TROUBLE DIAGNOSES FOR SYMPTOMS
AT-259
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
19.A/TDoesNotShift:22®11, When Selector Lever “2”®“1” PositionECS004TC
SYMPTOM:
A/T does not shift from 2
2to 11when changing selector lever from “2” to “1” position.
1.CHECK PNP SWITCH CIRCUIT
With CONSULT-II
Does “TCM INPUT SIGNALS” in “DATA MONITOR” show damage to PNP switch circuit?
Without CONSULT-II
Does self-diagnosis show damage to PNP switch circuit?
Ye s o r N o
Yes >> Check PNP switch circuit. Refer to “21. TCM Self-diag-
nosis Does Not Activate (PNP & Overdrive Control
switches, and Throttle Position Sensor Circuit Checks)”,
AT-260, "
21. TCM Self-diagnosis Does Not Activate
(PNP & Overdrive Control Switches, and Throttle Posi-
tion Sensor Circuit Checks)".
No >> GOTO2
2.CHECK SYMPTOM
Check again.
OK or NG
OK >>INSPECTION END
NG >> 1. Perform TCM input/output signal inspection.
2. If NG, recheck TCM pin terminals for damage or loose
connection with harness connector.
20. Vehicle Does Not Decelerate By Engine BrakeECS004TD
SYMPTOM:
Vehicle does not decelerate by engine brake when shifting from 2
2(12)to11.
1.CHECK SYMPTOM
Is 6. Vehicle Does Not Creep Backward In “R” Position OK?
Ye s o r N o
Yes >> Go to 15. Engine Speed Does Not Return To Idle (Light Braking D4®D3),AT - 2 5 5 , "15. Engine
Speed Does Not Return To Idle (Light Braking D4®D3)".
No >> Go to 6. Vehicle Does Not Creep Backward In “R” Position,AT-237, "
6. Vehicle Does Not Creep
Backward In“R”Position".
SCIA0706E
SAT778B
TROUBLE DIAGNOSIS — INTRODUCTION
AT-283
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
4. 4-
3.Cruise testAT- 2 9 6 , "3.
CRUISE
TEST"
AT- 3 0 0 ,
"Cruise Test
—Part 1"
Part-1
o8. Vehicle Cannot Be Started From D
1,AT- 3 6 4 , "8. Vehicle Cannot Be Started From D1".
o9. A/T Does Not Shift: D
1®D2Or Does Not Kickdown: D4®D2,AT- 3 6 6 , "9. A/T Does Not Shift: D1
®D2Or Does Not Kickdown: D4®D2".
o10. A/T Does Not Shift: D
2®D3,AT-368, "10. A/T Does Not Shift: D2®D3".
o11. A/T Does Not Shift: D
3®D4,AT-371, "11.A/TDoesNotShift:D3®D4".
o12. A/T Does Not Perform Lock-up,AT- 3 7 4 , "
12. A/T Does Not Perform Lock-up".
o13. A/T Does Not Hold Lock-up Condition,AT- 3 7 5 , "
13. A/T Does Not Hold Lock-up Condition".
o14. Lock-up Is Not Released,AT- 3 7 6 , "
14. Lock-up Is Not Released".
o15. Engine Speed Does Not Return To Idle (Light Braking D
4®D3),AT-377, "15. Engine Speed Does
Not Return To Idle (Light Braking D4®D3)".
Part-2AT- 3 0 3 ,
"Cruise Test
—Part 2"o16. Vehicle Does Not Start From D1,AT- 3 7 9 , "16. Vehicle Does Not Start From D1".
o9. A/T Does Not Shift: D
1®D2Or Does Not Kickdown: D4®D2,AT- 3 6 6 , "9. A/T Does Not Shift: D1
®D2Or Does Not Kickdown: D4®D2".
o10. A/T Does Not Shift: D
2®D3,AT-368, "10. A/T Does Not Shift: D2®D3".
o11. A/T Does Not Shift: D
3®D4,AT-371, "11.A/TDoesNotShift:D3®D4".
