IMMOBILIZER ANTI-THEFT SYSTEM 9T–11
DAEWOO M–150 BL2
The VIN code is calculated by the Immobilizer using a
random generator.
The VIN code is transmitted from the Immobilizer in the
release message communication only incase of using
an authorized key. Without an authorized key it is not
possible to getthe system VIN code.In case of ECM in-
ternal state is in Virgin mode or neutral mode the ECM
learns the system VIN code automatically after receiving
the first release response message.
To get a synchronized Immobilizer system (same VIN-
code in Immobilizer and ECM,authorized key) the DLC
test equipment has to be used for authorization of the
keys(first key coding). The usage of this test equipment
is restricted to authorized persons.

Communication with the DLC-test equipment. Main
functions are the key coding procedure, the VIN-code
handling and the support for system test functions.

Handling of the software watchdog
Operation
In the active mode of immobilizer (engine OFF, IG key
OFF) the status LED is blinking as mode A. When igni-
tion is turned ON, the system wakes up and tries to read
out the transponder.
In case of the detection of a valid key , The release mes-
sage communication with the ECM takes place. The sta-
tus LED displays the Immobilizer state “valid key”.
After turning off the ignition(ignition OFF detection simi-
lar to the ECM ignition OFF detection), the Immobilizer
changes to the active mode. The status LED is blinking
as Mode A.
Data Link Connector (DLC) Mode
When the ignition is on, a scan tool can switch the immo-
bilizer control unit to the DLC mode for diagnostics, key
coding and ID coding.

The status LED is turned off during DLC-mode

The Immobilizer will answer all correct messages,
which are defined as Immobilizer messages.
ID Code Handling
One of 65,535 VIN codes is stored in the immobilizer
EEPROM.
The VIN code can be erased by using “Reset VIN code”
command of the scan tool.
When the immobilizer control unit calculates a new VIN
code, ECM VIN code should be reset to get identical
with the immobilizer control unit’s.
During diagnostic procedures, the VIN code can be read
for comparison with the ECM VIN code by using the
scan tool’s “Read immobilizer control unit VIN code”
command.
SERIAL DATA LINK
Serial data can be exchanged between a scan tool and
the ECM and the Immobilizer control unit. The scan tool
connection is the data link connector (DLC).
ELECTRONIC CONTROL MOUDLE
(ECM)

ECM in Virgin mode
In this mode, the ECM knows only the model vehicle
identifier code.
The engine can be locked/unlocked.
ECM requests to ICU the VIN number. As soon as the
ECM receives two correct consecutive communica-
tion frames with the same VIN code the ECM learns
it.
The VIN code will be stored in non-volatile memory at
the end of power latch phase. ECM enters in Learnt
mode.

ECM in Learnt mode
In such a state, ECM checks on every communica-
tion, the correct encoding of the ICU.
If the code received is not correct, then the vehicle is
immobilized.
The coded 5 bytes of data emitted by ECM are a mix-
ture of MIN code and random.
The coded 5 bytes of data emitted by ICU are a mix-
ture of VIN code and random.

ECM in Neutral mode
This mode is a special intermediate mode, used for
ICU replacement or immobilizer option installation.
ECM request to ICU the VIN number. As soon as the
ECM receives two correct consecutive communica-
tion frames with the same VIN code the ECM learns
it. The VIN code will be stored in non-volatile memory
at the end of power latch phase. ECM enters in
Learnt mode.

After turning on the ignition the ECM will control the
engine in a normal way for starting and running while
waiting for a valid release response message from
the Immobilizer.
1. After receiving a response message including the in-
formation “ICU in learnt mode” and the correct sys-
tem VIN-code
→ the ECM enters the release state, which allows to
continue the running of the engine.
2. After receiving a response message including the in-
formation “ICU in learnt mode” and a wrong system
VIN-code
→ the ECM does not send a new request and enters
the blocked state, which causes the activation of the
immobilization actions of the engine.

