2003 Peugeot 307 SW boot

14-04-2003
TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver's door lock.
To open, pull handle Aand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened.
"Tailgate open" warning When the engine is running, an audible signal and a diagram dis-played briefly on the multi-functiondisplay warn you that the tailgate isnot properly closed. In addition, if the vehicle is being dri- ven, the courtesy lights flash. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. PANORAMIC ROOF
Your vehicle is fitted with a tinted glass panoramic roof whichincreases the light and visibility in thepassenger compartment. Its electricconcealing shutter improves tempe-rature conditions.
To open:
press part Aof the switch.
To close: press part Bof the switch.
Manually: press the switch without
going past the point of resistance; the shutter stops as soon as the switch is released. Automatically: press the switch
beyond the point of resistance; one press fully opens or closes the shut-
ter. Press the switch again to stop
the shutter.
YOUR 307 SW IN DETAIL
108

14-04-2003
YOUR 307 SW IN DETAIL125
BOOT LAYOUT
1. Grab handles and coat hooks
2. High load retaining net fastenings The high load retaining net can be fitted in the 2nd or
3rd row. Open the covers of the corresponding upper faste- nings. Fit the ends of the metal bar in these fastenings.Secure the two opaque material strap hooks in the sto-
wing rings on the floor. The rings are located directly below the corresponding upper fastenings. Pull the two straps taut.Secure the two hooks on the elastic parts of the opaque material in these rings. Note: the net must be positioned so that the label can
be seen from the boot. This ensures that the central
seat belt is routed correctly.
3. 12V Socket for accessories This is a 12 volt socket (lighter type), installed on theload space cover left support.
It is supplied with the ignition off.
4. Rear armrests with grab handle
5. Storage nets One of them contains the luggage retaining net.
6. Load space cover To install it:
Ð position one end of the cover roller in the 2nd row, Ð compress the opposite end of the roller and position
it,
Ð release it to allow it to engage,
Ð unroll the cover as far as the boot pillars,
Ð insert the cover guides in the rails in the pillars. To remove it:
Ð remove the cover guides from the pillar rails,
Ð return the cover into its roller,
Ð compress it and remove it from its support at the 2nd row,
To store it, pull it back and place it with the two storage nets, already lowered. Note: the roller has two hooks for securing the lugga-
ge retaining net depending on where it is installed.
7. Luggage retaining net Secure the net's seven hooks in the stowing rings and
the fastenings on the floor.
8. Luggage retaining net fastenings ("hammock" version) in the tailgate Fold the net in two. Secure the two centre hooks in the stowing rings on the
floor. Secure the net's remaining four hooks on the boot pillars.
See configuration of the nets (next page)

14-04-2003
CHANGING A WHEEL
Tools The following tools are located:
Ð in the right-hand trim of the boot,1 - Wheelbrace.
2 - Removable towing eye.
3 - Socket for anti-theft bolts.
Ð in the holder in the centre of the spare wheel, 4 - Jack with handle.
5 - Bolt cover tools.
6 - Centralising tool.
7 - Removable chock. Parking the vehicle
As far as possible, park the vehicle on level, stable and non-slippery ground.
 Apply the handbrake, switch offthe ignition and engage first orreverse gear (position Pfor the
automatic gearbox). Access to the spare wheel
Open the boot.
 Open the flap using the lug to release the winch and gainaccess to its control nut.
 Unscrew the nut fully, using thewheelbrace 1, to unroll the winch
cable.
PRACTICAL INFORMATION 141

14-04-2003
PRACTICAL INFORMATION143
For your safety, always change the wheel:
- on level, stable, non-slippery ground,
- with the handbrake on and the ignition switched off,
- with first or reverse gear enga- ged (position Pfor the automatic
gearbox),
- with the vehicle chocked. Never go underneath a vehicle that is supported only by a jack(use a ramp) Never refit the holder under the vehicle without the sparewheel. After changing the wheel:
- have the correct positioning of the punctured wheel, the tighte- ning of the bolts and the tyrepressure checked by a PEUGEOT dealer as soon aspossible.
- have the punctured tyre repai- red and refit it to the vehicle assoon as possible.
- have the correct positioning of the spare wheel checked by a
PEUGEOT dealer. Close the flap using the lug to lock the winch.
 Store the rest of the tools in theright-hand trim of the boot.
Fitting a wheel
Position the wheel using the cen- tralising tool 5to assist you.
 Tighten the bolts by hand andremove the centralising tool 5.
 Partly tighten the bolts using thewheelbrace 1.
 Fold the jack 4and remove it.
 Fully tighten the bolts using thewheelbrace 1.
 Replace the wheel trim, startingby placing the wheel trim notchopposite the valve, and press iton using the palm of the hand.
 Put the corresponding tools in
the holder and secure its cover.
 Place the holder on the groundand align the spare wheel on it.
 Pass the notched hook into the
holder cover.
 Refit the wheel under the vehicletightening the winch control nutusing the wheelbrace 1.
 Fully tighten and check that the
wheel is horizontally flush
against the rear floor.

