2003 Lexus IS300 Basic Functions / LEXUS 2003 IS300 OWNER'S MANUAL (OM53439U)

KEYS AND DOORS
20
DOORS
Locking with key
SS11007a

1Lock 2Unlock
Turn the key towards the front of the vehicle to lock and
towards the back to unlock.
Locking (or unlocking) the driver's door will lock (or unlock) all
the other doors simultaneously. In the driver's door lock,
turning the key once will unlock the driver's door and twice in
succession will unlock all doors simultaneously.*
Together with the activation of unlocking, the interior light will
turn on for 15 seconds if the interior light switch is in the
ºDOORº position.** However, this function does not work
when the ignition key is in the ºONº position. For further
information, see ºInterior lightº on page 57.
NOTE: *The 2±step unlocking function can be changed.**The interior light can be set not to come on or the duration
of lighting can be changed. Ask your Lexus dealer for details.
Locking with inside lock button
SV11004

1Lock 2Unlock
Push in the lock button to lock and unlock the door.
When locked, the door cannot be opened with either the
outside or inside door handle.
Closing the door with the lock button pushed in will also lock
the door. Be careful not to lock your keys in the vehicle. The
door will not lock if the key is left in the ignition switch when
closing the front doors.
2003 IS300 from Aug. '02 Prod. (OM53439U)

KEYS AND DOORS
21
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle during an accident.
It also helps prevent the doors from being opened
unintentionally.
Locking with power door lock switch
SV11006a

1Lock 2Unlock
To lock all the doors simultaneously, push the power door
lock switch down on the front side. Pushing down on the
rear side will unlock them.
The same switch is also located on the front passenger's side.
2003 IS300 from Aug. '02 Prod. (OM53439U)

KEYS AND DOORS
22
Locking with rear door child±protector
SV11005

1Lock 2Unlock
Whenever small children are in the vehicle, lock the rear
door so that it does not open from the inside. To do this,
turn the knob to the ºLOCKº position as shown and then
close the door.
BACK DOOR
Opening and closing
SV11021

Opening from outside 1Push 2Open
2003 IS300 from Aug. '02 Prod. (OM53439U)

KEYS AND DOORS
23
To open the back door from the outside, open it during
pressing the back door opener.
If the back door will not open even pressing the back door
opener, press it again.
When
opening the back door, make sure that the back door will
not come down by itself.
The back door can be opened when the vehicle is stopped.
The back door can be locked or unlocked in the following ways.
 Operate the power door lock switch. (See ºDoorsº on page
20.)
 Operate the wireless remote control. (See ºWireless
remote controlº on page 13.)
 Locking (or unlocking) the driver's door will lock (or unlock)
all the other doors simultaneously. In the driver's door lock,
turning the key once will unlock the driver's door and twice
in succession will unlock all doors simultaneously.
If the battery terminal is disconnected and reconnected, the
back door will be automatically locked. Be careful not to lock
your keys in the vehicle.
See ºLuggage stowage precautionsº on page 80 for
precautions in loading luggage.
SV11023
When closing the back door, use the inside handle for
easier reach to the back door.
To close the back door, lower it and press down on it. After
closing the back door, try pulling it up to make sure it is securely
closed.
When closing the back door, make sure it is securely closed.
See ºLuggage stowage precautionsº on page 80 for
precautions in loading luggage.
2003 IS300 from Aug. '02 Prod. (OM53439U)

KEYS AND DOORS
24
CAUTION
Keep the back door closed while driving. This not
only keeps the luggage from being thrown out but
also prevents exhaust gases from entering the
vehicle.
 If the open back door hides the rear stop and tail
lights or rear turn signal lights while you are parked,
other road users must be warned of the presence of
your vehicle by a warning triangle or other device.
NOTICE
To prevent damage to the back door dampers, do not
apply any force, paint or let any other foreign matter onthem.
SV11022

Opening from inside
If the back door opener does not operate, you can open
the back door from the inside.
To open the back door from inside, do the following.
1. Remove the cover with a key.
2003 IS300 from Aug. '02 Prod. (OM53439U)

KEYS AND DOORS
25
SV11018
2. Pull up the lever and open the back door.
Have your vehicle checked/repaired by your Lexus dealer if
the back door opener does not operate.
2003 IS300 from Aug. '02 Prod. (OM53439U)

KEYS AND DOORS
26
2003 IS300 from Aug. '02 Prod. (OM53439U)

SECTION 1 ± 2
27
INSTRUMENTS AND CONTROLS
Switches
Headlight switch28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Headlight dimmer and turn signal switch 30
. . . . . . . . . . . . . . . . . . . . .
Front fog light switch 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Rear fog light switch 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Windshield wiper and washer switch 32
. . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer switch 33
. . . . . . . . . . . . . . . . . . . . . . .
Headlight cleaner switch 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defogger,
and windshield wiper deicer switch 34
. . . . . . . . . . . . . . . . . . . . . . . . . .
Power window switches 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat heater switches 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
2003 IS300 from Aug. '02 Prod. (OM53439U)