IMMOBILIZER ANTI-THEFT SYSTEM 9T–15
DAEWOO M–150 BL2
DTC 1600 – ECM Immobilizer Error (No Answer)
StepActionValueYesNo
1
Connect the scan tool using the following procedure:
1. Insert the cartridge into the scan tool.
2. Turn the ignition switch to the OFF position.
3. Connect the scan tool to the data link connector
(DLC).
4. Connect the scan tool’s power cord to the cigar
lighter socket.
5. Turn the ignition ON, but do not start the engine.
Is communication established between the scan tool
and the immobilizer control unit?
–
Go to Step 2
Go to
“Communi-
cation
Between
Immobilizer
and Test
Equipment”
2
Select CURRENT KEY STATUS from the scan tool
menu.
Did the STATUS OF CURRENT KEY message
indicate “KEY IS WRONG”?
–
Go to “Key
Status Errors”
Go to Step 3
3
Read the IMMO & ECM ID CODE message that
was displayed after requesting DIAGNOSIS.
Did the message differ from normal message?
Normal Message –ECM MODE: LEARNT
IMMO. MODE: LEARNT
VIN CODE: SAME
–
Go to
“Identification
(ID) Code
Repro-
gramming”
Go to Step 4
4
Check for an open serial data wire between the
immobilizer control unit and the ECM.
Was the circuit open?
–
Go to Step 5Go to Step 6
5
Repair the open serial data wire between the ECM
and the immobilizer control unit.
Is the repair complete?
–
System OK
–
6
1. Replace the ECM.
2. Reprogram the identification (ID) code. Refer to
“Identification (ID) Code Reprogramming” in this
section.
Is the repair complete?
–
System OK
–

IMMOBILIZER ANTI-THEFT SYSTEM 9T–17
DAEWOO M–150 BL2
DTC 1601 – ECM Immobilizer Error (Incorrect Answer)
StepActionValueYesNo
1
Connect the scan tool using the following procedure:
1. Insert the cartridge into the scan tool.
2. Turn the ignition switch to the OFF.
3. Connect the scan tool to the data link connector
(DLC).
4. Connect the scan tool’s power cord to the cigar
lighter socket.
5. Turn the ignition ON, but do not start the engine.
Is communication established between the scan tool
and the immobilizer control unit?
–
Go to Step 2
Go to
“Communi-
cation
Between
Immobilizer
and Test
Equipment”
2
1. Select CURRENT KEY STATUS from the scan
tool menu.
2. Read the STATUS OF CURRENT KEY message.
Does the KEY STATUS message indicate “KEY IS
WRONG”?
–
Go to “Key
Status Errors”
Go to Step 3
3
1. Select DIAGNOSIS from the scan tool menu.
2. Read the IMMO & ECM ID CODE (immobilization
and electronic control module identification code)
message.
Did the message differ from normal message?
Normal Message –ECM MODE: LEARNT
IMMO. MODE: LEARNT
VIN CODE: SAME
–Go to
“Identification
(ID) Code
Repro-
gramming”
Go to Step 4
4
Check for an open serial data wire between the
immobilizer control unit and the electronic control
module (ECM).
Was the circuit open?
–
Go to Step 5Go to Step 6
5
Repair the open serial data wire between the ECM
and the immobilizer control unit.
Is the repair complete?
–
System OK
–
6
1. Replace the ECM.
2. Reprogram the ID code.
Is the repair complete?
–
System OK
–