14-04-2003
PRACTICAL INFORMATION147
Third brake light: 4 W 5 W bulbs.  Remove the tailgate upper trim carefully by unclipping it on eitherside, perpendicular to its direc-tion of engagement.
 Insert a screwdriver into the twoouter holes Bto press on the two
tabs C.
 Push the light unit outwards whilemaintaining the pressure on thetabs.
 Pull the light unit outwards whiletilting it.
 Change the faulty bulb.
 When refitting, ensure that thelight unit tabs are engaged cor-rectly and that the tailgate uppertrim has been put back in place
correctly.
Press the tab Aand remove the
bulb holder.
 Change the faulty bulb.
Note: if necessary use the wheelbra-
ce to remove the bolts. When refitting, take care to position
the bulb holder and the bulb correctly. Number plate lights (W 5 W)  Insert a small screwdriver in one of the external holes of the lens.
 Push the lens outwards to unclipit.
 Remove the lens.
 Change the faulty bulb.
Rear lights
1 - Brake lights (P 21 W).
2 - Side lights (R 5 W).
3 - Direction indicators (P 21 W).
4 - Reversing lights (P 21 W), left
side.
Fog lamp (P 21 W), right side.
These 5 bulbs are changed by remo- ving the light:  Remove the respective boot side trim to access the light.
 Remove the mounting nut for thelight inside the boot.
 Remove the mounting nut for thelight outside the boot.
 Remove the light.
 Unclip the harness.

14-04-2003
TOWING YOUR VEHICLE
Without lifting (4 wheels on the road)
You should always use a tow bar. The removable towing eye is inside the boot right-hand trim. From the front: Unclip the cover, by pressing the bottom part,
 Screw in the removable towing eye as far as it will go.
From the rear: Unclip the top of the cover using a coin,
 Screw in the removable towing eye as far as it will go.
Lifting (2 wheels only on the road ) It is preferable to raise the vehicle with a professional lifting device. Special features of the automatic gearbox When towing with four wheels on the ground, the following rules must beobeyed:
- lever in position
N,
- tow the vehicle at less than 50 km/h over a maximum distance of 50 km,
- do not add oil to the gearbox.
PRACTICAL INFORMATION
154
When towing with the engine switched off, thereis no braking or steeringassistance.

14-04-2003
PRACTICAL INFORMATION159
ACCESSORIES FOR YOUR 307 SW
For your PEUGEOT only use accessories and original parts approved by the manufacturer.
These accessories and parts are all adapted to your PEUGEOT, after being tested and approved for reliability and
safety, which PEUGEOT cannot guarantee for other products.
A wide choice of original accessories, approved by PEUGEOT, is available through the dealer network. They all carry
the PEUGEOT guarantee.
- Safety :
Anti-theft alarm, window engraving, wheel locks, first aid kit, warning triangle, rear parking assistance.
- Comfort : Telephone console, front centre arm rest, covers compatible with side air bags, mats, boot
tray, cool box, door deflectors, CD storage, side sun blinds and rear blind, additionalseats...
- Communication : Audio system, telephone, hands-free kit, speakers, amplifiers, CD changer, navigation
systems, entertainment screen kit, DVD player...
- Customising : Alloy wheels, trims, sport exhaust, aluminium or PVC door sills, mud flaps...
- Leisure : Tow bar, transverse roof bars, roof box, snow chains, ski carrier, roof bars bicycle carrier,tailgate bicycle carrier*...
- Children : Booster seats and child seats...
- Maintenance products : Screenwash, interior and exterior cleaning and maintenance products...
- Commercial use : Kit for transformation into a van...
* During the year.
Before installing any electrical accessory on your vehicle, contact a PEUGEOT dealer.
