2002 SUBARU IMPREZA WRX audio

Audio
5-22
Dolby B NR button ()
Press “
” button (14) when playing tapes re-
corded using the Dolby NR system*. The “” in-
dicator will light up and high-frequency noise on the
tape will be reduced for clearer sound reproduction.
* Noise reduction system manufactured under license from Dolby Laboratories Licensing Corporation.
“Dolby” and the
double-D Symbol are trade marks of Dolby Laboratories Li-
censing Corporation.
n Auto metal sensor
The cassette player automatically adjusts for metal or CrO 2 tape.
Built in CD changer operation
HS5004DB
(18) LOAD button
(19) SCAN button
(20) Disc slot
(21) CD button
(22) Eject button
(23) Random button
(24) Fast forward/Fast reverse and
track UP/DOWN knob
(25) Repeat button
(26) Disc select button

Audio
5-23
– CONTINUED –
NOTE
Make sure to always insert a disc with the label side up. If a disc is inserted with the label sidedown, it might be ejected or the player mightshut off.
How to insert a CD(s)
n Inserting a CD
1. Press “LOAD” button (18). If the magazine in the
player has an idle position where you can insert adisc, the “DISC” indicator associated with the idle
position will blink.
If no indicator blinks, it means that there is no idleposition in the magazine.
2. As soon as the “DISC” indicator begins to blink,
the “IN” will appear on display for a period of 15 se-
conds. Insert a disc during the period. The disc will be then automatically drawn in, and the player willbegin to play back the first number of the disc. To insert more discs in succession, repeat Steps 1
and 2. The magazine will be loaded with discs in the
ascending order of position number.
If you do not insert any disc in 15 seconds after you
have pressed the “LOAD” button, the player will be-
gin to play back the first number of the last disc you
have inserted.
The disc indicator steadily lights up if a disc is al-
ready inserted in the corresponding position of themagazine. While the player is in the loading mode, if you
press any of the other mode buttons “FM” (2), “AM”
(1)
and “TAPE” (12), the player will enter the stand-
by mode. Press the “CD” button (21) to start play-
back.
n Inserting a disc in a desired position
1. Press the “LOAD” button. If the magazine in the
player has an idle position where you can insert adisc, the “DISC” indicator associated with the idle
position will blink.
The positions in the magazine the indicator of which
steadily lights up are already loaded with discs.
2. Press the “DISC SELECT ” button (26) at the posi-
tion where you want to insert a disc. The associated
“DISC” indicator will blink, and the “IN” will be dis-
played.
3. If you insert a disc during the 15-second periodwhile the “IN” is on display, the disc will be automati-
cally drawn in, and the player will start playback of
the disc, beginning with the first number. To insert more discs in succession, repeat Steps 1
and 2. While the player is in the loading mode, if you

Audio
5-24
press any of the other mode buttons “FM” (2), “AM”
(1) and “TAPE” (12), the player will enter standby
mode. Press the “CD” button to start playback.
n Loading all the magazine (Full disc loading mode)
1. If you continue to press the “LOAD” button for
more than 1.5 seconds, the player will produce beep sound and will enter the full disc loading mode.
2. A “DISC” indicator will blink, and the “IN” will be
on display for a period of 15 seconds. If a disc issuccessfully loaded during this period, the “DISC”
indicator will stop blinking and will steadily light.
3. When the loading of a disc is complete, the next
“DISC” indicator will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeat-
ing Steps 2 and 3, the player will start playback of
the discs, beginning with the one inserted first.
If you fail to insert any disc during each 15-second interval, the full disc loading mode will be canceled,
and the player will start playback of the disc in-
serted first.
How to play back a CD or make a pause
n When there is no CD inserted:
Insert a CD by referring to “How to Insert a CD(s) ”.When a CD is loaded, the player will start playback
of the CD, beginning with the first number.
n When there are CDs loaded:
Press a desired one of the “DISC SELECT ” buttons
(26) the “DISC” indicator of which steadily lights up.
The player will then start playback of the selected
CD, beginning with the first number.
Selecting a desired track (TRACK)
HS5005BA
❚: Skipping forward
❚ : Skipping backward
: Fast forwarding
: Fast reversing

