HEATED SEAT SWITCH-PASSENGER - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 P138 20VT/LG PASSENGER SEAT LOW HEAT LED DRIVER
2 Y161 20OR/RD PANEL LAMPS FEED
3 Z260 20DG/BK GROUND
4 P131 20RD/DG HEATED SEAT SWITCH SUPPLY
5 P140 20VT/BK PASSENGER SEAT HIGH HEAT LED DRIVER
6 P134 20TN/LG PASSENGER SEAT HEATER MUX SWITCH
HORN SWITCH - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X3 20BK/RD HORN SWITCH SENSE
2- -
HORN-HIGH NOTE - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z307 18BK/WT GROUND
HORN-LOW NOTE - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z308 18BK/BR GROUND
IDLE AIR CONTROL MOTOR (3.7L/5.9L/8.0L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
C K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVER
B K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
A K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
D K59 18VT/BK IDLE AIR CONTROL MOTOR NO. 4 DRIVER
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 65

IDLE AIR CONTROL MOTOR (NGC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K60 18YL/BK IAC RETURN
2 K39 18GY/RD IAC MOTOR CONTROL
IGNITION COIL (5.9L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 16DG/OR AUTO SHUT DOWN RELAY OUTPUT
2 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
IGNITION COIL-LEFT (8.0L)-3WAY
CAV CIRCUIT FUNCTION
1 K17 18DB/TN IGNITION COIL NO. 8 DRIVER
2 A142 14DG.OR AUTO SHUT DOWN RELAY OUTPUT
3 K32 18YL/GY IGNITION COIL NO. 4 DRIVER
IGNITION COIL-RIGHT (8.0L)-4WAY
CAV CIRCUIT FUNCTION
1 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3 K18 18RD/YL IGNITION COIL NO. 3 DRIVER
4 K43 18DG/GY IGNITION COIL NO. 6 DRIVER
8W - 80 - 66 8W-80 CONNECTOR PIN-OUTSDR

INTEGRATED POWER MODULE C1 - 26 WAY
CAV CIRCUIT FUNCTION
1 A112 12RD/TN (DIESEL) FUSED B(+)
1 A17 16RD/BK (EXCEPT DIESEL) FUSED B(+)
2 Y107 20VT/RD FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 A20 20RD/DB FUSED IGNITION SWITCH OUTPUT (RUN)
5 Y141 18DG/WT TRAILER TOW LEFT TURN RELAY OUTPUT
6- -
7 Y140 18WT/PK TRAILER TOW RIGHT TURN RELAY OUTPUT
8 Y131 14RD/WT FUSED B(+)
9 M1 18PK FUSED B(+)
10 L7 18BK/YL TRAILER TOW RELAY OUTPUT
11 A21 16DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 F35 18RD FUSED B(+)
13 F32 20RD/YL FUSED B(+)
14 X2 18DG/RD HORN RELAY OUTPUT
15 A64 16DG/WT (EXCEPT 4.7L) FUEL PUMP RELAY OUTPUT
16 A108 18TN/RD FUSED B(+)
17 L76 18BK/OR FUSED PARK LAMP RELAY OUTPUT
18 F32 18RD/YL FUSED B(+)
19 Y174 18PK/VT FUSED PARK LAMP RELAY OUTPUT
20 - -
21 - -
22 - -
23 Y145 18DB/YL CONDENSER FAN RELAY CONTROL
24 - -
25 - - -
26 - -
INTEGRATED POWER MODULE C2 - WHITE 15 WAY
CAV CIRCUIT FUNCTION
1 A30 10RD/WT (EXCEPT BASE) FUSED B(+)
2 A34 16LB/RD (ETC) FUSED B(+)
3 Y148 18YL/RD FUSED B(+)
4 A61 16DG/BK (3.9L/5.7L/5.9L) FUEL PUMP RELAY OUTPUT
5 F37 12RD/LB (EXCEPT BASE) FUSED B(+)
6 A2 10PK/BK FUSED B(+)
7 A14 20RD/WT FUSED B(+)
8 A10 14RD/DG FUSED B(+)
9 A12 18RD/TN FUSED B(+)
10 A22 16BK/OR FUSED B(+)
11 - -
12 F30 18RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 F75 18VT (EXCEPT BASE) FUSED B(+)
14 A1 16RD FUSED B(+)
15 - -
8W - 80 - 70 8W-80 CONNECTOR PIN-OUTSDR

