14-04-2003
ISOFIX MOUNTINGS The two rear side seats of your vehicle are fitted with ISOFIX moun-
tings . These are two rings located
between the seat back and the seatcushion. The ISOFIX child seats are fitted
with two locks which are secured
easily on these rings. All this guaran-tees reliable, safe and fast fitting. The ISOFIX child seat approved forPeugeot vehicles and sold byPeugeot dealers is the
ISOFIX
KIDDY* child seat. It can be fitted in
the "rear facing" position (when theside seats are recentred) from birthto 13 kg and in the "forwards facing"position from 9 to 18 kg. In the front, in the "rear facing" posi- tion, the front passenger seat mustbe moved as far forward as possibleso that the body of the child seat is incontact with or as close as possibleto the fascia.
In the rear, in the "forwards facing" position, it is imperative that the frontpassenger seat is in the mid-way
position on the runner, seat backupright.
YOUR 307 SW IN DETAIL
94
The ISOFIX KIDDY seat can also be installed on a 2nd row side seatwhich has been positioned in the 3rd
row. In ths case, the ISOFIX KIDDYseat must be in the "rear facing"position, the body supported on theseat back of the corresponding 2ndrow seat. This seat can also be used on seats not fitted with ISOFIX mountings. Inthis case it is compulsory to attach itto the vehicle's seat by means of thethree-point seat belt for the "rearfacing" and "forwards facing" posi-tions. Refer to the "Summary table for fit- ting child seats".
When the ISOFIX KIDDY seat is fitted in the "rear facing" positionon the front passenger seat, it isimperative that that passenger airbag be disarmed. Otherwise there is a risk the child could be seriously injured or evenkilled due to deployment of the airbag. Follow the instructions for fitting the child seat in the seat manu-facturer's instruction booklet.
* You can only fit ISOFIX child seats
approved by PEUGEOT and sold
by PEUGEOT dealers on yourvehicle's ISOFIX mountings.
14-04-2003
CHILD SEATS RECOMMENDED BY PEUGEOT
In addition to the ISOFIX child seats, PEUGEOT offers a complete range of child seats which are secured using the seat belt: Group 0+: from birth to 13 kg
L1 - "Britax Babysure": installed in the rear-facing position in the front or in the rear using a three-point seat belt.In the front, it is compulsory to disarm the passenger air bag and the passenger seat must be adjusted to the "mid-way" position on the runner.
Group 1: from 9 to 18 kg
L2 - "Ršmer Prince": installed in the rear using a two or three-point seat belt. For the safety of your child, the seat and the restraining cushion must never be separated.
Group 2: from 15 to 25 kg
L3 - "Ršmer Vario'': installed in the rear with a two or three-point seat belt.
YOUR 307 SW IN DETAIL 95
14-04-2003
YOUR 307 SW IN DETAIL97
SUMMARY TABLE FOR FITTING CHILD SEATS In accordance with the European regulation (Directive 2000/3), the table below indicates the options for the installation of child restraints, depending on the weight group and the seat in the vehicle:
U : universal "rear facing" or "forwards facing" child seat.
U (R) : universal child seat with a height adjustable passenger seat; it must be adjusted to between mid and maximum height (in conformity with ¤ 3.3. of appendix 2 of annex XVIII of Directive 2000/3).
According to destination:
L1 : BRITAX Babysure E11 0344117 Universal (birth to 13 kg).
L2 : R…MER Prince E1 03301058 Universal (9 to18 kg).
L3 : R…MER Vario E1 03301120 Universal (15 to 25 kg).
L4 : RECARO Start E1 03301108 Universal (15 to 36 kg).
L5 : KLIPPAN Optima E17 030007 Universal (15 to 36 kg).
L6 : KIDDY Isofix Rearwards facing (c)
E1 03301123 and Universal (birth to 13 kg).
L7 : KIDDY Isofix Forwards facing (c)
E2 030011 Universal (9 to 18 kg).
(a) Group 0: from birth to 10 kg.
(b) Consult the current legislation in your country.
(c) See section "Seats - Isofix mountings" for use of the KIDDY child seat on the vehicle's Isofix mountings, or failing this with the seat belt. Statutory weight group
Seat Group 0(a)
at 0+ Group 1 Group 2 Group 3
< 13 kg 9 - 18 kg 15 - 25 kg 22 - 36 kg
Front passenger (b)
UU UU
Fixed seat L1, L6 L2, L7 L3, L4, L5 L4, L5
Front passenger (b)
U (R) U (R) U (R) U (R)
Height adjustable seat (R) L1, L6 L2, L7 L3, L4, L5 L4, L5
Side UU UU
Seat off centre and recentred L1, L6 L2, L7 L3, L4, L5 L4, L5
Centrale UU UU
Centre seat L1, L6 L2, L7 L3, L4, L5 L4, L5
Side
Additional seat L1 L2 L3, L4, L5 L4, L5
Side UU UU
2nd row side seat L3, L4, L5 L4, L5
Side UU UU
2nd row centre seat L3, L4, L5 L4, L5
1st row
2nd row
3rd row
