejected and
the indicator light will begin blinking.
3. To remove another disc, repeat step 1 and 2 choosing a different“ Disc select ” button.
(To remove discs when the ignition switch is in the “Lock” position,
press the “Eject” button, and the first disc will be ejected. Press the
“Eject” button again, and the next disc will be ejected and so on. At
this time, the “Disc select ” buttons are disabled.)

Audio5-15
–
CONTINUED –
To remove all discs at one time
1. Press and hold the “Eject” button 4 until all “Disc” indicators begin
blinking (about 1.5 seconds), and the first disc will be ejected.
2. When the disc is removed, the next one will be ejected, and so on. To replace a playing disc with another
Simply press the desired one of “Disc select ” buttons
3 (numbered
from 1 to 6) or press the “DISC UP ” or “DISC DOWN ” button on the
radio unit to select the desired disc, and the disc will begin to play. Disc indicators
Lit: when the corresponding storage tray is occupied by a disc. Blinking: Disc player is either in loading, eject or changing mode.OFF: No disc is loaded or the ignition switch is in the “LOCK” position.
Function control
Refer to CD player control operating instructions described in the“ AM/FM radio with CD player ” section.

Interior and exterior equipments6-9
–
CONTINUED –
Cigarette lighter socket
CAUTION
The electrical power socket located on the lower part of the
instrument panel is originally designed to use a SUBARU genuine
cigarette lighter plug. Do not use non-genuine cigarette lighterplugs in the socket. Doing so may cause a short-circuit and over-heating, resulting in a fire. If the socket is ever used for a plug-in accessory such as a
mobile phone, they may damage the portion of the socket ’s inter-
nal mechanism that causes a cigarette lighter plug to “pop out ”
after its lighter element is heated. Therefore, do not place a ciga-rette lighter plug in a socket that has been used, even once, to
power a plug-in accessory. Doing so may cause the plug to stickand overheat, creating a potential fire hazard. Do not place any foreign objects, especially metal ones such
as coins or aluminum foil, into the socket. That could cause ashort circuit.
HB6011BA
The electrical power socket located on the lower part of the instrument
panel can be used as cigarette lighter socket. A cigarette lighter plug is
an optional accessory. It is available from your SUBARU dealer.
The cigarette lighter socket may also be used as a power source for anin-car use electrical appliance.

7-4
taining methanol EXCEPT under these conditions.
If undesirable drivability problems are experienced and you sus-
pect they may be fuel related, try a different brand of gasoline before
seeking service at your SUBARU dealer. Fuel system damage or drivability problems which result from the
use of improper fuel are not covered under the SUBARU Limited War-
ranty.
Fuel filler door and cap Refueling
WARNING
Gasoline vapor is highly flammable. Before refueling, always
first stop the engine and make sure that there are no lighted ciga- rettes, open flames or electrical sparks in the adjacent area. When opening the cap, do not remove the cap quickly. Fuel
may be under pressure and spray out of the fuel filler neck espe-
cially in hot weather, which may cause injury. Never fill gasoline containers on the cargo bed. Static electric-
ity may ignite gasoline vapor when filling portable containers.
Approved containers must be removed from the vehicle and
placed on the ground when filling.Do not fill any portable container on a vehicle.
CAUTION
Never add any cleaning agents to the fuel tank. The addition of
a cleaning agent may cause damage to the fuel system. Make sure that the cap is tightened until it clicks to prevent
fuel spillage in the event of an accident. Do not let fuel spill on the exterior surfaces of the vehicle.
Fuels may cause paint damage, which is not covered under the
SUBARU Limited Warranty. Always use a genuine SUBARU fuel filler cap. If you use the
wrong cap, it may not fit or have proper venting, and your fuel
