82 Safety and SecurityAnti-theft systemsAnti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens

a door


the trunk


the hood.
The alarm system will also be triggered
when


someone attempts to raise the vehicle


the vehicle is opened with the mechan-
ical keyArming the alarm system
The alarm system is armed within approx.
10 seconds after locking the vehicle. The
indicator lamp in the button for the
tow-away alarm will then blink.
Disarming the alarm system
The alarm system is disarmed when you
unlock your vehicle with the remote con-
trol or KEYLESS-GO*.
Canceling the alarm
With the key

Insert the key in the starter switch.
or

Press the Œ or ‹ button on the
key.With KEYLESS-GO*

Grasp the outside door handle.
or

Press the KEYLESS-GO* start/stop
button.
Tow-away alarm
Once the tow-away alarm is armed, a visual
and audible alarm will be triggered when
someone attempts to raise the vehicle.
iIf the alarm stays on for more than
20 seconds, an emergency call is initi-
ated automatically by the Tele Aid sys-
tem* (
page 234), provided that the
Tele Aid service was subscribed to and
properly activated.
iThe tow-away protection alarm is trig-
gered, for example, if the vehicle is lift-
ed on one side.
If the alarm stays on for more than
20 seconds, an emergency call is initi-
ated automatically by the Tele Aid sys-
tem* (
page 234), provided that the
Tele Aid service was subscribed to and
properly activated, and that necessary
cellular service and GPS coverage are
available.
ProCarManuals.com

83 Safety and Security
Anti-theft systems
Arming the tow-away alarm
When you lock your vehicle, the tow-away
alarm is automatically armed after about
30 seconds.
When you unlock your vehicle, the
tow-away protection disarms automatical-
ly.
Disarming the tow-away alarm
To prevent triggering the tow-away alarm
feature, switch off the tow-away alarm be-
fore towing the vehicle, or when parking on
a surface subject to movement, such as a
ferry or auto train.The button is located on the overhead con-
trol panel.
1Tow-away alarm off button

Turn off the ignition and remove the
key.

Press button1.
The indicator lamp in the button lights
up briefly.

Lock your vehicle with the key or (vehi-
cles with KEYLESS-GO*) the lock but-
ton at each door handle.
The tow-away alarm remains disarmed un-
til you lock your vehicle again.
Canceling the alarm

Insert the key in the starter switch.
or

Press the Œ or ‹ button on the
key.
iYou cannot disarm the tow-away alarm
if the ignition is turned on.
ProCarManuals.com

87 Controls in detail
Locking and unlocking
Factory setting
Global unlocking
Press buttonŒ.
All turn signal lamps blink once. The
locking knobs in the doors move up.
The vehicle will lock again automatically
within approximately 40 seconds of un-
locking if neither door nor trunk is opened,
the SmartKey is not inserted in the starter
switch, or the central locking switch is not
activated.
Global locking

Press button‹.
All turn signal lamps blink three times.
The locking knobs in the doors move
down.Selective setting
If you frequently travel alone, you may wish
to reprogram the key so that
pressingŒ only unlocks the driver’s
door and the fuel filler flap.

Press and hold buttonsŒ and‹
simultaneously for about five seconds
until battery check lamp5 blinks twice.
The key will then function as follows:
Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.
Global unlocking

Press buttonΠtwice.
Global locking

Press button‹.Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about six seconds
until battery check lamp5 blinks twice.Warning!
G
When leaving the vehicle always remove the
key from the starter switch, take the Smart-
Key with KEYLESS-GO (if so equipped) with
you and lock the vehicle. Do not leave chil-
dren unattended in the vehicle, or with ac-
cess to an unlocked vehicle. It is possible for
children to open a looked door from the in-
side, which could result in an accident or se-
rious injury.
ProCarManuals.com

89 Controls in detail
Locking and unlocking
Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:
Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.

Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you grasp a door
handle.
If the SmartKey with KEYLESS-GO* is valid,
your vehicle unlocks

the doors


the trunk lid


the fuel filler flap
iIf the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 96). The
turn signals will flash three times to
confirm locking.
If the vehicle was previously separately
locked (
page 98), the trunk lid will re-
main locked.
ProCarManuals.com

90 Controls in detailLocking and unlocking
Important notes on using KEYLESS-GO

You can also use the SmartKey with
KEYLESS-GO like a normal key
(page 86).


