2003 SAAB 9-3 Owners Manual

97 Interior equipment
Steering wheel
adjustment _________ 98
Electric windows ______ 99
Sunroof _____________ 102
Interior lighting _______ 105
Cup holder ___________ 107
Ashtray______________ 108
Storage compartments _ 109
Rearview mirrors______ 110
Trunk _______________ 116
Interior equipment
ProCarManuals.com

98 Interior equipmentSteering wheel
adjustmentThe height and reach of the steering wheel
can be adjusted.
There is a release lever under the steering
column.
1 Pull down the lever to release the steer-
ing wheel.
2 Adjust the position of the steering wheel.
3 Raise the lever to the locked position to
lock the steering wheel in position.
When returning the release lever to its
locked position, you may need to adjust the
position of the steering wheel slightly to
allow the lock mechanism to engage cor-
rectly.
Steering wheel lock, see page 123.
Horn signalActivate the horn by pressing one of the
three areas shown above on the steering
wheel pad.
WARNING
Only adjust the steering wheel while the
car is stationary so that you are not
distracted from the traffic.
Lever for steering wheel adjustment
ProCarManuals.com

99 Interior equipment
Electric windowsThe electric windows are operated by
means of switches in the door armrests.
For the electric windows to work, the remote
control must be in the ON position in the
ignition switch.
At the end of a journey and having removed
the remote control, you can still operate the
windows, so long as neither of the front
doors has been opened.
Windows having the automatic closing func-
tion (option) can be operated as long as the
car is unlocked and until 20 minutes has passed since the remote control was
removed from the ignition switch.
To openPress down the front edge of the button one
step.
The window will stop when it is fully open or
when the button is released.
Automatic opening: Press the button all
the way down and release it.Comfort opening (option)Comfort opening is the remote opening of
windows and the sunroof.
Press and hold the unlocking button on the
remote control until the windows and sun-
roof start to open (approx. 2 s).
WARNING
Bear in mind the pinch hazard when clos-
ing the side windows. Risk of serious or
fatal injuries!
•Always remove the remote control
from the ignition switch and open one
of the front doors when you leave the
car to prevent personal injury caused
by the activation of the electric
windows, for example, due to children
playing.
 The person operating the electric
window is responsible for ensuring
that no one, especially a child, has
their head, hands or fingers in the
window openings, before raising the
window.
Window switches
Window switch in rear door
ProCarManuals.com

100 Interior equipmentTo closeRaise the front edge of the button one step.
The window will stop when it is fully closed
or when the button is released.
Automatic closing (option): Raise the
button all the way and release it. If the
window does not close automatically, refer
to Calibration on page 101.
Comfort closing (option)Comfort closing is the remote closing of
open windows and the sunroof, and the
retracting of electrically retractable door
mirrors.
Press and hold the locking button on the
remote control until the windows are closed
and door mirrors retracted (takes roughly
2 s). The doors must be shut.
Confirmation that closing has finished is
provided by the direction indicators, which
flash once. No confirmation indicates that
closing was not possible. This may be due
to a door being open or a window requiring
calibration.
Pinch protectionOn certain model variants, the electric win-
dows are equipped with pinch protection.
This is activated if something gets trapped
between the window pane and door frame
when the window is closed. The window will
stop and lower slightly.
WARNING
Take care when closing a window to
ensure that no one gets caught.
WARNING
Make sure no one is so close to the car
that they can be injured if comfort closing
is activated.
ProCarManuals.com

101 Interior equipment
Overriding the pinch protectionIf dirt, ice or similar create so much resis-
tance that the pinch protection cuts in, the
pinch protection can be temporarily disen-
gaged and the window closed.
1 Make sure the ignition is ON.
2 Press and hold the button on the
driver’s door while operating the window
in question.
3 Close the window in question.
The pinch protection will be active the next
time a window is operated.
CalibrationAfter a power break, the electric windows
must be calibrated for the pinch protection
to work. Fully open and close the windows
at least twice. You will hear a chime after
successful calibration.Deactivating the rear window
switchesThe in the driver’s door deactivates the
window switches in the rear doors.
The illuminated switch will change colour
from green to orange (deactivated).
WARNING
Make sure nothing obstructs the window
when it is closed without pinch protection.
WARNING
The pinch protection will not be engaged
after a power break until the electric
windows have been calibrated.
Button for temporary deactivation of rear
door window switches and temporary
override of window pinch protection
ProCarManuals.com

