2003 HONDA PILOT Owners Manual

Panic mode allows you to remotely
activate your vehicle’s horn and
lights to attract attention. When
activated, the horn will sound, and
the headlights, parking lights, side
marker lights, taillights and
instrument panel lights will f lash f or
about 30 seconds. To activate panic
mode,pressandholdthePANIC
button f or about one second.When the remote transmitter’s
battery begins to get weak, it may
take several pushes on the button to
lock or unlock the doors and the
tailgate, and the LED will get dim.
Replace the battery as soon as
possible.
Battery type: CR2025
To cancel Panic mode bef ore 30
seconds, press any button on the
remote transmitter. You can also
turn the ignition switch to ON (II).
Panic mode will not activate if the
key is in the ON (II) position.
To replace the battery, remove the
round cover on the back of the trans-
mitter by turning it counterclockwise
with a coin.
CONT INUED
Panic Mode
Replacing t he Bat t ery
Keys and Locks
Inst rument s and Cont rols85
ROUND
COVERBATTERY

´
Õ Ü
As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Avoid severe shock to the trans-
mitter, such as dropping or throwing
it. Also, protect it f rom extreme hot
or cold temperatures.
Clean the transmitter case with a
sof t cloth. Do not use strong
cleaners or solvents that could harm
the case. Immersing the transmitter
in any liquid will harm the trans-
mitter and cause it to not f unction
properly.
Remove the old battery and note the
polarity. Make sure the polarity of
the new battery is the same ( side
f acing up), then insert it in the
transmitter.
Align the mark on the cover
with the mark on the
transmitter, then set the cover in
place and turn it clockwise.
If you lose a transmitter, you will
need to have the replacement
programmed to your vehicle’s
system by your Honda dealer. Any
other transmitters you have will also
need to be reprogrammed.
Transmitter Care
Keys and Locks
Inst rument s and Cont rols86

See page for information on
cargo loading. Keep the tailgate
closed at all times while driving to
avoid damaging the tailgate and to
prevent exhaust gas f rom getting
into the interior. Seeon page .
To open the tailgate, pull the handle,
then lif t up the tailgate.
The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position, the door
cannot be opened f rom the inside
regardless of the position of the lock
tab. To open the door, pull the lock
tab up and use the outside door
handle. To close the tailgate, use the inner
handle to pull the tailgate down, then
press down on the back edge.
56
225
Carbon
Monoxide Hazard
Childproof Door L ocks
T ailgate
Keys and Locks
Inst rument s and Cont rols87
LOCK LEVER HANDLE

Open the glove box by pulling the
bottom of the handle. Close it with a
f irm push. Lock or unlock the glove
box with the master key.
The glove box light comes on only
when the parking lights are on. Glove Box
Keys and Locks
Inst rument s and Cont rols88
GLOVE BOX
An open glove box can cause
serious injury to your passenger
inacrash,evenifthe
passenger is wearing the seat
belt.
Always keep the glove box
closed while driving.

µ
Pull up or push down on the f ront of
the switch to move the seat bottom’s
f ront edge up or down. Pull up or
push down on the rear of the switch
to move the rear of the seat bottom
up or down.
Push the horizontal switch forward
or backward to move the seat
forward or backward. The long horizontal switch adjusts
the seat bottom in several directions.
The short vertical switch adjusts the
seat-back angle.
The EX model has a power
adjustable driver’s seat. The two
power seat adjustment switches are
on the outside edge of the seat
bottom. All other seats in the EX
model have manual adjustments.
All seats in the LX model adjust
manually.
You can adjust the power seat with
the ignition switch in any position.
Make all seat adjustments bef ore
you start driving.
See pages f or important saf ety
inf ormation and warnings about how toproperly position seats and seat-backs. 12 13
CONT INUED
Power Seat A djustments
Seats
Inst rument s and Cont rols89

Pull the center of the horizontal
switch up to raise the seat. Push it
down to lower the seat.Adjust the seat-back angle by
pushing the rear switch in the
direction you want to move.
Vary the lumbar support by moving
the lever on the right side of the
seat-back. Move the lever forward or
backward to adjust the lumbar
support through its f ull range.
On EX model
Driver’s L umbar Support
Seats
Inst rument s and Cont rols90

µ
To adjust the seat forward and
backward, pull up on the lever under
the seat cushion’s f ront edge. Move
the seat to the desired position and
releasethelever.Trytomovethe
seat to make sure it is locked in
position.To change the seat-back angle of the
f ront seats, pull up on the lever on
the outside of the seat bottom.
Make all seat adjustments bef ore
you start driving.
See pages f or important saf ety
inf ormation and warnings about how toproperly position seats and seat-backs. 12 13
Manual Seat Adjustments
Seats
Inst rument s and Cont rols91

To adjust the seat-back angle of the
third seat, pull on the handle on the
back of the seat-back, move the seat-
back to the desired position, and
release the handle. Let the seat-back
latch in the new position.
To change the seat-back angle of the
seats in the second row, pull up on
thehandleontheoutsideof theseat-
back.
The height of your driver’s seat is
adjustable. Turn the front dial on the
outside of the seat cushion to raise
the front of the seat bottom, and turn
the rear dial to raise the rear.On LX model
Seats
Inst rument s and Cont rols
Second and T hird Row Seat
Adjustments
Driver’s Seat Manual Height
Adjustment
92
SECOND
SEAT
THIRD
SEAT
HANDLE
