2003 FORD MUSTANG warning

GENERAL PROCEDURES
Safety Belt Procedure After a Collision
WARNING: All safety belt assemblies include retractors, buckles, front seat belt buckle
support assemblies (slide bar, if so equipped), shoulder belt height adjuster (if equipped), child
safety seat tether bracket assemblies (if equipped) and attaching hardware should be inspected
after any collision. Ford recommends new safety belt assemblies be installed unless a qualified
technician finds the assemblies show no damage and operate correctly. Safety belt assemblies
not in use during a collision should also be inspected and new assemblies installed if either
damage or incorrect operation is noted.
1. Before installing a new safety belt assembly, the safety belt attaching areas must be inspected for damage and distortion. If the attaching points are damaged and distorted, the sheet metal
must be worked back to its original shape and structural integrity.
2. Install the new safety belt(s); refer to the procedure in this section. Carry- out the Functional
Test. For additional information, refer to Safety Belt System in this section.
SECTION 501-
20A: Safety Belt System 2003 Mustang Workshop Manual Klj . 1 ba
12003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

current and historical DTCs through the DLC, using a scan tool. If the air bag indicator does not
function, and the system detects a fault condition, the RCM will signal the GEM to activate an audible
chime. The chime is a series of five sets of five tone bursts. If the chime is heard, the SRS and the air
bag indicator require repair.
LFCs are prioritized. If two or more faults occur at the same time, the fault having the highest priority
will be displayed. After that fault has been corrected, the next highest priority fault will be displayed.
The RCM includes a backup power supply. This feature provides sufficient backup power to deploy the
air bags in the event that the ignition circuit is damaged in a collision before the safing and air bag
sensors determine that deployment is required. The backup power supply will deplete its stored energy
approximately one minute after the battery ground cable is disconnected.
Electrical System
The electrical system that supports the air bag supplemental restraint system (SRS):
zis powered from the battery through the ignition circuit.
z provides the electrical path from the restraints control module (RCM) to the air bag modules.
z provides the electrical path from the RCM to the air bag indicator.
z provides the electrical path from the RCM to the data link connector (DLC).
z provides the electrical path from the RCM to the generic electronic module (GEM).
Sensor WARNING: The restraints control module (RCM) orientation is critical for proper system
operation. If a vehicle equipped with an air bag supplemental restraint system (SRS) has been
involved in a collision in which the center tunnel area has been damaged, inspect the mounting
and bracket for deformation. If damaged, the RCM must be replaced whether or not the air bags
have deployed. In addition, make sure the area of the RCM mounting is restored to its original
condition.
The SRS contains two sensors which are integral to the RCM. The RCM is mounted on the center
tunnel under the instrument panel. Klj . 3 ba
42003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