Part-3AT- 3 0 5 ,
"Cruise Test
—Part 3"o17.A/TDoesNotShift:D4®D3When Overdrive Control Switch “ON”®“OFF”,AT-380, "17. A/T Does
Not Shift: D4®D3, When Overdrive Control Switch“ON”®“OFF”".
o15. Engine Speed Does Not Return To Idle (Engine Brake In D
3),AT-377, "15. Engine Speed Does Not
Return To Idle (Light Braking D4®D3)".
o18. A/T Does Not Shift: D
3®22, When Selector Lever “D”®“2” Position,AT-380, "18. A/T Does Not
Shift: D3®22, When Selector Lever“D”®“2”Position".
o15. Engine Speed Does Not Return To Idle (Engine Brake In 2
2),AT- 3 7 7 , "15. Engine Speed Does Not
Return To Idle (Light Braking D4®D3)".
o19. A/T Does Not Shift: 2
2®11, When Selector Lever “2”®“1” Position,AT-381, "19. A/T Does Not
Shift: 22®11, When Selector Lever“2”®“1”Position".
o20. Vehicle Does Not Decelerate By Engine Brake,AT- 3 8 1 , "
20. Vehicle Does Not Decelerate By Engine
Brake".
o21. TCM Self-diagnosis Does Not Activate (PNP & Overdrive Control Switches , and throttle position sen-
sor Circuit Checks),AT-382, "
21. TCM Self-diagnosis Does Not Activate (PNP & Overdrive Control
Switches, and Throttle Position Sensor Circuit Checks)".
oSELF-DIAGNOSTIC PROCEDURE — Mark detected items.
oVehicle speed sensor·A/T (Revolution sensor),AT- 3 9 2 , "
VEHICLE SPEED SENSOR·A/T (REVO-
LUTION SENSOR)".
oVehicle speed sensor·MTR,AT-397, "
DTC VEHICLE SPEED SENSOR MTR".
oAccelerator pedal position(APP) sensor,AT- 4 0 1 , "
ACCELE RATOR PEDAL POSITION (APP)
SENSOR".
oShift solenoid valve A,AT-406, "
SHIFT SOLENOID VALVE A".
oShift solenoid valve B,AT-4 11 , "
SHIFT SOLENOID VALVE B".
oOverrun clutch solenoid valve,AT- 4 1 6 , "
OVERRUNCLUTCHSOLENOIDVALVE".
oTorque converter clutch solenoid valve,AT-421, "
TORQUE CONVERTER CLUTCH SOLENOID
VA LV E".
oBatt/fluid temp sen (A/T fluid temperature sensor and TCM power source),AT-426, "
BATT/FLUID
TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POWER SOURCE)".
oEngine speed signal,AT- 4 3 2 , "
ENGINE SPEED SIGNAL".
oLine pressure solenoid valve,AT-436, "
LINE PRESSURE SOLENOID VALVE".
oCAN communication line,AT-443, "
CAN CAMMUNICATION LINE".
oControl unit (RAM), control unit (ROM),AT- 2 2 6 , "
DTC CONTROL UNIT (RAM), CONTROL UNIT
(ROM)".
oControl unit (EEP ROM),AT- 2 2 8 , "
DTC CONTROL UNIT(EEPROM)".
oPNP & overdrive control switches, and throttle position sensor,AT- 3 8 2 , "
21. TCM Self-diagnosis
Does Not Activate (PNP & Overdrive Control Switches, and Throttle Position Sensor Circuit Checks)"
.
oBattery
oOthers
AT-286
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — BASIC INSPECTION
TROUBLE DIAGNOSIS — BASIC INSPECTION
PFP:00000
A/T Fluid CheckECS004VR
FLUID LEAKAGE CHECK
1. Clean area suspected of leaking. — for example, mating surface
of converter housing and transmission case.
2. Start engine, apply foot brake, place selector lever in “D” posi-
tion and wait a few minutes.
3. Stop engine.
4. Check for fresh leakage.
FLUID CONDITION CHECK
FLUID LEVEL CHECK
Refer to “Checking A/T Fluid”,AT-13, "A/T FLUID".
SAT767B
SAT288G
Fluid color Suspected problem
Dark or black with burned odor Wear of frictional material
Milky pink Water contamination — Road water
entering through filler tube or breather
Varnished fluid, light to dark brown and
tackyOxidation — Over or under filling, —
Overheating
SAT638A
AT-302
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — BASIC INSPECTION
5.CHECK LOCK-UP (D4TO D4L/U)
Does A/T perform lock-up at the specified speed?