IMMOBILIZER ANTI-THEFT SYSTEM 9T–19
DAEWOO M–150 BL2
DTC 1602 – ECM Immobilizer Error (ECM Locked)
StepActionValueYesNo
1
Connect the scan tool using the following procedure:
1. Insert the cartridge into the scan tool.
2. Turn the ignition switch to the OFF.
3. Connect the scan tool to the data link connector
(DLC).
4. Connect the scan tool’s power cord to the cigar
lighter socket.
5. Turn the ignition ON, but do not start the engine.
Is communication established between the scan tool
and the immobilizer control unit?
–
Go to Step 2
Go to
“Communi-
cation
Between
Immobilizer
and Test
Equipment”
2
1. Select CURRENT KEY STATUS from the scan
tool menu.
2. Read the STATUS OF CURRENT KEY message.
Does the KEY STATUS message indicate “KEY IS
WRONG”?
–
Go to “Key
Status Errors”
Go to Step 3
3
1. Select DIAGNOSIS from the scan tool menu.
2. Read the IMMO & ECM ID CODE (immobilization
and electronic control module identification code)
message.
Did the message differ from normal message?
Normal Message –ECM MODE: LEARNT
IMMO. MODE: LEARNT
VIN CODE: SAME
–Go to
“Identification
(ID) Code
Repro-
gramming”
Go to Step 4
4
Check for an open serial data wire between the
immobilizer control unit and the electronic control
module (ECM).
Was the circuit open?
–
Go to Step 5Go to Step 6
5
Repair the open serial data wire between the ECM
and the immobilizer control unit.
Is the repair complete?
–
System OK
–
6
1. Replace the ECM.
2. Reprogram the ID code.
Is the repair complete?
–
System OK
–

IMMOBILIZER ANTI-THEFT SYSTEM 9T–21
DAEWOO M–150 BL2
P 1628 – ECM Immobilizer Error (No Successful Communication)
StepActionValueYesNo
1
Connect the scan tool using the following procedure:
1. Insert the cartridge into the scan tool.
2. Turn the ignition switch to the OFF position.
3. Connect the scan tool to the data link connector
(DLC).
4. Connect the scan tool’s power cord to the cigar
lighter socket.
5. Select immobilizer mode on the scan tool.
6. Turn the ignition ON, but do not start the engine.
Is communication established between the scan tool
and the immobilizer control unit?
–
Go to Step 2
Go to
“Communi-
cation
Between
Immobilizer
and Test
Equipment”
2
Read the IMMO & ECM ID CODE message that
was displayed after requesting DIAGNOSIS.
Did the message differ from normal message?
Normal Message –ECM MODE: LEARNT
IMMO. MODE: LEARNT
VIN CODE: SAME
–
Go to
“Identification
(ID) Code
Repro-
gramming”
Go to Step 3
3
Check for an open serial data wire between the
immobilizer control unit and the ECM.
Was the circuit open?
–
Go to Step 4Go to Step 5
4
Repair the open serial data wire between the ECM
and the immobilizer control unit.
Is the repair complete?
–
System OK
–
5
1. Replace the immobilizer.
2. Reprogram the identification (ID) code. Refer to
“Identification (ID) Code Reprogramming” in this
section.
Is the repair complete?
–
System OK
–
Go to Step 6
6
1. Replace the ECM.
2. Turn the ignition ON, OFF for more than 4
seconds.
3. Turn the ignition ON.
Is the repair complete?
–
System OK
–

9T–24 IMMOBILIZER ANTI-THEFT SYSTEM
DAEWOO M–150 BL2
KEY STATUS ERRORS (FENIX 5MR)
The following KEY STATUS messages may be shown
on the scan tool after commanding FIRST KEY COD-
ING and KEY ADD:

IGNITION OFF STATUS. This message informs the
technician that the ignition is OFF during the key cod-
ing process. Turn the ignition ON during key coding,
but do not start the engine.

KEY IS OCCUPIED. Only five keys may be coded. If
a new key is desired, the previous key codes must be
deleted. Up to five keys may then be authorized.

ALREADY AUTHORIZED. Key coding is being at-
tempted with a key that is already authorized.

ERROR NO. A3, A4, A5. There is no communication
between the transponder in the ignition key and the
detection coil. Follow the steps below to diagnose the
problem:
1. Try a different key. If a different key works, the
problem is in the original key.
2. If trying a different key results in the same er-
ror message, replace the detection coil.

INVALID KEY. The communication between the im-
mobilizer control unit and the key transponder has not
validated the key. Follow the steps below to diagnose
the problem:
1. Code the key. Refer to “Key Coding Proce-
dure” in this section.
2. If the same message is received after key
coding, check the connection of the detection
coil.
3. If the detection coil is okay, replace the immo-
bilizer. Refer to “Immobilizer Control Unit” in
this section.