INTEGRATED POWER MODULE C5 - 26 WAY
CAV CIRCUIT FUNCTION
1 A38 16OR FUSED IGNITION SWITCH OUTPUT (RUN)
2 K173 18LG (GAS EXCEPT 5.9L) GROUND
2 K173 18LG (5.9L) GROUND
2 K173 20LG (DIESEL) GROUND
3- -
4 L10 18BR/LG FUSED IGNITION SWITCH OUTPUT (RUN)
5 C23 16DG CONDENSER FAN RELAY OUTPUT
6 F15 20DB (DIESEL) FUSED IGNITION SWITCH OUTPUT (RUN)
7 G115 20YL/WT (DIESEL) FUSED B(+)
8 Z316 12BK/OR GROUND
9- -
10 - -
11 C13 18DB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
12 - -
13 A42 18DG (CALIFORNIA) OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT
14 Z114 18BK/LG (DIESEL) GROUND
14 Y145 20DB/YL (EXCEPT DIESEL)
15 A17 16RD/BK (EXCEPT DIESEL)
15 Y135 18LG/BK (DIESEL) FUSED IGNITION SWITCH OUTPUT (RUN-START)
16 K30 18PK TRANSMISSION CONTROL RELAY CONTROL
17 F121 16TN/BK HEATED MIRROR RELAY OUTPUT
18 C3 18DB/BK A/C COMPRESSOR CLUTCH RELAY OUTPUT
19 - -
20 - -
21 C16 20LB/YL HEATED MIRROR RELAY CONTROL
22 V4 16RD/YL WIPER RELAY HIGH SPEED OUTPUT
23 F23 18DB/YL FUSED B(+)
24 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
25 - -
26 F15 20DB FUSED IGNITION SWITCH OUTPUT (RUN)
26 Y106 20OR/RD (ELECTRIC TRANSFER
CASE)FUSED IGNITION SWITCH OUTPUT (RUN)
INTEGRATED POWER MODULE C6 - BLACK 15 WAY
CAV CIRCUIT FUNCTION
1- -
2 Y133 14RD/OR FUSED B(+)
3- -
4 A142 16DG/OR AUTO SHUT DOWN RELAY OUTPUT
5- -
6- -
7- -
8- -
9- -
10 A93 12RD/BK (DIESEL) FUEL HEATER RELAY OUTPUT
10 C23 16DG (EXCEPT DIESEL)
11 A112 12RD/TN (DIESEL) FUSED B(+)
11 A17 16RD/BK (EXCEPT DIESEL)
12 A31 14BK/WT FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 - -
14 T16 14RD TRANSMISSION CONTROL RELAY OUTPUT
15 - -
8W - 80 - 72 8W-80 CONNECTOR PIN-OUTSDR

INTEGRATED POWER MODULE C7 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 T40 14BR STARTER MOTOR RELAY OUTPUT
2 V3 16BR/WT WIPER RELAY LOW SPEED OUTPUT
3 Y105 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 F235 18RD FUSED B(+)
5- -
6 Y171 18WT/DG LEFT LOW BEAM DRIVER
7 Y168 18WT/LB RIGHT HIGH BEAM DRIVER
8- -
9 A64 16DG/WT FUEL PUMP RELAY OUTPUT
10 - -
11 K51 20DB/YL AUTO SHUT DOWN RELAY CONTROL
12 K127 18DB/OR (CALIFORNIA) OXYGEN SENSOR DOWNSTREAM RELAY CONTROL
13 - -
14 - -
15 Y170 18WT/LG LEFT HIGH BEAM DRIVER
16 Y153 18DB/RD ADJUSTABLE PEDAL RELAY OUTPUT
17 - -
18 - -
19 K31 20BR -
20 L39 18LB (FOG LAMPS) FOG LAMP RELAY OUTPUT
21 A41 16YL FUSED IGNITION SWITCH OUTPUT (START)
22 Y169 18WT/TN RIGHT LOW BEAM DRIVER
23 T24 20BR/YL (EXCEPT NGC) PARK/NEUTRAL POSITION SWITCH SENSE (T41)
23 T752 18DG/OR (NGC)
24 E1 20TN FUSED B(+)
25 A141 18DG/WT (EXCEPT NGC) FUSED AUTO SHUT DOWN RELAY OUTPUT
26 - -
KNOCK SENSOR (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K73 18YL/BK KNOCK SENSOR NO. 1 SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K74 18BR/VT KNOCK SENSOR NO. 2 SIGNAL
4 K4 18BK/LB SENSOR GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 73

