2002 SUBARU IMPREZA WRX wheel

In case of emergency
9-17
– CONTINUED –
1. Take out the towing eye, screwdriver and wheel
nut wrench from the on board tool bag.
2. Pry off the cover on the front bumper using a
screwdriver, and you will find a threaded hole for at-
taching the towing eye.
3. Screw the towing eye into the threaded hole until
its thread can no longer be seen.
4. Tighten the towing eye securely with a wheel nut
wrench.
After towing, remove the towing eye from the vehicle
and stow it in the tool bag. Put the threaded hole
cover on the front bumper.
WARNING
Do not use the towing eye except when tow-
ing your vehicle. Be sure to remove the towing eye after tow-
ing. Leaving the towing eye mounted on the
vehicle could interfere with proper operationof the SRS airbag system in a frontal collision. Rear towing eye:
HG9004CA
CAUTION
Do not apply excessive lateral load to the tow- ing eyes.

In case of emergency
9-19
– CONTINUED –
3. Secure the vehicle onto the carrier properly with safety chains. Each of safety chain should be
equally tightened and care must be taken not to pull
the chains so tightly that the suspension bottomsout.
CAUTION
If your vehicle has a front underspoiler and rear underspoiler (both optional), be carefulnot to scrape them when placing the vehicleon the carrier and when removing the vehicle
from the carrier.
Towing with all wheels on the ground
HG9001AA
1. Check the transmission and differential oil levels
and add oil to bring it to the upper level if necessary.
2. Release the parking brake and put the transmis-sion in neutral.
3. The ignition switch should be in the “ACC” posi-
tion while the vehicle is being towed.
4. Take up slack in the towline slowly to prevent
damage to the vehicle.
WARNING
Never turn the ignition switch to the “LOCK”
position while the vehicle is being towed be-
cause the steering wheel and the direction ofthe wheels will be locked. Remember that the brake booster and pow-
er steering do not function when the engine is not running. Because the engine is turned off,
it will take greater effort to operate the brakepedal and steering wheel.

In case of emergency
9-20
CAUTION
If transmission failure occurs, transport
your vehicle on a flat-bed truck. Do not run the engine while being towed in
this method. Transmission damage could re- sult if the vehicle is towed with engine run-ning. For vehicles with automatic transmission,
the traveling speed must be limited to less than 20 mph (30 km/h) and the traveling dis- tance to less than 31 miles (50 km). Forgreater speeds and distances, transport your
vehicle on a flat-bed truck. Maintenance tools
HG9010AA
Your vehicle is equipped with the following mainte-
nance tools:
Wheel cover remover (vehicles with wheel covers)
Screwdriver
Towing eye
Wheel nut wrench

10
10-1
– CONTINUED –
Exterior care 10-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washing 10-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Waxing and polishing 10-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning aluminum wheels 10-3 . . . . . . . . . . . . . . . . . . . . . .
Corrosion protection 10-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Most common causes of corrosion 10-4 . . . . . . . . . . . .
To help prevent corrosion 10-4 . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the interior 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat fabric 10-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leather seat materials 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Synthetic leather upholstery 10-6 . . . . . . . . . . . . . . . . . . . .
Appearance care

Appearance care
10-3
– CONTINUED –
If a stain will not come out easily, wash by hand.
Some warm water washers are of the high tempera-
ture, high pressure type, and they can damage or
deform the resin parts such as mouldings, or causewater to leak into the vehicle. Waxing and polishing
Always wash and dry the vehicle before waxing and polishing. Use a good quality polish and wax and apply them
according to the manufacturer ’s instructions. Wax or
polish when the painted surface is cool.
Be sure to polish and wax the chrome trim, as well
as the painted surfaces. Loss of wax on a painted
surface leads to loss of the original luster and also
quickens the deterioration of the surface. It is rec-
ommended that a coat of wax be applied at least
once a month, or whenever the surface no longer re-
pels water. If the appearance of the paint has diminished to the
point where the luster or tone cannot be restored,
lightly polish the surface with a fine-grained com-
pound. Never polish just the affected area, but in-
clude the surrounding area as well. Always polish in
only one direction. A No. 2000 grain compound is
recommended. Never use a coarse-grained com- pound. Coarser grained compounds have a smaller grain-size number and could damage the paint. Af-
ter polishing with a compound, coat with wax to re-
store the original luster. Frequent polishing with a
compound or an incorrect polishing technique will
result in removing the paint layer and exposing the
undercoat. When in doubt, it is always best to con- tact your SUBARU dealer or an auto paint specialist.
Cleaning aluminum wheels
Promptly wipe the aluminum wheels clean of any
kind of grime or agent. If dirt is left on too long, it
may be difficult to clean off. Do not use soap containing grit to clean the
wheels. Be sure to use a neutral cleaning agent, and
later rinse thoroughly with water. Do not clean the
wheels with a stiff brush or expose them to a high-speed washing device. Clean the vehicle (including the aluminum wheels)
with water as soon as possible when it has been
splashed with sea water, exposed to sea breezes, or
driven on roads treated with salt or other agents.

