2003 Peugeot 307 SW fault

14-04-2003
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle. Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition.Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompa-nied by the message
''Remote
control battery low'' on the multi-
function display.
To replace the battery, remove the screw then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control. Programming the remote control  Switch off the ignition.
 Switch the ignition on again.
 Immediately press button A.
 Switch off the ignition and remo- ve the remote control key from
the ignition lock. The remotecontrol is now working again.
YOUR 307 SW IN DETAIL
104
Electronic engine immobiliser This locks the engine control system as soon as the ignition has been
switched off and therefore preventsstarting of the vehicle by anyone
who does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode must be recognised for startingto be possible. If the system does not function correctly
, the central locking button
indicator light, situated in the centreof the fascia, flashes rapidly whenthe ignition is switched on (2ndnotch), accompanied by an audiblesignal and the message "Anti-theft
device faulty" on the multi-function
display. In this case your vehicle will not start.
Contact a PEUGEOT dealer as soon as possible.

14-04-2003
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle. Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition.Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompa-nied by the message
''Remote
control battery low'' on the multi-
function display.
To replace the battery, remove the screw then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control. Programming the remote control  Switch off the ignition.
 Switch the ignition on again.
 Immediately press button A.
 Switch off the ignition and remo- ve the remote control key from
the ignition lock. The remotecontrol is now working again.
YOUR 307 SW IN DETAIL
104
Electronic engine immobiliser This locks the engine control system as soon as the ignition has been
switched off and therefore preventsstarting of the vehicle by anyone
who does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode must be recognised for startingto be possible. If the system does not function correctly
, the central locking button
indicator light, situated in the centreof the fascia, flashes rapidly whenthe ignition is switched on (2ndnotch), accompanied by an audiblesignal and the message "Anti-theft
device faulty" on the multi-function
display. In this case your vehicle will not start.
Contact a PEUGEOT dealer as soon as possible.

14-04-2003
THE ALARM This provides two types of protec- tion: Ðexterior protection: it sounds if
a door, the boot or the bonnet is opened.
Ð interior protection: it sounds if
the volume inside the passengercompartment changes (breakingof a window or a movement insi-de the vehicle).
Setting the alarm  Switch off the ignition and get out of the vehicle.
 Set the alarm within five minutesof getting out of the vehicle, bylocking or deadlocking using theremote control (button Aindica-
tor light flashes once persecond).
Note: if you wish to lock your vehicle
without setting the alarm, use thedoor lock. When the alarm is triggered, thesiren sounds and the direction indi-cator lights flash for thirty seconds. After triggering, the alarm remains set.
Warning:
if the alarm has been
triggered ten times in succession, on the eleventh time it becomesinactive. Note: if button Aindicator light
flashes rapidly, the alarm has been triggered while you were away fromyour vehicle.
Disarming Unlock the vehicle with the remote control key (button Aindicator light
goes out). Note: if the alarm has been triggered
while you were away from your vehicle, the rapid flashing of the indi-cator light will stop when you switchon the ignition.
To set the alarm with exterior protection only If, while you are away from the vehicle, you wish to leave a windowpartially open or a pet inside thevehicle, you should choose exterior
protection only.  Switch off the ignition,
 In the next ten seconds, press button Auntil the indicator light is
on continuously,
 Get out of the vehicle,
Set the alarm by locking or dead-locking using the remote control(button Aindicator light flashes
once a second).
Note: when the alarm is set but the
remote control does not operate:  Unlock the doors with the key
and open the door. The alarm istriggered.
 Switch on the ignition in the next
ten seconds. The alarm is disar-med.
Incorrect operation When the ignition is switched on, if button Alights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have the system checked. Automatic activation* The alarm is activated automatically two minutes after the last closure ofa door or the boot. In order to avoid accidental triggering of the alarm when a door or the bootis opened, it is essential to first pressthe unlocking button on the remotecontrol.
* According to destination.
YOUR 307 SW IN DETAIL
106

14-04-2003
TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver's door lock.
To open, pull handle Aand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened.
"Tailgate open" warning When the engine is running, an audible signal and a diagram dis-played briefly on the multi-functiondisplay warn you that the tailgate isnot properly closed. In addition, if the vehicle is being dri- ven, the courtesy lights flash. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. PANORAMIC ROOF
Your vehicle is fitted with a tinted glass panoramic roof whichincreases the light and visibility in thepassenger compartment. Its electricconcealing shutter improves tempe-rature conditions.
To open:
press part Aof the switch.
To close: press part Bof the switch.
Manually: press the switch without
going past the point of resistance; the shutter stops as soon as the switch is released. Automatically: press the switch
beyond the point of resistance; one press fully opens or closes the shut-
ter. Press the switch again to stop
the shutter.
YOUR 307 SW IN DETAIL
108

