PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00696
Adjusting the brake lever
free playThe brake lever free play should
measure 2–5 mm as shown.
Periodically check the brake lever
free play and, if necessary, adjust it
as follows.
1. Loosen the locknut at the brake
lever.
2. To increase the brake lever free
play, turn the adjusting bolt in
direction a. To decrease the
brake lever free play, turn the
adjusting bolt in direction b.
3. Tighten the locknut.
EW000099
w8After adjusting the brake lever
free play, check the free play
and make sure that the brake
is working properly.
8A soft or spongy feeling in the
brake lever can indicate the
presence of air in the
hydraulic system. If there is air
in the hydraulic system, have
a Yamaha dealer bleed the
system before operating the
motorcycle. Air in the
hydraulic system will diminish
the braking performance,
which may result in loss of
control and an accident.
1
2b
c
a
1. Locknut
2. Adjusting bolt
c. Free play
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 56
Page 58 of 94
6-22
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00712
Adjusting the brake pedal
positionThe top of the brake pedal should be
positioned approximately 23 mm
below the top of the footrest as
shown. Periodically check the brake
pedal position and, if necessary,
have a Yamaha dealer adjust it.
EW000109
wA soft or spongy feeling in the
brake pedal can indicate the pres-
ence of air in the hydraulic system.
If there is air in the hydraulic sys-
tem, have a Yamaha dealer bleed
the system before operating the
motorcycle. Air in the hydraulic
system will diminish the braking
performance, which may result in
loss of control and an accident.
EAU00713
Adjusting the rear brake light
switchThe rear brake light switch, which is
activated by the brake pedal, is prop-
erly adjusted when the brake light
comes on just before braking takes
effect. If necessary, adjust the brake
light switch as follows.
Turn the adjusting nut while holding
the rear brake light switch in place.
To make the brake light come on ear-
lier, turn the adjusting nut in direction
a. To make the brake light come on
later, turn the adjusting nut in direc-
tion b.
a
1
b
a12
1. Footrest
a. Brake pedal position1. Rear brake light switch
2. Adjusting nut
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 57
Page 59 of 94
6-23
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00721
Checking the front and rear
brake padsThe front and rear brake pads must
be checked for wear at the intervals
specified in the periodic maintenance
and lubrication chart.
EAU00725
Front brake pads
Each front brake pad is provided with
a wear indicator groove, which allows
you to check the brake pad wear
without having to disassemble the
brake. To check the brake pad wear,
check the wear indicator groove. If a
brake pad has worn to the point that
the wear indicator groove has almost
disappeared, have a Yamaha dealer
replace the brake pads as a set.
EAU00728
Rear brake pads
Each rear brake pad is provided with
a wear indicator, which allows you to
check the brake pad wear without
having to disassemble the brake. To
check the brake pad wear, check the
position of the wear indicator while
applying the brake. If a brake pad
has worn to the point that the wear
indicator almost touches the brake
disc, have a Yamaha dealer replace
the brake pads as a set.
1
1
1. Wear indicator groove 1. Wear indicatorREARFRONT
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 58
Page 60 of 94
6-24
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03776
Checking the brake fluid
levelInsufficient brake fluid may allow air
to enter the brake system, possibly
causing it to become ineffective.
Before riding, check that the brake
fluid is above the minimum level mark
and replenish if necessary. A low
brake fluid level may indicate worn
brake pads and/or brake system
leakage. If the brake level is low, be
sure to check the brake pads for
wear and the brake system for leak-
age.Observe these precautions:
8When checking the fluid level,
make sure that the top of the
brake fluid reservoir is level.
8Use only the recommended qual-
ity brake fluid, otherwise the rub-
ber seals may deteriorate, caus-
ing leakage and poor braking
performance.8Refill with the same type of brake
fluid. Mixing fluids may result in a
harmful chemical reaction and
lead to poor braking perfor-
mance.
8Be careful that water does not
enter the brake fluid reservoir
when refilling. Water will signifi-
cantly lower the boiling point of
the fluid and may result in vapor
lock.
8Brake fluid may deteriorate paint-
ed surfaces or plastic parts.
Always clean up spilled fluid
immediately.
8As the brake pads wear, it is nor-
mal for the brake fluid level to
gradually go down. However, if
the brake fluid level goes down
suddenly, have a Yamaha dealer
check the cause.