NO TRANSPONDER DETECTED. The fault may be
in ignition key transponder, the detection coil, or the
immobilizer. Follow the steps below to diagnose the
problem:
1. Try a different key. If a different key works, the
problem is in the original key.
2. If trying a different key results in the same er-
ror message, check the connection of the
detection coil.
3. If the connection of the detection coil is okay,
disconnect the detection coil and use an ohm-
meter to check for an open detection coil.
4. If the detection coil is not open, replace the
immobilizer control unit. Refer to “Immobilizer
Control Unit” in this section.
KEY STATUS ERRORS (SIRIUS D3)
The following KEY STATUS messages may be shown
on the scan tool after commanding FIRST KEY COD-
ING and KEY ADD:

IGNITION OFF STATUS. This message informs the
technician that the ignition is off during the key coding
process. Turn the ignition ON during key coding, but
do not start the engine.

KEY IS OCCUPIED. Only five keys may be coded. If
a new key is desired, the previous key codes must be
deleted. Up to five keys may then be authorized.

ALREADY AUTHORIZED. Key coding is being at-
tempted with a key that is already authorized.

ERROR NO. A3, A4, A5. There is no communication
between the transponder in the ignition key and the
detection coil. Follow the steps below to diagnose the
problem:
1. Try a different key. If a different key works, the
problem was in the original key.
2. If trying a different key resulted in the same error
message, replace the detection coil.

INVALID KEY. The communication between the im-
mobilizer control unit and the key transponder has not
validated the key. Follow the steps below to diagnose
the problem:
1. Code the key. Refer to “Key Coding Procedure” in
this section.
2. If the same message is received after key coding,
check the connection of the detection coil.
3. If the detection coil is okay, replace the immobiliz-
er. Refer to “Immobilizer Control Unit” in this sec-
tion.

NO TRANSPONDER DETECTED. The fault may be
in ignition key transponder, the detection coil, or the
Immobilizer. Follow the steps below to diagnose the
problem
1. Try a different key. If a different key works, the
problem was in the original key.
2. If trying a different key resulted in the same error
message, check the connection of the detection
coil.
3. If the connection of the detection coil is okay, dis-
connect the detection coil and use an ohmmeter to
check for an open detection coil.
4. If the detection coil was not open, replace the im-
mobilizer control unit. Refer to “Immobilizer Control
Unit” in this section.

IMMOBILIZER ANTI-THEFT SYSTEM 9T–27
DAEWOO M–150 BL2
6. Turn the ignition OFF and ON again, but do not
crank or start the engine. The ECM will reset the
ECM ID code to match the new ID code that was
calculated and sent by the immobilizer control unit
when the ignition was first turned ON after the reset
command.
7. Return the system to the normal mode.
8. Turn OFF the ignition.
9. Turn ON the ignition.
10. Start the engine.
After reprogramming the ID code, the scan tool SYS-
TEM DIAGNOSIS command can verify that the ECM ID
code matches the immobilizer control unit ID code.
If the reprogramming procedure does not result in
matching ID codes, check the electrical connectors for
the serial data wire between the immobilizer control unit
and the ECM.
TRANSPONDER
Each valid ignition key has an internal transponder
which is a read /write transponder.
The transponder contains an implementation of a cryp-
to-algorithm with 96 bits of user configurable secret-key
contained in EEPROM and transmits data to the ICU by
modulating the amplitude of the electromagnetic field,
and receives data and commands in a similar way.
D105A504
DETECTION COIL
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the steering column covers. Refer to Section
6E, Steering Wheel and Column.
D29T001
2. Remove the detection coil.

Disconnect the two-pin connector from the detec-
tion coil (1).

Pry the detection coil away from the lock cylinder
(2).
Important: If the detection coil will be replaced with a
new one, it does not matter if the key position trim ring is
damaged during removal. A new trim ring is part of the
new detection coil.