You can combine KEYLESS-GO func-
tions with normal key functions (e.g.
unlocking with KEYLESS-GO and lock-
ing with the remote control).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the key
must be located outside the vehicle
within approximately 3 ft. (1 m) of a
door or the trunk.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


All the doors must be closed.


If you have started the engine with the
KEYLESS-GO start/stop button, you
can only turn it off again with this but-
ton, even if you have put the key in the
starter switch in the meantime.


This does not apply if, after starting, the
selector lever is still in positionP. The
SmartKey will then have priority over
the KEYLESS-GO function and the vehi-
cle’s electrical system will operate ac-
cording to the position of the key in the
starter switch, even stopping the en-
gine.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle (e.g. inside clothing or briefcase)
and can no longer be recognized by the
Warning!
G
When leaving the vehicle always remove the
key from the starter switch, take the Smart-
Key with KEYLESS-GO (if so equipped) with
you and lock the vehicle. Do not leave chil-
dren unattended in the vehicle, or with ac-
cess to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause serious
personal injury.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.
ProCarManuals.com

91 Controls in detail
Locking and unlocking
system, the vehicle cannot be locked
or the engine started via the KEY-
LESS-GO system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the igni-
tion is switched on (e.g. if passenger
exits the vehicle with the key), the mes-
sage
Key not recognized!
will appear
in the multifunction display.
Find the key or change its present loca-
tion immediately (e.g. place it on the
front passenger seat or insert it in shirt
pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the card behind
when exiting and locking the vehicle,
the message
Key recognized in vehi-
cle!
will appear in the multifunction
display.Factory setting
Global unlocking

Grasp the door handle.
The vehicle will lock again automatically
within approximately 40 seconds if neither
door nor trunk is opened.Global locking

Press lock button at door handle
(page 53) or trunk lid (
page 92).
iThe vehicle could be inadvertently un-
locked if the SmartKey with KEY-
LESS-GO is within 3 ft. (1 m) of the
vehicle and

the door handle is splashed with
water, or


you attempt to clean the door
handle.
!If you cannot lock or unlock the vehicle
with the SmartKey with KEYLESS-GO,
then either the batteries of the key are
discharged or the key is malfunction-
ing.

Check the batteries of the Smart-
Key with KEYLESS-GO (
page 88)
and replace them if necessary
(
page 328).


Use the mechanical key to unlock
the driver’s door (
page 327) and
trunk lid (
page 328) as required.
Lock the vehicle using the mechan-
ical key (
page 328).
If your SmartKey with KEYLESS-GO is
malfunctioning, contact your autho-
rized Mercedes-Benz Center.
ProCarManuals.com

93 Controls in detail
Locking and unlocking
Loss of the SmartKey with KEYLESS-GO
If you lose your SmartKey with KEY-
LESS-GO, you should do the following:
Have the SmartKey with KEYLESS-GO
deactivated by an authorized Mer-
cedes-Benz Center.

Report the loss immediately to your car
insurance company.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
Opening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handle
Pull on door handle2.
If door was locked, locking knob1 will
move up.
Warning!
G
When closing the windows and the slid-
ing/pop-up roof, be sure that there is no
danger of anyone being harmed by the clos-
ing procedure.
If potential danger exists, proceed as fol-
lows:

Release the lock button.


Pull on the door handle or trunk lid han-
dle and hold firmly. The side windows
and the sliding/pop-up roof will open.
ProCarManuals.com

97 Controls in detail
Locking and unlocking
Closing from outside
1Trunk closing switch
Press the closing switch briefly.
The trunk lid closes automatically.
When closing, if the trunk lid comes into
contact with an object (e.g. luggage that
has been piled too high) in the upper mo-
tion sequence, the closing procedure is
stopped and the trunk re-opens slightly.
Trunk lid emergency release
The emergency release button is located
on the inside of the trunk lid.
1Emergency release button
Briefly press the emergency release
button.
The trunk unlocks and the trunk lid
opens.
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
press the remote control switch for the
trunk lid or the
Š
key on the remote con-
trol.
!Do not place the key in the open trunk.
You may lock yourself out.
Vehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO is
recognized in the area of the rear shelf
or inside the trunk.
!The emergency release button unlocks
and opens the trunk while the vehicle is
standing or driving.
ProCarManuals.com
