Arrive safely
4
Protecting the environment
Development…Motorcyclists have an intensive
relationship with nature. BMW
has made sure that they con-
tinue to enjoy the best possible
prospects for successful riding
in the future.
For instance, your new Boxer is
available with exhaust emission
control by closed-loop, three-
way catalytic converter.
…waste disposal …Behind the scenes, in the repair
shop, we do not neglect the
pro-environmental aspects of
our work either.
Wherever possible, we use
environmentally acceptable
biodegradable materials. We
ensure strict compliance with
all environmental legislation, for
example the correct disposal of
old oil, which is now classified
as hazardous waste in many
countries.
…recyclingAlongside the correct disposal
of environmentally hazardous
materials, recycling is another
high-priority issue for BMW.
For example, plastics that are
marked according to type can
more easily be returned to the
materials cycle. Remember:
when it comes to making
repairs to your motorcycle, the
authorised BMW motorcycle
workshop is far better equipped
to protect the environment than
you are at home.
10Classic1g.book Seite 79 Freitag, 27. Januar 2006 2:01 14

80
Arrive safely
4
The essentialsTo reach your destination safely
every time, there is only one
choice:
Helmet
 Suit
 Gloves
 Boots
It is foolhardy to ride without
these items of clothing. This
even applies to short journeys,
and to every season of the year.
Well-planned riding
pleasure
Many motorcyclists have learned
the hard way that the proper cloth-
ing contributes so much to riding
pleasure. You must feel comforta-
ble and relaxed – and your own
safety must never be endangered.
There is no doubt about it: when
buying motorcycling clothing, you
simply cannot set your sights too
high. It is good to know that the
BMW brand can be trusted to
supply you with safe, high-quality
rider's clothing as well.
Information on the latest products
is always available from your
authorised BMW motorcycle
dealer.
BMW rider ’s equipment
10Classic1g.book Seite 80 Freitag, 27. Januar 2006 2:01 14

81
Arrive safely
4
Always an idea aheadThis is our motto – and it is one
we live up to. For many years
now, BMW has offered the
enthusiast everything capable
of enhancing the fascination of
motorcycling. A unique pro-
gramme that is regularly
updated and offers plenty of
scope for choosing items
according to individual prefer-
ences.
Ask your authorised BMW
motorcycle dealer for the latest
upgrades and retrofits. Every accessory product is
made to the same exemplary
standards of design, function
and quality as the motorcycle
itself. This calls for a great deal
of experience, but our engi-
neers are themselves enthusi-
astic motorcyclists who know
what is needed. Accessories
and motorcycle equipment are
included when a new motorcy-
cle is being developed, and
their practical features opti-
mised in a series of thorough
tests. This is your guarantee of
the high quality you expect from
BMW.
BMW motorcycle equipment
10Classic1g.book Seite 81 Freitag, 27. Januar 2006 2:01 14

82
Arrive safely
4
Training means extra safety
Cornering and braking
need to be practiced
Develop a "sixth sense" for
potentially dangerous situa-
tions. What this means: look
ahead, plan how to avoid possi-
bly dangerous situations and
study other road users’ behav-
iour with a degree of healthy
scepticism.
– Take bends smoothly and
rhythmically, avoiding violent
braking and acceleration
– Approach bends slower than
you feel they can be taken; a
neat riding style will get you to
your destination more safely
than sheer speed
– Ride at the inner edge of the
ideal line, look ahead and plan
to leave the bend as smoothly
as you entered it Allow for reaction time when
judging braking distances.
–
at a speed of 50 km/h, for
instance, one second's hesi-
tation means that
about 14 meters are covered
additionally before the brakes
are applied
– At 90 km/h, this distance
grows to 25 metres
Practice applying the brakes
with and without an extra load
on the motorcycle, and study its
reactions on various kinds of
road surface.
Work up to the wheel lock limit
gradually.
BMW has a worthwhile safety
contribution to make in this area
too – BMW Safety Training.
These programmes are a won-
derful opportunity: systematic
basic and follow-up training
enables you to master situa-
tions close to the limit and keep
your motorcycle under
supreme control whatever
happens.
10Classic1g.book Seite 82 Freitag, 27. Januar 2006 2:01 14

83
Arrive safely
4
Concluding thoughts
Now it’s your turn Regular care is important,
with all functions checked
before the journey starts
 Use only genuine BMW
accessories. These satisfy all
safety requirements and are
precisely matched to your
BMW motorcycle.
 Your authorised
BMW motorcycle dealer is
best placed to service your
motorcycle
 Do not under any circum-
stances install unapproved
accessories: They may give
rise to a safety risk, and inval-
idate your insurance policy
and the motorcycle's general
operating permit
 Technical modifications
should always be entrusted to
the trained specialists
employed by your authorised
BMW motorcycle dealer.
\f Note:
Your authorised BMW motorcy-
cle dealer can supply you with
useful items to accompany the
Maintenance Instructions.
– BMW Repair Manual
– BMW set of circuit diagrams
It is good to know you have
thought of everything, isn't it?
Our aim is to make your
journey safer
We want you to reach your des-
tination safely – and for riding
your BMW Boxer to be the most
delightful leisure pastime in the
world!
10Classic1g.book Seite 83 Freitag, 27. Januar 2006 2:01 14

