Starting and operating
7-26
running, the parking brake warning light comes on.
After starting the vehicle, be sure that the warning
light has gone out before the vehicle is driven. Referto the “Warning and indicator lights ” section (chap-
ter 3).
When parking your vehicle, always set the parking
brake firmly and put the shift lever in the “1” (1st) for
an upgrade or “R” (Reverse) for a downgrade for
manual transmission vehicles, or in the “P” (Park)
position for automatic transmission vehicles. Always
set the parking brake firmly when parking your ve-
hicle. Never rely on the transmission alone to hold the vehicle.
HG7006AA
When parking on a hill, always turn the steering
wheel. When the vehicle is headed up the hill, the front wheels should be turned away from the curb.
HG7007AA
When facing downhill, the front wheels should be
turned into the curb.
CAUTION
If your vehicle has a front underspoiler and rear underspoiler (both optional), pay atten-tion to blocks and other obstructions on the ground when parking. The underspoilers could be damaged by contact with them.

Driving tips
8-2
New vehicle break-in driving –
the first 1,000 miles (1,600 km)
The performance and long life of your vehicle are
dependent on how you handle and care for your ve-
hicle while it is new. Follow these instructions duringthe first 1,000 miles (1,600 km): Do not race the engine. And do not allow engine
speed to exceed 4,000 rpm except in an emergen-
cy. Do not drive at one constant engine or vehicle
speed for a long time, either fast or slow. Avoid starting suddenly and rapid acceleration,
except in an emergency. Avoid hard braking, except in an emergency.
The same break-in procedures should be applied to
an overhauled engine, newly mounted engine or
when brake pads or brake linings are replaced withnew ones. Fuel economy hints The following suggestions will help to save your fuel.
Select the proper gear position for the speed and
road conditions. Avoid sudden acceleration or deceleration. Al-
ways accelerate gently until you reach the desired
speed. Then try to maintain that speed for as longas possible. Do not pump the accelerator and avoid racing the
engine. Avoid unnecessary engine idling.
Keep the engine properly tuned.
Keep the tires inflated to the correct pressure
shown on the tire placard, which is located under the door latch on the driver ’s side. Low pressure will
increase tire wear and fuel consumption. Use the air conditioner only when necessary.
Keep the front and rear wheels in proper align-
ment. Avoid carrying unnecessary luggage or cargo.

Driving tips
8-6
Driving in foreign countries
When planning to use your vehicle in another coun-
try:Confirm the availability of the correct fuel. (Refer
to the “Fuel requirement ” section in chapter 7.)
Comply with all regulations and requirements of
each country. Driving tips for AWD vehicles
HS0113
All wheel drive distributes the engine power to all
four wheels. AWD vehicles provide better traction
when driving on slippery, wet or snow-covered
roads and when moving out of mud, dirt and sand.
By shifting power between the front and rear wheels,
SUBARU AWD can also provide added traction dur-
ing acceleration and added engine braking force during deceleration.
Therefore, your SUBARU AWD vehicle may handle
differently than an ordinary two wheel drive vehicle
and it contains some features unique to AWD. For safety purposes as well as to avoid damaging the