14-04-2003
TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver's door lock.
To open, pull handle Aand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened.
"Tailgate open" warning When the engine is running, an audible signal and a diagram dis-played briefly on the multi-functiondisplay warn you that the tailgate isnot properly closed. In addition, if the vehicle is being dri- ven, the courtesy lights flash. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. PANORAMIC ROOF
Your vehicle is fitted with a tinted glass panoramic roof whichincreases the light and visibility in thepassenger compartment. Its electricconcealing shutter improves tempe-rature conditions.
To open:
press part Aof the switch.
To close: press part Bof the switch.
Manually: press the switch without
going past the point of resistance; the shutter stops as soon as the switch is released. Automatically: press the switch
beyond the point of resistance; one press fully opens or closes the shut-
ter. Press the switch again to stop
the shutter.
YOUR 307 SW IN DETAIL
108

14-04-2003
AUTOMATIC SWITCHING ON OF LIGHTS The side lights and dipped beam headlamps switch on automatically if
the light is poor, or during operation
of the windscreen wipers. They swit-
ch off when the light becomes brightenough or the windscreen wipersstop. Note:In foggy weather or in snow,
the brightness sensor can detect suf-
ficient light. As a consequence, the
lights will not come on automatically. This function is active when the vehicle is delivered.
To disarm or activate the function:  Turn the key to the accessories position (1st notch),
 Press the end of the lights stalkfor more than four seconds.
The brightness sensor, connected
to the rain sensor, is located in thecentre of the windscreen, behind
the interior mirror. It is used forautomatic switching on of thelights. Operating check ActivationActivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting
active" on the multi-function display.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is disarmed tem-
porarily when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by anaudible signal, accompanied by themessage "Automatic switching on
of lights faulty" on the multi-func-
tion display.
Contact a PEUGEOT dealer to have the system checked.
* During the year.
YOUR 307 SW IN DETAIL 111
Direction indicators (flashers) Left: downwards.
Right: upwards.
In good or rainy weather, both day and night, thefront fog lamps and therear fog lamp are dazz-
ling and are prohibited. Do not forget to switch them off when they are no longer needed.

14-04-2003
AUTOMATIC SWITCHING ON OF LIGHTS The side lights and dipped beam headlamps switch on automatically if
the light is poor, or during operation
of the windscreen wipers. They swit-
ch off when the light becomes brightenough or the windscreen wipersstop. Note:In foggy weather or in snow,
the brightness sensor can detect suf-
ficient light. As a consequence, the
lights will not come on automatically. This function is active when the vehicle is delivered.
To disarm or activate the function:  Turn the key to the accessories position (1st notch),
 Press the end of the lights stalkfor more than four seconds.
The brightness sensor, connected
to the rain sensor, is located in thecentre of the windscreen, behind
the interior mirror. It is used forautomatic switching on of thelights. Operating check ActivationActivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting
active" on the multi-function display.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is disarmed tem-
porarily when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by anaudible signal, accompanied by themessage "Automatic switching on
of lights faulty" on the multi-func-
tion display.
Contact a PEUGEOT dealer to have the system checked.
* During the year.
YOUR 307 SW IN DETAIL 111
Direction indicators (flashers) Left: downwards.
Right: upwards.
In good or rainy weather, both day and night, thefront fog lamps and therear fog lamp are dazz-
ling and are prohibited. Do not forget to switch them off when they are no longer needed.

14-04-2003
YOUR 307 SW IN DETAIL113
Do not cover the rain sen- sor located on the wind-screen behind the interior
mirror.
When using an automatic carwash, switch off the ignition orcheck that the wiper stalk is not in
the automatic position. In winter, itis advisable to wait for the wind-screen to completely clear of icebefore operating the automaticwipe. Rear windscreen wiper
Turn ring Ato the first notch
for intermittent wiping.
Rear windscreen wash Turn ring Apast the first
notch; the windscreen wash then the windscreen wiperoperate for a fixed period. Automatic windscreen wipers In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the inten-
sity of the rainfall .
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wiping active" appears on the mul-
tifunction display. Disarming Disarming of the function is accom- panied by an audible signal. In the event of malfunction , the dri-
ver is informed by an audible signal and the message "Auto wind-
screen wiper faulty" on the multi-
function display. In the AUTOposition, the wind-
screen wiper will operate in intermit- tent mode.
Contact a PEUGEOT dealer to have the system checked.