Read vehicle speed, throttle position when lock-up duty becomes 94%.
Ye s o r N o
Yes >>GOTO6
No >> Go To "12. A/T Does Not Perform Lock-up”,AT-374, "
12.
A/T Does Not Perform Lock-up".ContinueROAD
TEST.
6.CHECK HOLD LOCK-UP
Does A/T hold lock-up condition for more than 30 seconds?
Ye s o r N o
Yes >>GOTO7
No >> Go To "13. A/T Does Not Hold Lock-up Condition”,AT-375, "
13. A/T Does Not Hold Lock-up Con-
dition".
7.CHECK SHIFT DOWN (D4L/U TO D4)
1. Release accelerator pedal.
2. Is lock-up released when accelerator pedal is released?
Ye s o r N o
Yes >>GOTO8
No >> Go To "14. Lock-up Is Not Released”,AT-376, "
14. Lock-
up Is Not Released". Continue ROAD TEST.
8.CHECK SHIFT DOWN (D4TO D3)
1. Decelerate vehicle by applying foot brake lightly.
2. Does engine speed return to idle smoothly when A/T is shifted from D
4to D3?
Read gear position and engine speed.
Ye s o r N o
Ye s > > 1 . St o p v e h i c l e .
2. Go To “Cruise test — Part 2”,AT-303, "
Cruise Test—
Part 2".
No >> Go To "15. Engine Speed Does Not Return To Idle (Light
Braking D
4®D3)”,AT-377, "15. Engine Speed Does
Not Return To Idle (Light Braking D4®D3)". Continue
ROAD TEST. Specified speed when lock-up occurs:
Refer to Shift schedule, $$$$$.
SAT957I
SAT958I
SAT959I
AT-306
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — BASIC INSPECTION
2.CHECK ENGINE BRAKE
Does vehicle decelerate by engine brake?
Ye s o r N o
Yes >>GOTO3
No >> Go To "15. Engine Speed Does Not Return To Idle (Light
Braking D
4®D3)”,AT-377, "15. Engine Speed Does
Not Return To Idle (Light Braking D4®D3)". Continue
ROAD TEST.
3.CHECK SHIFT DOWN (D3TO D2)
1. Move selector lever from “D” to “2” position while driving in D
3(O/D OFF).
2. Does A/T shift from D
3(O/D OFF) to 22?
Read gear position.
Ye s o r N o
Yes >>GOTO4
No >> Go To "18. A/T Does Not Shift: D
3®D2, When Selec-
tor Lever “D”®“2” Position”,AT - 3 8 0 , "
18. A/T Does Not
Shift: D3®22, When Selector Lever“D”®“2”Position"
. Continue ROAD TEST.
4.CHECK ENGINE BRAKE
Does vehicle decelerate by engine brake?
Ye s o r N o
Yes >>GOTO5
No >> Go To "15. Engine Speed Does Not Return To Idle (Light
Braking D
4®D3)”,AT-377, "15. Engine Speed Does
Not Return To Idle (Light Braking D4®D3)". Continue
ROAD TEST.
SAT776BA
SAT791GA
SAT791GA
TROUBLE DIAGNOSES FOR SYMPTOMS
AT-377
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
Lock-up is not released when accelerator pedal is released.
1.CHECK THROTTLE POSITION SENSOR* CIRCUIT
*: This sensor means accelerator pedal position (app) senror.
With CONSULT-II
Does “TCM INPUT SIGNALS” in “DATA MONITOR” show damage throttle position sensor circuit?
Without CONSULT-II
Does self-diagnosis show damage to throttle position sensor circuit?
Ye s o r N o
Yes >> Check throttle position sensor circuit. Refer to “21. TCM
Self-diagnosis Does Not Activate (PNP & Overdrive
Control switches, and Throttle Position Sensor )”,AT-
382, "21. TCM Self-diagnosis Does Not Activate (PNP &
Overdrive Control Switches, and Throttle Position Sen-
sor Circuit Checks)".
No >> GOTO2
2.CHECK SYMPTOM
Check again.
OK or NG
OK >>INSPECTION END
NG >> 1. Perform TCM input/output signal inspection.
