2003 BMW MOTORRAD R 850 R Rider's Manual (in English)

71
Starting - Riding - Parking
3
Brake system - with BMW Integral ABS2(
RESIDUAL BRAKING
FUNCTION
If the BMW Integral ABS devel-
ops a fault, a RESIDUAL BRAK-
ING FUNCTION only is available
in the brake circuits in question.
The RESIDUAL BRAKING
FUNCTION is the braking effi-
ciency without the hydraulic
servo assistance of the BMW
Integral ABS.
Under these circumstances,
therefore, you must apply CON-
SIDERABLY higher pressure to
the brake levers in question in
order to apply the brakes, and
lever travel is longer.
When the RESIDUAL BRAKING
FUNCTION is active, the ABS
function is unavailable in the
brake system in question.
When the RESIDUAL BRAKING
FUNCTION is active, the inte-
gral braking function is partially
or entirely unavailable.
d Warning:
When the RESIDUAL BRAK-
ING FUNCTION is active,
maintain a defensive riding
style and proceed immediate-
ly to the nearest specialist
workshop, preferably an au-
\f Note:
When the RESIDUAL BRAKING
FUNCTION is active at the front
wheel, it is advisable to set ad-
juster A of the front-brake lever
to position 4 (
b 27).
The RESIDUAL BRAKING
FUNCTION is active under the
following circumstances:
– Ignition off
– Before and during self-diag-
nosis (
b 72)
– Fault in the BMW
Integral ABS (
b 75)
\f Note:
When the RESIDUAL BRAKING
FUNCTION is active for both
brake circuits, the noise of the
pump is no longer audible when
you operate the brake levers.
2(Optional extra
10Classic1g.book Seite 71 Freitag, 27. Januar 2006 2:01 14

72
Starting - Riding - Parking
3
Self-diagnosis with pull-
away test
The BMW Integral ABS per-
forms self-diagnosis and a
pull-away test to ensure its
operability.
Self-diagnosis is performed
automatically when you switch
on the ignition.
d Warning:
Self-diagnosis is not per-
formed unless both brake le-
vers are in their fully released
positions.
Only the RESIDUAL BRAKING
FUNCTION is available until
self-diagnosis is completed
(b 71).
Release the brake levers, if
necessary
 Switch on the ignition
Initially:
– ABS warning light 2:
Flashes at 4 Hz
– General warning light 1:
ON
bSelf-diagnosis is in
progress
Then:
– ABS warning light 2:
Flashes at 1 Hz
– General warning light 1:
OFF
bSelf-diagnosis successfully
completed
2(Optional extra
Brake system - with BMW Integral ABS2(
12
10Classic1g.book Seite 72 Freitag, 27. Januar 2006 2:01 14

73
Starting - Riding - Parking
3
Start the engine.
 Move off
– ABS warning light 2:
OFF (as of approx. 5 km/h
road speed)
bPull-away test successfully
completed
bBMW Integral ABS is
available
\f Note:
Starting on gradients:
Always switch on the ignition
with gear engaged, clutch lever
released and both brake levers
released.
Self-diagnosis cannot be per-
formed if you do not follow this
procedure.
When self-diagnosis com-
pletes, apply the brakes, disen-
gage the clutch, and start the
engine.
\f Note:
Flashing at 1 Hz = 1 flash per
second (slow flashing)
Flashing at 4 Hz = 4 flashes per
second (fast flashing)
2(Optional extra
12
Brake system - with BMW Integral ABS
2(
10Classic1g.book Seite 73 Freitag, 27. Januar 2006 2:01 14

74
Starting - Riding - Parking
3
d Warning:
If the BMW Integral ABS fails
in both brake circuits, a
RESIDUAL BRAKING FUNC-
TION only is available. (b 71)
d Warning:
If the RESIDUAL BRAKING
FUNCTION (
b 71) is active,
maintain a defensive riding
style and proceed immediate-
ly to a specialist workshop,
preferably an authorised
BMW motorcycle dealer.
2(Optional extra
d Warning:
If there is a fault in the ABS
system, the reserves of safety
normally afforded by ABS are
not available until the defect
has been put right.
There is a risk of dropping the
motorcycle if the brakes are
applied too hard and the
w h ee ls l o ck o r th e r e ar w h ee l
lifts clear of the ground as a
result of a high level of tyre
adhesion. Have the defect
rectified immediately by a
specialist workshop, prefera-
bly an authorised
BMW motorcycle dealer.
Brake system - with BMW Integral ABS2(
10Classic1g.book Seite 74 Freitag, 27. Januar 2006 2:01 14