11
11-1
– CONTINUED –
Maintenance schedule 11-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 11-3 . . . . . . . . . . . . . . . . . . . . . . . .
Engine hood 11-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 11-7 . . . . . . . . . . . . . . . . .
2.5 liter model 11-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.0 liter (Turbo) model 11-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 11-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-10 . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-11 . . . . . . . . . . .
Recommended grade and viscosity under
severe driving conditions 11-13 . . . . . . . . . . . . . . . . . . . . . .
Cooling system 11-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hose and connections 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the air cleaner element 11-18 . . . . . . . . . . . . . .
Spark plugs 11-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended spark plugs 11-21 . . . . . . . . . . . . . . . . . . . . .
Drive belts 11-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-24 . . . . . . . . . . .
Automatic transmission fluid 11-24 . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-24 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (AT vehicles) 11-26 . . . . . Checking the oil level 11-26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-26 . . . . . . . . . . .
Rear differential gear oil 11-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the gear oil level 11-27 . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-28 . . . . . . . . . . .
Power steering fluid 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended brake fluid 11-31 . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (MT vehicles) 11-31 . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended clutch fluid 11-32 . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the brake pedal free play 11-33 . . . . . . . . . . . .
Checking the brake pedal reserve distance 11-34 . .
Clutch pedal (MT vehicles) 11-34 . . . . . . . . . . . . . . . . . . . . . .
Checking the clutch function 11-34 . . . . . . . . . . . . . . . . . . . .
Checking the clutch pedal free play 11-35 . . . . . . . . . . .
Replacement of brake pad and lining 11-35 . . . . . . . .
Breaking-in of new brake pads and linings 11-36 . . .
Parking brake stroke 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire inspection 11-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressures and wear 11-38 . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and service

Maintenance and service
11-2
Wheel balance 11-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wear indicators 11-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 11-42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire replacement 11-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel replacement 11-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel covers 11-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (If equipped) 11-45 . . . . . . . . . . . . . . . .
Windshield washer fluid 11-46 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 11-47 . .
Battery 11-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 11-51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse 11-53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 11-54 . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 11-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-58 . . . . . .
Front fog light (if equipped) 11-61 . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-62 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-63 . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 11-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Room light, spot light and cargo area light 11-66 . . .
Trunk light 11-67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High mount stop light 11-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance and service
11-3
– CONTINUED –
Maintenance schedule
The scheduled maintenance items required to be
serviced at regular intervals are shown in the “War-
ranty and Maintenance Booklet ”.
For details of your maintenance schedule, read theseparate “Warranty and Maintenance Booklet ”.Maintenance precautions
When maintenance and service are required, it is
recommended that all work be done by an autho-
rized SUBARU dealer.
If you perform maintenance and service by yourself,
you should familiarize yourself with the information
provided in this section on general maintenance andservice for your SUBARU.
Incorrect or incomplete service could cause
improper or unsafe vehicle operation. Any problems
caused by improper maintenance and service per-
formed by you are not eligible for warranty cover-age.
WARNING

Testing of an All-Wheel Drive vehicle must
NEVER be performed on a single two-wheel
dynamometer or similar apparatus. Attempt-ing to do so will result in transmission dam-age and in uncontrolled vehicle movement and may cause an accident or injuries to per-
sons nearby. Always select a safe area when performing
maintenance on your vehicle.