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
15. Engine Speed Does Not Return To Idle (Light Braking D4®D3)ECS004VG
SYMPTOM:
lEngine speed does not smoothly return to idle when A/T shifts from D4to D3.
lVehicle does not decelerate by engine brake when turning overdrive control switch OFF.
lVehicle does not decelerate by engine brake when shifting A/T from “D” to “2” position.
1.CHECK SELF-DIAGNOSTIC RESULTS
Does self-diagnosis show damage to overrun clutch solenoid valve
circuit after cruise test?
Ye s o r N O
Yes >> Check overrun clutch solenoid valve circuit. Refer toAT-
416, "OVERRUN CLUTCH SOLENOID VALVE"
(Except for Euro-OBD)/AT - 2 0 8 , "DTC P1760 OVERRUN
CLUTCH SOLENOID VALVE"(Euro-OBD).
No >> GOTO2
SAT367J
SCIA0774E
TROUBLE DIAGNOSES FOR SYMPTOMS
AT-381
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
19.A/TDoesNotShift:22®11, When Selector Lever “2”®“1” PositionECS004VK
SYMPTOM:
A/T does not shift from 2
2to 11when changing selector lever from “2” to “1” position.
1.CHECK PNP SWITCH CIRCUIT
With CONSULT-II
Does “TCM INPUT SIGNALS” in “DATA MONITOR” show damage to PNP switch circuit?
Without CONSULT-II
Does self-diagnosis show damage to PNP switch circuit?
Ye s o r N o
Yes >> Check PNP switch circuit. Refer to “21. TCM Self-diag-
nosis Does Not Activate (PNP & Overdrive Control
switches, and Throttle Position Sensor Circuit Checks)”,
AT-382, "
21. TCM Self-diagnosis Does Not Activate
(PNP & Overdrive Control Switches, and Throttle Posi-
tion Sensor Circuit Checks)".
No >> GOTO2
2.CHECK SYMPTOM
Check again.
OK or NG
OK >>INSPECTION END
NG >> 1. Perform TCM input/output signal inspection.
2. If NG, recheck TCM pin terminals for damage or loose
connection with harness connector.
20. Vehicle Does Not Decelerate By Engine BrakeECS004VL
SYMPTOM:
Vehicle does not decelerate by engine brake when shifting from 2
2(12)to11.
1.CHECK SYMPTOM
Is 6. Vehicle Does Not Creep Backward In “R” Position OK?
Ye s o r N o
Yes >> Go to 15. Engine Speed Does Not Return To Idle (Light Braking D4®D3),AT - 3 7 7 , "15. Engine
Speed Does Not Return To Idle (Light Braking D4®D3)".
No >> Go to 6. Vehicle Does Not Creep Backward In “R” Position,AT-359, "
6. Vehicle Does Not Creep
Backward In“R”Position".
SCIA0706E
SAT778B
AT-460
[ALL]
REMOVAL AND INSTALLATION
3. Install torque converter to drive plate.
lWith converter installed, rotate crankshaft several turns
to check that transaxle rotates freely without binding.
4. Tighten belts fixing transaxle.
5. Reinstall any part removed.
6. Adjust control cable. Refer toAT-456, "
Control Cable Adjust-
ment".
7. Check continuity of PNP switch. Refer toAT-130, "
DTC P0705
PARK/NEUTRAL POSITION (PNP) SWITCH".
8. Refill transaxle with ATF and check fluid level.
9. Move selector lever through all positions to be sure that tran-
saxle operates correctly. With parking brake applied, idle
engine. Move selector lever through “N” to “D”, to “2”, to “1” and
“R” positions. A slight shock should be felt through the hand
gripping the selector each time the transaxle is shifted.
10. Perform road test. Refer toAT-69, "
Road Test".
AAT266A
Bolt No.Tightening torque
N-m (kg-m, ft-lb)Bolt length “ L ”
mm (in)
1
69.6 - 79.4 (7.1 - 8.1, 51.4 - 58.6)49 (1.93)
245(1.77)
3
39.2 - 46.1 (4.0 - 4.7, 29.0 - 34.0)40 (1.57)
430(1.18)
5
30.4 - 40.2 (3.1 - 4.1, 22.4 - 29.7)40 (1.57)
645(1.97)
SCIA0795E
SAT638A