75
Starting - Riding - Parking
3
2(Optional extra
Warning light,
generaleABS warning
light
\b Malfunctions
OFF ON Only RESIDUAL BRAKING FUNCTION available in both circuits (
b 71)
OFF Flashing at 1 HzABS not available
Pull-away test not completed (
b 72)
OFF Flashing at 4 HzOnly RESIDUAL BRAKING FUNCTION
available in both circuits (
b 71)
Self-diagnosis not completed (b 72)
ON OFF Rear light/brake light defective (b Maintenance Instructions, Chapter 2)
ON Flashing at 1 HzAt least one brake circuit without
ABS (
b 70)
ON Flashing at 4 HzAt least one brake circuit in RESIDUAL
BRAKING FUNCTION mode (
b 71)
Alternate
flashing at
1 Hz Alternate
flashing at
1 HzFluid level in BMW Integral ABS too low.
Check the motorcycle as follows:
Ignition OFF: is brake pressure OK at the
brake levers?
Are the brakes acting on both wheels?
Is the brake system leaktight, no signs of
brake fluid escaping?
The brake system is defective if the test
outcome is negative.
Alternate
flashing at
4 Hz Alternate
flashing at
4 HzFluid level in the BMW Integral ABS is too
low, perform the checks listed above.
Only RESIDUAL BRAKING FUNCTION
available in at least one circuit (
b 71)
d Warning:Do not ride the motorcycle if you have
any doubts about the dependability of
the brake system.
BMW Integral ABS2( - Troubleshooting chart
10Classic1g.book Seite 75 Freitag, 27. Januar 2006 2:01 14

76
Arrive safely
4
Know how…In recent years, motorcycles ’
technical design features have
become more and more
sophisticated.
Motronic, electronic ignition,
integral brakes, the catalytic
converter or the use of four
valves per cylinder are clear
signs that far more than basic
technical knowledge may be
needed to solve certain prob-
lems. In addition, high-tech
materials are increasingly tak-
ing the place of conventional
ones, which again calls for thor-
ough and expert knowledge if
they are to be handled correctly
during repair work.
To be sure of achieving the nec-
essary standard, it is always
advisable to consult your
authorised BMW motorcycle
dealer. The authorised BMW motorcy-
cle dealer employs staff who
attends regular and compre-
hensive training courses.
Authorised BMW motorcycle
dealers also receive all the cur-
rent technical information and
are therefore fully aware of the
latest developments.
…
technical features …The authorised BMW motorcy-
cle dealer’s staff has the experi-
ence and all the necessary
facts at its disposal when it
comes to solving problems
quickly and effectively. Work-
shops are equipped with the
latest technical facilities, for
example the special tools
developed by BMW, such as
the BMW diagnostic system
and exhaust emissions tester.
Reliability
10Classic1g.book Seite 76 Freitag, 27. Januar 2006 2:01 14

77
Arrive safely
4
Regular visits to the workshop
for routine servicing are
strongly recommended even
after the warranty period has
elapsed. They are the only way
to be genuinely certain that your
BMW motorcycle is being kept
in perfect working order.
For generous treatment of
claims submitted after the war-
ranty period has expired, evi-
dence of regular maintenance
by an authorised BMW motor-
cycle dealer is essential.
Certain signs of wear may not
otherwise be noticed until it is
too late to put them right at
moderate cost. The staff in the authorised BMW
motorcycle dealer
’s workshop
know every detail of your motor-
cycle and can take remedial
action if necessary before minor
faults develop into serious prob-
lems. By having the necessary
repairs done properly and in good
time, you save time and money in
the long run.
… serviceYou can obtain accurate advice
in all cases, and make appoint-
ments with a firm completion
deadline which we will comply
with punctually. But the most
gratifying feeling of all is that
your BMW is in genuinely good
shape when it leaves the author-
ised BMW motorcycle dealer ’s
workshop – and above all, safe.
Reliability
10Classic1g.book Seite 77 Freitag, 27. Januar 2006 2:01 14

78
Arrive safely
4
Service worldwide
BMW Service CardA Service Card is available for
all new BMW motorcycles.
A wide range of emergency-
assistance services are in place
to help you in the unlikely event
of a problem occurring some-
where far from home.
If you have a breakdown any-
where in Europe, just call our
Central Emergency Service
number from any telephone.
Our experts are on duty there
day and night to arrange assist-
ance for you. They can provide
practical advice on what to do
next and can make arrange-
ments on your behalf, for exam-
ple notifying local emergency
services anywhere in Europe,
arranging recovery and trans-
portation of the motorcycle to
the nearest authorised BMW
motorcycle dealer, a taxi for
you, and even a replacement
vehicle and hotel accommoda-
tion, if necessary.
BMW Service worldwideAnd if your travels take you
even further afield, you have
no need to worry: we are
represented in more than
100 countries of the world.
\f Note:
Call us if you have an y qu estion s
about the BMW dealership net-
work. You can contact us from
any European country on a tele-
phone hotline. The phone num-
bers are listed in the "Service
Kontakt / Service Contact"
booklet (see on-board documen-
tation). Or if you prefer you can
use the homepage address to
contact us on the Internet.