84
Index
i
AABS - anti-lock brake system, 70
Adjusting beam throw, 38
Adjusting front seat, 14, 15, 16
Anti-lock brake systemNotes, 68, 70, 71, 72,
73, 74, 75
BBMW Integral ABSChanging brake fluid, 33
Checking brake fluid level, 33
Troubleshooting chart, 75
Brake fluid level CheckFront brakes, 31, 35
Rear brakes, 32, 36
Brake servo, 70
Brake system
With BMW Integral ABS, 33,
34, 35, 36
Without BMW Integral ABS, 30,
31, 32
Brake system, general, 28, 29
Brake-fluid level Check, 30
Braking, precautions, 66
CCapacity, 25
Catalytic converter, 51 Safety instructions, 51
Centre stand, 54, 55
Changing brake fluid, 30 Checking brake fluid level, 30
Checking brake pads, 29
Checking the brake system, 28
Choke
Cold start, 61
Cold-start lever, 12
Choke (cold-start lever) Operation, 61
Clock, 10
Closing system cases, 18
Clutch
Fluid level, 37
Clutch lever, 26
Cockpit
Overview, 6
Cold-start lever (choke)
Position, 12
EEmergency off (kill) switch for ignition, 13
Engine oil, 23 Oil filler neck, 4, 23
Engine oil level sight glass, 4
Engine oil pressure Telltale light, 62
FFlashing turn indicator switchLeft, 12
Right, 13
A - F
10Classic1g.book Seite 84 Freitag, 27. Januar 2006 2:01 14

85
Index
i
Front brakeBrake fluid level, 35
Brake lever, 27
Brake-fluid reservoir, 5
Front brakes Brake fluid level, 31
Fuel Octane number, 25
Refuelling, 24
Fuel filler cap, 5
Fuse box, 5
GGear shifts, 64, 65
Gearbox in neutral, 59
General view Left side, 4
Right side, 5
HHandlebar fittingLeft, 12
Right, 13
Handlebar lever Brake lever, 27
Clutch lever, 26
Handlebar levers, 26
Hazard warning flashers, 11
Heated handlebar grips, 11, 13
Hemet holder, 16
High/low (dipped) headlight switch, 12
Horn push, 12 Hydraulic fluid
Clutch, 37
IIgnition switch and steering lock, 6
Function, 8, 9
Installing system cases, 19
Instruments in cockpit, 6
LLights Beam throw, 38
Notes, 38
MMotorcycle equipment, 81
NNeutral (transmission), 59
OOctane number, fuel, 25
Odometer, 6
Oil filler neck, 4, 23
Oil level
Check, 23
Engine oil pressure, 7, 62
Oil level sight glass, 4
Opening system cases, 17
Overheating, 51, 60
F - O
10Classic1g.book Seite 85 Freitag, 27. Januar 2006 2:01 14

86
Index
i
PPartially integral brakes, 70
Power socket, 12 V, 4
RRear brakeBrake-fluid reservoir, 5
Refuelling, 24
Removing system cases, 18
Residual braking, 34
Residual braking function, 71
Revolution counter, 6
Rider ’s equipment, 80
Riding, 64
Rims, 43
Running in, 57
SSafety check, 20
Safety instructions Catalytic converter, 51
General, 50, 51
Seat lock, 4
Service worldwide, 78
Shock absorber, 41
Side stand, 52, 53
Speedometer, 6
Spring preload
Front wheel, 42
Spring strut, 4
Starter pushbutton, 13
Starting, 60
Stowage compartment for toolkit, 5
Switching on ignition, 58
System cases, 17, 18, 19
TTelltale and warning lights ABS, 7, 63
Battery charge current, 7, 63
Engine oil pressure, 7, 62
Fuel level, 7, 62
High-beam headlight, 7
Neutral, 7
Turn indicator, left, 7
Turn indicator, right, 7
Toolkit, 5
Tools, 5
Tread depth, tyres, 43
Trip meter, 6
Troubleshooting chart, 75
Troubleshooting, ABS, 75
Turn indicator cancel switch, 13
Turn indicators Telltale lights, 7
Type plate, 5
Tyres
Running in, 57
Tyre pressures, 44
VValve caps, 44
WWarning, 7