DIAGNOSIS AND TESTING
Air Bag Supplemental Restraint System (SRS)
Refer to Wiring Diagrams Cell
46 , Air Bag for schematic and connector information.
Restraint System Diagnostic Tool Warning WARNING: This tool is for restraint system service only. Remove from vehicle prior to
road use. Failure to remove could result in injury and possible violation of vehicle safety
standards.
Diagnosing Customer Concerns Without Hard DTCs
If a lamp fault code (LFC) is reported by the customer but is not present when the vehicle comes in for
service, follow the Diagnostic Instructions procedure in this section to identify the intermittent DTC.
Once the DTC is known, read the Normal Operation section of the pinpoint test for the DTC involved.
zFollow the deactivation procedure in this section.
z Determine the location of components involved in creating that code.
z Perform a thorough visual inspection of:
„components.
„ connectors.
„ splices and wiring harnesses.
„ pinched wires.
„ worn insulation on conductors.
Refer to the Possible Causes section of the pinpoint test for the DTC involved, which lists the common
concerns that relate to the DTC. Concerns are listed according to priority.
Diagnosing Customer Concerns with Hard DTCs
WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and possible
violation of vehicle safety standards. SECTION 501-
20B: Supplemental Restraint System 2003 Mustang Workshop Manual Special Tool(s)
Diagnostic Tool, Restraint
System
418-
F088 (105- R0012) Klj . 1 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Most air bag supplemental restraint system (SRS) diagnostic procedures will require the use of the
deactivation and reactivation procedures in this section.
The deactivation and reactivation require the installation and removal of restraint system diagnostic
tools. These procedures require removal of driver air bag module, and the disconnection of the
passenger air bag module. This reduces the risk of deployment of air bag modules and safety belt
pretensioners while diagnostics are being carried out.
Restraint system diagnostic tools are required to carry out diagnosis and testing of the supplemental
restraint system (SRS). It is not acceptable to short-circuit the air bag module connections with a
jumper wire. If a jumper wire is used to short- circuit the air bag module connections, a lamp fault code
(LFC) will be displayed.
WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and possible
violation of vehicle safety standards.
The reactivation procedure requires the removal of any restraint system diagnostic tools installed and
the reconnection of any air bag modules disconnected.
Deactivation Procedure
WARNING: If the supplemental restraint system (SRS) is being serviced, the system must
be deactivated and restraint system diagnostic tools must be installed. Refer to Air Bag Supplemental Restraint System (SRS) in this section.
The air bag restraint system diagnostic tools must be removed and the air bag modules
reconnected when the system is reactivated to avoid non- deployment in a collision, resulting in
possible personal injury.
NOTE: Diagnostics or repairs are not to be performed on a seat equipped with a seat side air bag with
the seat in the vehicle. Prior to attempting to diagnose or repair a seat concern when equipped with a
seat side air bag, the seat must be removed from the vehicle and the restraint system diagnostic tools
must be installed in the seat side air bag electrical connectors. The restraint system diagnostic
tools must be removed prior to operating the vehicle over the road.
NOTE: After diagnosing or repairing an SRS, the restraint system diagnostic tools must be
removed before operating the vehicle over the road.
NOTE: After diagnosing or repairing a seat system, the restraint system diagnostic tools must be
removed before operating the vehicle over the road.
NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the
customer.
1. WARNING: To avoid accidental deployment and possible personal injury, the
backup power supply must be depleted before repairing or replacing any front or side air
bag supplemental restraint system (SRS) components and before servicing, replacing,
adjusting or striking components near the front or side air bag sensors, such as doors,
instrument panel, console, door latches, strikers, seats and hood latches.
Please refer to the appropriate vehicle shop manual to determine location of the front air
bag sensors.
The side air bag sensors are located at or near the base of the B- pillar. Klj . 2 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

To deplete the backup power supply energy, disconnect the battery ground cable and
wait at least one minute. Be sure to disconnect auxiliary batteries and power supplies (if
equipped).
Disconnect the battery ground cable. For additional information, refer to
Section 414 - 01 .
2. Wait at least one minute for the backup power supply in the restraints control module (RCM) to deplete its stored energy.
3. WARNING: Carry a live air bag module with the air bag and trim cover pointed away
from your body. This will reduce the risk of injury in the event of an accidental
deployment.
WARNING: Do not set an air bag module down with the trim cover face down. This
will reduce the risk of injury in the event of an accidental deployment.
Remove the driver air bag module from the vehicle. Refer to Driver Air Bag Module in this
section.
4. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Connect a restraint system diagnostic tool to the vehicle harness at the top of the steering
column.
5. Disconnect the passenger air bag module electrical connector.
6. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Connect a restraint system diagnostic tool to the vehicle harness.
7. Reconnect the battery ground cable. For additional information, refer to Section 414 - 01 .
Reactivation Procedure 1. WARNING: The restraint system diagnostic tool must be removed and the air bag
modules reconnected when the system is reactivated to avoid non- deployment in a
collision, resulting in possible personal injury.
WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Disconnect the battery ground cable. Refer to Section 414 - 01 .
2. Wait at least one minute for the backup power supply in the restraints control module (RCM) to deplete its stored energy.
3. Remove the restraint system diagnostic tool from the vehicle harness connector at the top of the Klj . 3 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

steering column.
4. WARNING: Carry a live air bag module with the air bag and trim cover pointed away
from your body. This will reduce the risk of injury in the event of an accidental
deployment.
Install the driver air bag module. Refer to Driver Air Bag Module in this section.
5. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Remove the restraint system diagnostic tool from the vehicle harness connector at the
passenger air bag module.
6. Connect the passenger air bag module electrical connector.
7. Reconnect the battery ground cable. For additional information, refer to Section 414 - 01 .
8. Prove out the system.
Prove Out Procedure
Turn the ignition switch from the OFF to the RUN position and visually monitor the air bag indicator
with the air bag modules or restraint system diagnostic tools installed. The air bag indicator will light
continuously for approximately six seconds and then turn off. If an air bag supplemental restraint
system (SRS) fault is present, the air bag indicator will either: zfail to light.
z remain lit continuously.
z flash.
The flashing might not occur until approximately 30 seconds after the ignition switch has been turned
from the OFF to the RUN position. This is the time required for the restraints control module (RCM) to
complete the testing of the SRS. If the air bag indicator is inoperative and an SRS fault exists, a chime
will sound in a pattern of five sets of five beeps. If this occurs, the air bag indicator will need to be
repaired before diagnosis can continue.
Glossary
Restraint System Diagnostic Tool
Restraint system diagnostic tools are used to simulate air bag module connections to the system.
Disconnect the Component
Disconnect the component means disconnect the component vehicle harness connector. It does not
mean remove the component. Do not reconnect a disconnected component unless instructed to do so. Deactivate the System Klj . 4 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