Audio
5-25
– CONTINUED –
nSkipping forward
Turn the “TRACK” knob (24) clockwise and release it
immediately to skip to the beginning of the next
track. Each time the knob is turned and released,
the indicated track number will increase.
n Skipping backward
Turn the “TRACK” knob (24) counterclockwise and
release it immediately to skip to the beginning of the
current track. If you continue to turn and release the
knob, the indicated truck number will decrease.
n Fast forwarding
Turn the “TRACK” knob (24) clockwise and hold it
continuously for more than 2 seconds to fast forwardthe disc.
Release the knob to stop fast forwarding.
n Fast reversing
Turn the “TRACK” knob (24)
counterclockwise and
hold it continuously for more than 2 seconds to fast
reverse the disc.
Release the knob to stop fast reverse.
Repeat playback
Press the “RPT” button (25) while a song is playing
to play the song repeatedly. The “RPT” indicator will
come on and the song will be played continuously. To cancel the repeat mode, press the button again.
Then the
“RPT” indicator goes out, and normal play-
back mode is restored.
Random playback
Press the “RDM” button (23) while a disc is being
played back to play all songs on the disc in a ran-
dom order. The “RDM” indicator will come on and all
songs on the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RDM” indicator goes out, and normal
playback mode is restored.
Scan
When the “SCAN” button (19) is pressed while the
disc is being played back, you can hear the first 10
seconds of each track to search for the desired pro-
gram. To continue listening to the program, pressthe “SCAN” button again. After all tracks on the disc
have been scanned, normal playback mode is re-
stored.
How to unload CDs from the player
n Ejecting a CD from the player
Of the discs loaded, you can select and removeonly one disc.
1. Press the “DISC SELECT ” button (26) of the disc

Audio
5-26
whose “DISC” indicator is ON.
2. Press the “EJECT” button (22). Then the “DISC”
indicator associated with the disc you have selected will blink, and the disc will be ejected.
To remove more discs in succession, repeat Steps 1and 2.
n Ejecting all discs from the player (All discejection mode)
1. If you continue to press the “EJECT” button (22),
the player will produce beep sound and will enterthe all disc ejection mode.
2. Remove the disc that has been ejected. The oth- er discs loaded will then be ejected one after anoth-
er. If you do not remove the disc that has been
ejected, the “All disc ejection mode ” will be can-
celed.
NOTE
Avoid driving the vehicle with a CD sticking out,
because vibration might make it fall out. Precautions to observe when han- dling a compact disc (CD)
To remove a disc from the case, press the center
of the case and hold both edges of the disc. If the
disc surface is touched directly, contamination
could cause poor tone quality. Do not touch the disc
surface. Use a clean disc whenever possible. If there are
deposits, wipe the disc surface from the center out-
ward with a dry, soft cloth. Be sure not to use a hard
cloth, thinner, benzene, alcohol, etc. Never use a badly damaged, deformed or
cracked disc. Malfunctions or problems might result. A disc is vulnerable to heat. Never keep it either in
places exposed to direct sunlight, near heaters or in vehicles parked in the sun or hot days.

Audio
5-27
– CONTINUED –
HG5009BA

Interior equipment
6-7
– CONTINUED –
might burn you or your passengers. Spilled
beverages may also damage upholstery, car-pets or audio equipment. Accessory power socket
In the luggage compartment (if equipped)
CAUTION
Do not attempt to use a cigarette lighter in
the accessory power socket. Do not place any foreign objects, especially
metal ones such as coins or aluminum foil,
into the accessory power socket. That could
cause a short circuit. Always put the cap onthe accessory power socket when they are notin use. Use only electrical appliances which are
designed for 12V DC and which consume less
than 120W. Overloading the accessory power
socket can cause a short circuit. Do not use
double adapters or more than one electricalappliance. If the plug on your electric appliance is
either too loose or too tight for the accessorypower socket, this can result in a poor contactor cause the plug to get stuck. Only use plugs
that fit properly. Use of an electric appliance in the acces-