Driving tips
8-7
– CONTINUED –
AWD system, you should keep the following tips in mind: An AWD vehicle is better able to climb steeper
roads under snowy or slippery conditions than a two
wheel drive vehicle. There is little difference in han-
dling, however, during extremely sharp turns or sud-
den braking. Therefore, when driving down a slope
or turning corners, be sure to reduce your speed
and maintain an ample distance from other vehicles. When replacing a tire, make sure you use only the
same size, construction, brand, and load range as
the original tires listed on the tire placard. Using other
sizes, circumference or construction may result in se-
vere mechanical damage to the drive train of your ve-
hicle and may affect ride, handling, braking,
speedometer/odometer calibration, and clearance
between the body and tires. It also may be danger-
ous and lead to loss of vehicle control. If you use a temporary spare tire to replace a flat
tire, be sure to use the original temporary spare tire
stored in the vehicle. Using other sizes may result in
severe mechanical damage to the drive train of your
vehicle. Always check the cold tire pressure before start-
ing to drive. The recommended tire pressure is pro-
vided on the tire placard, which is located under thedoor latch on the driver ’s side.
Tire chains should always be placed on the front
wheels only. There are some precautions that you must ob-
serve when towing your vehicle. For detail informa-
tion, see the “Towing” section in chapter 8.
WARNING
Always maintain a safe driving speed ac-
cording to the road and weather conditions in order to avoid having an accident on a sharp turn, during sudden braking or under other similar conditions. Always use the utmost care in driving –
overconfidence because you are driving an allwheel drive vehicle could easily lead to a seri-ous accident.

Driving tips
8-8
Off road driving
WARNING
Always maintain a safe driving speed ac-
cording to the road and weather conditions in order to avoid having an accident on a sharpturn, during sudden braking or under othersimilar conditions. Always use the utmost care in driving –
overconfidence because you are driving an allwheel drive vehicle could easily lead to a seri-ous accident.
All AWD models except OUTBACK SPORT
Your AWD vehicle is neither a conventional off-road
vehicle nor an all terrain vehicle. It is a passenger
car designed primarily for on-road use. The AWD
feature gives it some limited off-road capabilities in
situation in which driving surfaces a relatively level,
obstruction-free and otherwise similar to on-road driving conditions. Operating it under other than those conditions could subject the vehicle to exces-
sive stress which might result in damage not eligible for repair under warranty. If you do take your
SUBARU off road, you should review the common
sense precautions in the next section (applicable to
the OUTBACK SPORT) for general guidance. Butplease keep in mind that your vehicle
’s off-road ca-
pabilities are more limited than those of the OUT-
BACK SPORT.
Never attempt to drive through pools and puddles,
or roads flooded with water. Water entering the
engine air intake or the exhaust pipe or water
splashing onto electrical parts may damage your
vehicle and may cause it to stall. OUTBACK SPORT
Because of the AWD feature and higher ground
clearance, your Subaru can be driven on ordinary
roads or off-road. But please keep in mind that an
AWD SUBARU is a passenger car and is neither a
conventional off-road vehicle nor an all-terrain ve-
hicle. If you do take your Subaru off-road, certain
common sense precautions such as the following should be taken: Make certain that you and all of your passengers
are wearing seat belts. Carry some emergency equipment, such as a
towing rope or chain, a shovel, wheel blocks, first

Driving tips
8-9
– CONTINUED –
aid kit and portable phone or citizens band radio. Drive carefully. Do not take unnecessary risks by
driving in dangerous areas or over rough terrain. Slow down and employ extra caution at all times.
When driving off-road, you will not have the benefit
of marked traffic lanes, banked curves, traffic signs and the like. Do not drive across steep slopes. Instead, drive
either straight up or straight down the slopes. A ve-
hicle can much more easily tip over sideways than it
can end over end. Avoid driving straight up or down
slopes that are too steep. Avoid sharp turning maneuvers, especially at
higher speeds. Do not grip the inside or spokes of the steering
wheel. A bad bump could jerk the wheel and injureyour hands. Instead drive with your fingers andthumbs on the outside of the rim. If driving through water, such as when crossing
shallow streams, first check the depth of the water
and the bottom of the stream bed for firmness and
ensure that the bed of the stream is flat. Drive slowly
and completely through the stream. The water
should be shallow enough that it does not reach the
vehicle’ s undercarriage. Water entering the engine
air intake or the exhaust pipe or water splashing
onto electrical parts may damage your vehicle and may cause it to stall. Never attempt to drive through
rushing water; regardless of its depth, it can wash
away the ground from under your tires, resulting in
possible loss of traction and even vehicle rollover.
Always check your brakes for effectiveness im-
mediately after driving in sand, mud or water. Do
this by driving slowly and stepping on the brake
pedal. Repeat that process several times to dry outthe brake discs and brake pads. Do not drive or park over or near flammable mate-
rials such as dry grass or fallen leaves, as they may
burn easily. The exhaust system is very hot while en- gine is running and right after the engine stops. This
could create a fire hazard. After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, pa-
per, rags, stones, sand, etc. adhering to or trapped
on the underbody. Clear off any such matter from
the underbody. If the vehicle is used with these ma-
terials trapped or adhering to the underbody, a
mechanical breakdown or fire could occur. Secure all cargo carried inside the vehicle and
make certain that it is not piled higher than the seat-
backs. During sudden stops or jolts, unsecured car-
go could be thrown around in the vehicle and cause
injury. Do not pile heavy loads on the roof. Thoseloads raise the vehicle ’s center of gravity and make