2. Turn the ignition switch to the RUN position.
3. Follow manufacturer's instructions for the scan tool being used.
4. PIDs are continuously updated on the display.
Active Commands
This command allows the technician to verify operation of the air bag indicator and chime. When the
air bag output command is executed, the indicator and the chime are activated simultaneously for
approximately four seconds. Both devices are deactivated automatically.
Restraints Control Module (RCM) Diagnostic Trouble Code (DTC) Priority Table DTC
a LFC
b LFC
Priority Description Action To
Take — — 1 The Air Bag Indicator is Illuminated Continuously —
RCM
Disconnected, Inoperative, or Lost/Low Ignition Feed Go To Pinpoint
Test A .
B1342 24 2 RCM Is Faulted INSTALL a
new RCM.
B1231 19 3 RCM Crash Data Memory Full INSTALL a
new RCM.
B1921 21 4 RCM Bracket Ground Resistance High Go To Pinpoint
Test B .
C1414 29 5 Incorrect Vehicle Identification Code Go To Pinpoint
Test C .
B1887 15 6 Driver Air Bag Circuit Shorted to Ground Go To Pinpoint
Test D .
B1916 15 7 Driver Air Bag Circuit Shorted to Battery or Ignition Go To Pinpoint
Test E .
B1888 16 8 Passenger Air Bag Circuit Shorted to Ground Go To Pinpoint
Test F .
B1925 16 9 Passenger Air Bag Circuit Shorted to Battery or Ignition Go To Pinpoint
Test G .
B1932 32 10 Driver Air Bag Circuit Resistance High Go To Pinpoint
Test H .
B1933 33 11 Passenger Air Bag Circuit Resistance High Go To Pinpoint
Test I .
B1934 34 12 Driver Air Bag Circuit Resistance Low Go To Pinpoint
Test J .
B1935 35 13 Passenger Air Bag Circuit Resistance Low Go To Pinpoint
Test K .
B1892 — 17 Air Bag Tone Warning Indicator Circuit Shorted to
Ground or Open Go To Pinpoint
Test L .
B1891 — 18 Air Bag Tone Warning Indicator Circuit Shorted to Battery
or Ignition Go To Pinpoint
Test M .
B1869 Tone
c 19 Air Bag Indicator Inoperative Go To Pinpoint
Test N .
B1870 Tone
c 20 Air Bag Indicator Shorted to Battery Go To Pinpoint
Test O . Klj . 3 ba
52003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

a
DTC: Diagnostic Trouble Code, retrieved using a scan tool.
b LFC: Lamp fault code, flashed on air bag indicator.
c Tone will sound only if additional DTCs are present.
Inspection and Verification 1. Verify the customer concern by checking the air bag indicator in the instrument cluster. Refer to Prove Out the System in this section.
2. Visually inspect for obvious signs of mechanical and electrical damage using the following chart:
3. If the concern is not visually evident, use the scan tool to retrieve diagnostic trouble codes (DTCs) and perform the on- demand self test.
4. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
If the on- demand self test is passed and no DTCs are retrieved, GO to Symptom Chart .
5. If DTCs are retrieved, proceed to the Restraints Control Module (RCM) Diagnostic Trouble Code (DTC) Priority Table.
Symptom Chart — — — No Communication with the Restraints Control Module Go To Pinpoint
Test P .
Visual Inspection Chart Mechanical Electrical
z
Damaged restraints control module (RCM) bracket z
Open fuse(s)
z Damaged wiring harness
z Loose or corroded connectors
z Circuitry open/shorted Symptom Chart
Condition
Possible Sources Action
z Air bag warning indicator is
illuminated continuously z
Circuitry.
z Worn or damaged
connector component.
z RCM.
z Instrument cluster. z
Go To Pinpoint Test A .
z Air bag indicator flashing zAir bag SRS system
fault. z
REFER to DTC
Priority Table.
z Audible tone — DTCs
retrieved z
Air bag SRS system
fault. z
Go To Pinpoint Test N .
z Go To Pinpoint Test O .
z No communication with the zScan Tool. zGo To Pinpoint Klj . 4 ba
52003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...