KNOCK SENSOR-LEFT (5.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K73 18YL/BK KNOCK SENSOR NO. 1 SIGNAL
2 Y205 18BR/WT KNOCK SIGNAL RETURN
KNOCK SENSOR-RIGHT (5.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K74 18BR/VT KNOCK SENSOR NO. 2 SIGNAL
2 Y206 18DB/VT kNOCK SIGNAL RETURN
LEAK DETECTION PUMP (NGC) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z54 18BK/PK GROUND
2 K107 18OR NVLD SWITCH SIGNAL
3 K106 18WT/DG NVLD SOLENOID CONTROL
LEAK DETECTION PUMP - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2 K125 18WT/DB GENERATOR SOURCE
3 K106 18WT/DG LEAK DETECTION PUMP SWITCH SENSE
4 K107 18OR LEAK DETECTION PUMP SOLENOID CONTROL
LICENSE LAMP-LEFT - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Y174 18PK/VT FUSED PARK LAMP RELAY OUTPUT
2 Z53 18BK GROUND
8W - 80 - 74 8W-80 CONNECTOR PIN-OUTSDR

OUTPUT SPEED SENSOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
OVERDRIVE SWITCH - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 T6 20OR/WT OVERDRIVE OFF SWITCH SENSE
2 Z71 20BK/TN GROUND
OVERHEAD MAP/READING LAMP (EXCEPT BASE) - NATURAL 3 WAY
CAV CIRCUIT FUNCTION
1 M11 20PK/LB COURTESY LAMP GROUND
2 F32 18RD/YL FUSED B(+)
3 M20 20BR COURTESY LAMP DRIVER
OXYGEN SENSOR 1/1 UPSTREAM - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 A141 18DG/WT FUSED AUTO SHUT DOWN RELAY OUTPUT
1 K41 18BK/DG (NGC) O2 1/1 HEATER CONTROL
2 Z192 18BK/WT (NGC) GROUND
2 K199 18BR/VT OXYGEN SENSOR 1/1 HEATER CONTROL
3 K4 18BK/LB SENSOR GROUND
3 Y213 18PK/LB (NGC) O2 UPSTREAM RETURN
4 K99 18BR/OR (NGC) O2 1/1 SIGNAL
4 K41 18BK/DG OXYGEN SENSOR 1/1 SIGNAL
8W - 80 - 78 8W-80 CONNECTOR PIN-OUTSDR

OXYGEN SENSOR 1/2 DOWNSTREAM - NATURAL 4 WAY
CAV CIRCUIT FUNCTION
1 A141 18DG/WT (EXCEPT CALIFORNIA) FUSED AUTO SHUT DOWN RELAY OUTPUT
1 A42 18DG (CALIFORNIA) OXYGEN SENSOR RELAY OUTPUT
1 K199 18BR/VT (NGC) O2 1/2 HEATER CONTROL
2 Z188 18BK/LB (NGC) SENSOR GROUND
2 Z193 18BK/WT (CALIFORNIA) GROUND
2 K299 18BR/WT (EXCEPT CALIFORNIA) OXYGEN SENSOR 1/2 HEATER CONTROL
3 K4 18BK/LB SENSOR GROUND
3 K904 18BR/DG (NGC) O2 RETURN DOWNSTREAM
4 K141 18TN/WT (NGC) 02 1/2 SIGNAL
4 K141 18TN/WT OXYGEN SENSOR 1/2 SIGNAL
OXYGEN SENSOR 2/1 UPSTREAM (CALIFORNIA 4.7L/CALIFORNIA 5.9L)-4WAY
CAV CIRCUIT FUNCTION
1 A141 18DG/WT FUSED AUTO SHUT DOWN RELAY OUTPUT
1 K299 18BR/WT (NGC) O2 2/1 HEATER CONTROL
2 Z193 18BK/DG (NGC) GROUND
2 K299 18BR/WT OXYGEN SENSOR 2/1 HEATER CONTROL
3 K4 18BK/LB SENSOR GROUND
3 Y213 18PK/LB (NGC) O2 UPSTREAM RETURN
4 K241 18LG/RD (NGC) 02 2/1 SIGNAL
4 K241 18LG/RD OXYGEN SENSOR 2/1 SIGNAL
OXYGEN SENSOR 2/2 DOWNSTREAM (CALIFORNIA 4.7L/CALIFORNIA 5.9L)-4WAY
CAV CIRCUIT FUNCTION
1 A42 18DG OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT
1 K399 18BR/GY (NGC) O2 2/2 HEATER CONTROL
2 Z186 18BK/LB (NGC) GROUND
2 Z192 18RD GROUND
3 K4 18DB SENSOR GROUND
3 K904 18BR/DG (NGC) O2 RETURN DOWNSTREAM
4 K341 18TN/WT (NGC) O2 2/2 SIGNAL
4 K341 18OR OXYGEN SENSOR 2/2 SIGNAL