Driving tips
8-10
it more prone to tip over. If you must rock the vehicle to free it from sand or
mud, depress the accelerator pedal slightly and
move the selector lever back and forth between “D”
and “R” repeatedly. Do not race the engine. For the
best possible traction, avoid spinning the wheels
when trying to free the vehicle.
When the road surface is extremely slippery, you
can obtain better traction by starting the vehicle withthe transmission in 2nd than 1st (both for MT and
AT). Never equip your vehicle with tires larger than
those specified in this manual. Frequent driving of an AWD vehicle under hard-
driving conditions such as rough roads or off roads
will necessitate more frequent replacement of engine
oil, brake fluid and transmission oil than that specified
in the maintenance schedule described in the “War -
ranty and Maintenance Booklet ”.
Remember that damage done to your Subaru while
operating it off-road and not using common sense
precautions such as those listed above is not eligi-ble for warranty coverage. Winter driving
HG8001AA

Operation during cold weather
Carry some emergency equipment, such as tire
chains, a window scraper, a bag of sand, flares, asmall shovel, and jumper cables.
Check the battery and cables. Cold temperatures
reduce battery capacity. The battery must be in
good condition to provide enough power for cold
winter starts.
Use an engine oil of proper grade and viscosity for
cold weather. Heavy summer oil will cause harder
starting.

Driving tips
8-12
WARNING
Snow can trap dangerous exhaust gases under your vehicle. Keep snow clear of the
exhaust pipe and from around your vehicle ifyou park the vehicle in snow with the engine running.
Refueling in cold weather
To help prevent moisture from forming in the fuel
system and the risk of its freezing, use of an anti-
freeze additive in the fuel tank is recommended dur-
ing cold weather.
Use only additives that are specifically designed for
this purpose. When an antifreeze additive is used,
its effect lasts longer if the tank is refilled whenever
the fuel level reaches half empty. If your SUBARU is not going to be used for an ex-
tended period, it is best to have the fuel tank filled to
capacity. Driving on snowy and icy roads
To prevent skidding and slipping, avoid sudden braking, abrupt acceleration, high-speed driving,
and sharp turning when driving on snowy or icy roads.
Always maintain ample distance between your ve-
hicle and the vehicle ahead of you to avoid the needfor sudden braking.
To supplement the foot brake, use the engine brake
effectively to control the vehicle speed. (Shift into a
lower gear when necessary.)
Avoid shifting down abruptly. Such behavior cancause the wheels to lock, possibly leading to loss of
vehicle control.
An anti-lock brake system (ABS) e
nhances your
vehicle’ s braking performance on snowy and icy
roads. Refer to the “ABS (Anti-Lock Brake System) ”
section in chapter 7 for information on braking on
slippery surfaces. NOTE The optional 17-inch tires for the WRX are sum- mer tires. Compared with winter and all-season tires, summer tires give significantly less grip on
snowy and icy road surfaces. Avoid driving onsnowy and icy road surface with summer tires.
