2002 TOYOTA CAMRY Navigation Manual

Camry_Navi_U (L/O 0108)
22002 MY CAMRY NAVI_U (OM33559U)
L00004
You can adjust the angle of the dis-
play by pushing the
“TILT” button.
Each push of the
“TILT” button will
tilt the display to position 1, 2, 3 and
then back to 0 in that order.
If you turn the ignition switch off, the dis-
play will automatically move back to position
0. The display will automatically resume the
previous position you used when the ignition
switch is turned to the “ACC” or “ON” posi-
tion.
CAUTION
Take care not to jam your fingers
while the display is moving. Other-
wise, you could be injured.
NOTICE
Do not obstruct th e display while it
is tilting. It could damage your navi-
gation system.
The navigation system is operated by
switches on the screen and the but-
tons located on the front face around
the screen. When you touch a switch
or push a button, a beep sounds.
When using the switches on the touch
screen, please use only light pressure
with your finger to protect the screen
from damage. Do not use objects other
than your finger to touch the screen.
L00013
To type in an address etc., directly touch
alphabet keys on the screen. If you touch
a wrong letter, dele te it using the
switch. Touching the switch erases
one letter.
Your navigation system Inputting letters and numbers

Camry_Navi_U (L/O 0108)
32002 MY CAMRY NAVI_U (OM33559U)
Touching the “List” switch will change
the screen to a display of the database
items that match the name or address
that you have entered on the screen. The
number of matching items is shown to
the right side of the screen. If the match-
ing item is more than 9,999, the system
displays
“” on the screen.
To input numerals, touch the
“0–9”
switch and the display will change the
screen to number input display.
L00014
Touching the “A–Z” switch changes the
screen back to the previous name input
display.
L00015
When a list is displayed, you can scroll
or page through the list by using the
appropriate switch.
To shift to the next or previous
page.
To scroll up or down one item
at a time.
This expresses a displayed
screen position.
If appears to the right of the
item name, the complete name
is too long for the display.
To u c h , and the name will
scroll to the end of the name.
Touching will scroll the
name to the beginning of the
name.

Camry_Navi_U (L/O 0108)
42002 MY CAMRY NAVI_U (OM33559U)
L00016
1. Touch the “Adjust” switch to move the cursor .
How to move the cursor

Camry_Navi_U (L/O 0108)
52002 MY CAMRY NAVI_U (OM33559U)
L00017
Position locating screen on the map
2. When you touch an arrow facing your desired point, the map scrolls in that direction. When you release your finger,
scrolling stops.
3. If you touch the
“Enter” switch, the position of cursor is set.

Camry_Navi_U (L/O 0108)
62002 MY CAMRY NAVI_U (OM33559U)
Touch the “DEST” tab on the screen
and the “Destination” screen appears.
L00018
The “Destination” screen allows you to
select the area to search for your des-
tination.
Touch the
“Change” switch on the
“Destination” screen to display a map
of the United States and Canada divid-
ed into 11 areas. See page 62 for map
database information and updates.
L00019
Touch one of the “US1” through
“CAN” switches to select a search
area. Touch the
“OK” switch and the
“Destination” screen returns.
Once you choose the area to search, you
can use one of 11 different methods to
enter your destination. USA
SwitchStates included in the search
area
US1Idaho
Oregon
Washington
US2California
Nevada
US3
Arizona
Colorado
Montana
New Mexico
Utah
Wyoming
US4
Iowa
Kansas
Minnesota
Missouri
Nebraska
North Dakota
South Dakota
US5Oklahoma
Te x a s
US6
Illinois
Indiana
Kentucky
Michigan
Ohio
Wisconsin
Destination input

Camry_Navi_U (L/O 0108)
72002 MY CAMRY NAVI_U (OM33559U)
US7
Alabama
Arkansas
Louisiana
Mississippi
Tennessee
US8
Connecticut
Maine
Massachusetts
New Hampshire
New Jersey
New York
Rhode Island
Vermont
US9
Delaware
Maryland
New Jersey
Pennsylvania
Virginia
West Virginia
US10
Florida
Georgia
North Carolina
South Carolina
Canada
SwitchProvinces and regions included
in the search area
CAN
Alberta
British Columbia
Manitoba
New Brunswick
Newfoundland and Labrac
Nova Scotia
Ontario
Prince Edward Island
Québec
Saskatchewan
You can find your destination using vari-
ous methods. See page 10 through 24
for the detailed steps.
1. By Home (
switch on the “Destination” screen): You can select your own home without entering the address each time.
In this case, it is necessary to register your home beforehand. See page 10 for the detailed steps.
2. By Preset Destination (
— switches on the “Destination” screen): You can select one of 5 preset destinations
directly. In this case, it is necessary to register the destinations beforehand. See page 11 for the detailed steps.
3. By Address: You can input the house number and th e street address by using the input keys. See page 11 for the detailed
steps.

Camry_Navi_U (L/O 0108)
82002 MY CAMRY NAVI_U (OM33559U)
4. By POI: You can select one of the many points of interest that ha ve been already stored in the system’s database. There are
more than 50 categories to choose from, including restaurants, banks and automotive locations. See page 14 for the detailed
steps.

Camry_Navi_U (L/O 0108)
92002 MY CAMRY NAVI_U (OM33559U)
5. By Marked Point: You can register your own favorite destinations as a “Marked Point”. The system allows you to store up 100
marked points. See page 19 for the detailed steps.
6. By Previous Destination: You can select a destination from any of the last 20 previously set destinations. See page 20 for
the detailed steps.
7. By Emergency: You can select one of the three points of emergency service points that have been already stored in the system’s
database. See page 21 for the detailed steps.
8. By Intersection: You can enter the names of two intersec ting streets. This is helpful if you do not know the specific street
address of your destination but know the general vicinity. See page 22 for the detailed steps.
9. By Freeway Entrance/Exit: You can enter the name of the freeway (interstate) entrance or exit. See page 23 for the detailed
steps.
10. By Previous Starting Point: You can enter a point where the system has started to guide last time. See page 24 for the detailed
steps.