1
LOWER
1
LOWERUPPER
1. Minimum level mark 1. Minimum level mark
Recommended brake fluid:
DOT 4
FRONT
REAR
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 59
Page 61 of 94
6-25
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03976
Changing the brake fluidHave a Yamaha dealer change the
brake fluid at the intervals specified in
the NOTE after the periodic mainte-
nance and lubrication chart. In addi-
tion, have the oil seals of the master
cylinders and calipers as well as the
brake hoses replaced at the intervals
listed below or whenever they are
damaged or leaking.
8Oil seals: Replace every two
years.
8Brake hoses: Replace every four
years.
EAU00744
Drive chain slackThe drive chain slack should be
checked before each ride and adjust-
ed if necessary.
To check the drive chain slack
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:
When checking and adjusting the
drive chain slack, the motorcycle
should be positioned straight up and
there should be no weight on it.
2. Shift the transmission into the
neutral position.
3. Move the rear wheel by pushing
the motorcycle to locate the tight-
est portion of the drive chain,
and then measure the drive
chain slack as shown.
4. If the drive chain slack is incor-
rect, adjust it as follows.
a
a. Drive chain slack
Drive chain slack:
25–40 mm
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 60
Page 62 of 94
6-26
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03752
To adjust the drive chain slack
1. Loosen the axle nut, then loosen
the locknut at each end of the
swingarm.
2. To tighten the drive chain, turn
the adjusting nut at each end of
the swingarm in direction a. To
loosen the drive chain, turn the
adjusting nut at each end of the
swingarm in direction b, and
then push the rear wheel for-
ward.
NOTE:
Using the alignment marks on each
side of the swingarm, make sure that
both adjusting nuts are in the same
position for proper wheel alignment.
EC000096
cCImproper drive chain slack will
overload the engine as well as
other vital parts of the motorcycle
and can lead to chain slippage or
breakage. To prevent this from
occurring, keep the drive chain
slack within the specified limits.3. Tighten the locknuts, and then
tighten the axle nut to the speci-
fied torque.
EAU03006
Lubricating the drive chainThe drive chain must be cleaned and
lubricated at the intervals specified in
the periodic maintenance and lubrica-
tion chart, otherwise it will quickly
wear out, especially when riding in
dusty or wet areas. Service the drive
chain as follows.
EC000097
cCThe drive chain must be lubricated
after washing the motorcycle or
riding in the rain.1. Clean the drive chain with
kerosene and a small soft brush.
ECA00053
cCTo prevent damaging the O-rings,
do not clean the drive chain with
steam cleaners, high-pressure
washers or inappropriate solvents.
1
4
2
3
a
b1. Axle nut
2. Locknut
3. Adjusting nut
4. Alignment marks
Tightening torque:
Axle nut:
104 Nm (10.4 m0kgf)
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 61
Page 63 of 94
6-27
PERIODIC MAINTENANCE AND MINOR REPAIR
62. Wipe the drive chain dry.
3. Thoroughly lubricate the drive
chain with a special O-ring chain
lubricant.
ECA00052
cCDo not use engine oil or any other
lubricants for the drive chain, as
they may contain substances that
could damage the O-rings.
EAU02962
Checking and lubricating the
cablesThe operation of all control cables
and the condition of the cables
should be checked before each ride,
and the cables and cable ends
should be lubricated if necessary. If
a cable is damaged or does not move
smoothly, have a Yamaha dealer
check or replace it.
EW000112
wDamage to the outer sheath may
interfere with proper cable opera-
tion and will cause the inner cable
to rust. Replace a damaged cable
as soon as possible to prevent
unsafe conditions.
Recommended lubricant:
Engine oil
5AE-28199-E5 honbun 7/6/01 10:18 AM Page 62
Page 64 of 94
6-28
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU04034
Checking and lubricating the
throttle grip and cableThrottle grip and cable, checking and lubricatingThe operation of the throttle grip
should be checked before each ride.
In addition, the cable should be lubri-
cated or replaced at the intervals
specified in the periodic maintenance
chart.
EAU00774
Adjusting the Autolube
pumpThe Autolube pump is a vital and
sophisticated component of the
engine, which must be adjusted by a
Yamaha dealer at the intervals speci-
fied in the periodic maintenance and