102 Interior equipmentSunroofThe sunroof is operated by the control in the
roof console. For the sunroof to work, the
remote control must be in the ON position in
the ignition switch.
At the end of a journey and having removed
the remote control, you can still operate the
sunroof, so long as neither of the front doors
has been opened.
If the car is equipped with windows having
the automatic closing function, the sunroof
can be opened and closed so long as the car
is unlocked until 20 minutes has passed
since the remote control was removed from
the ignition switch.
To openManually controlled opening
Slide the control rearward to its first position.
The sunroof will halt when you release the
control. If you do not release the control, the
sunroof will open to the comfort position. To
open the sunroof further, release the control
and then once again press it rearward.
Automatic opening
Slide the control rearward to the second
position and release it. The sunroof will
open to the comfort position. To open the
sunroof further, slide the control rearward a
second time.
WARNING
Bear in mind the pinch hazard when clos-
ing the electric sunroof. Risk of serious or
fatal injuries!
Always remove the remote control
from the ignition switch and open one
of the front doors when you leave the
car to prevent personal injury caused
by the activation of the electric
sunroof, for example, due to children
playing.
 The person operating the electric
sunroof is responsible for ensuring
that no one, especially a child, has
their head, hands or fingers in the
opening, before closing the sunroof.
Sunroof control1 Manually controlled opening
2 Automatic opening3 Manually controlled closing
4 Automatic closing
5 Ventilation position
ProCarManuals.com

103 Interior equipment
To closeManually controlled closing
Slide the control forward to its first position.
The sunroof will halt when you release the
control.
Automatic closing
Slide the control forward to its second posi-
tion and release it. The sunroof will close
fully.
The sunroof pinch protection halts closing
and opens the sunroof slightly if something
obstructs closing.Ventilation position (rear edge of
sunroof open)
 To open – press in the control.
 To close – slide the control forward to the
second position.
It is also possible to select the ventilation
position when the sunroof is open by press-
ing in the control. The sunroof will then close
automatically. Press the control once
more to open the sunroof to its ventilation
position.
If you wish to open the sunroof fully from
the ventilation position, you must first close
it (slide the control forward). You can then
slide the control rearward to open the sun-
roof.
The sunroof incorporates an interior, man-
ual, sliding sun blind.
Comfort opening (option)Comfort opening is the remote opening of
windows and the sunroof.
Press and hold the unlocking button on the
remote control until the windows and sun-
roof start to open (approx. 2 s).
If the sunroof is in the ventilation position, it
will not open.
Comfort closing (option)Comfort closing is the remote closing of
open windows and the sunroof, and the
retracting of electrically retractable door
mirrors.
Press and hold the locking button on the
remote control until the windows are closed
and door mirrors retracted (takes roughly
2 s). The doors must be shut.
WARNING
Exercise great care when closing the
sunroof to ensure that nothing gets
trapped.
WARNING
Make sure no one is so close to the car
that they can be injured if comfort closing
is activated.
ProCarManuals.com

104 Interior equipmentPinch protectionThe sunroof is equipped with pinch protec-
tion. This is activated if something gets
trapped when the sunroof is being closed.
The sunroof will stop and open slightly.
Overriding the pinch protection
If dirt, ice or similar create so much resis-
tance that the pinch protection cuts in (sun-
roof cannot be closed), the pinch protection
can be temporarily disengaged.
1 Make sure the ignition is ON.
2 Press and hold the button on the
driver’s door while operating the window
in question.
3 Close the sunroof with the button on the
roof console.
The pinch protection will be operative the
next time the sunroof is operated.
Emergency operation of the sunroofIn an emergency, such as if there is an elec-
trical failure, the sunroof can be operated
with a screwdriver.
Remove the lens from the roof console. Use
a screwdriver to press in the pin in the slot
in the center of the motor shaft and turn the
screwdriver.
Turn clockwise to close the sunroof.
If the rear edge of the sunroof is open (ven-
tilation position), turn the screwdriver
counter-clockwise.
WARNING
Make sure nothing obstructs the sunroof
when it is closed without pinch protection.
Button for overriding the sunroof pinch
protection
