2002 SUBARU IMPREZA WRX ESP

Seat, seatbelt and SRS airbags
1-2
Front seats
WARNING
Never adjust the seat while driving to avoid
the possibility of loss of vehicle control and of
personal injury. Before adjusting the seat, make sure the
hands and feet of rear seat passengers areclear of the adjusting mechanism. Seatbelts provide maximum restraint when
the occupant sits well back and upright in the
seat. To reduce the risk of sliding under the
seatbelt in a collision, the front seatbacksshould be always used in the upright position
while the vehicle is running. If the front seat-
backs are not used in the upright position in a
collision, the risk of sliding under the lap belt
and of the lap belt sliding up over the abdo-men will increase, and both can result in seri-ous internal injury or death.
HG1002BA
WARNING
Put children aged 12 and under in the rear seat
properly restrained at all times. The SRS airbag
deploys with considerable speed and force and
can injure or even kill children, especially if
they are 12 years of age and under and are not
restrained or improperly restrained. Because
children are lighter and weaker than adults,
their risk of being injured from deployment is
greater. For that reason, we strongly recom-
mend that ALL children (including those in
child seats and those that have outgrown child
restraint devices) sit in the REAR seat properly
restrained at all times in a child restraint device

Seat, seatbelt and SRS airbags
1-18
nUnfastening the seatbelt
Push the button on the buckle.
HB0303
Before closing the door, make sure that the belts are
retracted properly to avoid catching the belt web-
bing in the door.
Rear center seatbelt on Wagon
WARNING
Fastening the seatbelt with the webbing twisted can increase the risk or severity ofinjury in an accident. When fastening the belt
after it is pulled out from the retractor, espe-
cially when inserting the connector ’s tongue plate into the mating buckle (on right-handside), always check that the webbing is nottwisted.
HB1030BA
WARNING
Be sure to fasten both tongue plates to the
respective buckles. If the seatbelt is used onlyas a shoulder belt (with the connector
’s
tongue plate not fastened to the connector ’s
buckle on the right-hand side), it cannot prop-erly restrain the wearer in position in an acci- dent, possibly resulting in serious injury or death.

Keys and doors
2-4
NOTE
Make sure that you do not leave the key inside the vehicle when locking the doors from the out-
side without the key. Locking and unlocking from the inside
HB2001BC
1) Lock 2) Unlock
To lock the door from the inside, rotate the lock lever
rearward. To unlock the door from the inside, rotate
the lock lever forward.
The red mark on the lock lever appears when the door is unlocked. Pull the inside door handle to open an unlocked
door.
Always make sure that all doors and the rear gate
(wagon) are closed before starting to drive.
WARNING
Keep all doors locked when you drive, espe-
cially when small children are in your vehicle.Along with the proper use of seat belts and child restraints, locking the doors reduces the
chance of being thrown out of the vehicle inan accident.It also helps prevent passengers from fallingout if a door is accidentally opened, and in-
truders from unexpectedly opening doors and entering your vehicle.

Keys and doors
2-6
Keyless entry system (if equipped)
Two transmitters are provided for your vehicle.
The keyless entry system has the following func- tions. Locking and unlocking the doors (and rear gate
on the wagon) without a key Sounding a panic alarm
Arming and disarming the security system (if your
vehicle is equipped with an optional security sys-tem). See the next section “Security system (if
equipped)” for detailed information.
This device complies with Part 15 of the FCC
Rules and with RSS-210 of Industry Canada.Operation is subject to the following twoconditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, includinginterference that may cause undesired opera-tion.
Changes or modifications not expresslyapproved by the party responsible for com-
pliance could void the user ’s authority to
operate the equipment. The operable distance of the keyless entry system is
approximately 30 feet (10 meters). However, this
distance will vary depending on environmental
conditions. Range may be reduced near sources of
RF interference such as power plants and radio/tele-
vision broadcasting towers.
The keyless entry system does not operate when the
key is inserted in the ignition switch.
CAUTION

Do not expose the transmitter to severe
shocks, such as those experienced as a result of dropping or throwing. Do not take the transmitter apart except
when replacing the battery. Do not get the transmitter wet. If it gets wet,
wipe it dry with a cloth immediately.

Instruments and controls
3-9
– CONTINUED –
and high revving operation when engine is not
warmed up enough should be avoided.
CAUTION
If the pointer exceeds the normal operating range, safely stop the vehicle as soon as pos- sible. See the “In case of emergency ” in chapter 9.
Outside temperature indicator (if equipped)
The outside temperature indicator shows the outside
temperature in a range from –22°F to 122 °F ( –30 °C
to 50 °C).
The indicator can give a false reading under any of the following conditions: When there is too much sun.
During idling; while running at low speeds in a
traffic jam; when the engine is restarted immediately
following a shutdown. When the actual outside temperature falls outside
the specified indicator range. Warning and indicator lights
Several of the warning and indicator lights come on
momentarily and then go out when the ignition
switch is initially turned to the
“ON” position. This
permits checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to the “ON” position. The following lights come on:
Seatbelt warning light
SRS airbag system warning light
CHECK ENGINE warning light/Malfunction indica- tor lamp
Charge warning light
Oil pressure warning light
AT OIL temperature warning light (AT vehicles)
ABS warning light
Brake system warning light
If any lights fail to come on, it indicates a burned-out
bulb or a malfunction of the corresponding system.
Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime
When the ignition switch is turned to the “ON” posi-
tion, the seatbelt warning light will come on and the
reminder chime will sound for about six seconds to
remind the driver to fasten the seatbelt.

Instruments and controls
3-12
CAUTION
Do not operate the engine with the oil pres- sure warning light on. This may cause serious engine damage.
AT OIL TEMPerature warning
light (for AT vehicles)
If this light comes on when the engine is running, it may indicate that the automatic transmission fluid
temperature is too hot.
If the light comes on while driving, it is unnecessary
to stop the vehicle, but avoid driving up steep
grades or in stop and go traffic.
Automatic transmission control system warn- ing
If the light flashes after the engine starts, it may indi-
cate that the automatic transmission control system
is not working properly. Contact your nearest
SUBARU dealer for service immediately. ABS warning light
The ABS warning light comes on when the ignition
switch is turned to the “ON” position and goes out after about two seconds.This is an indication that the ABS system is working
properly.
CAUTION
If the warning light behaves as follows, the
ABS system may not work properly. When the warning light is on, the ABS func-
tion shuts down; however, the conventional
brake system continues to operate normally.
The warning light does not come on when
the ignition switch is turned to the “ON” posi-
tion. The warning light comes on when the igni-
tion switch is turned to the “ON” position, but
it does not go out even when the vehiclespeed exceeds approximately 8 mph (12km/h). The warning light comes on during driving.
If these occur, have the ABS system repaired at the first available opportunity by your
SUBARU dealer.
NOTE
If the warning light behavior is as shown below, the ABS system may be considered normal.
(U.S.) (Canada)

Climate control
4-6
2. Set the air flow control dial to the “” position.
3. Turn the temperature control dial all the way to the right.
4. Set the fan speed control dial to the highestspeed.
If your vehicle is equipped with an air conditioner, when the “
” position is selected, the air condi-
tioner automatically operates regardless of the posi-
tion of the air conditioner button. NOTE
Warm air also comes out from the right and left
air outlets. To stop warm air flow from these out- lets, turn the corresponding knob clockwise.
Heating and defrosting
HG4024AA
To direct warm air toward the floor and the wind- shield:
1. Set the air inlet selection lever to the “
”
position.
2. Set the air flow control dial to the “
” position.
3. Set the temperature control dial to the most com-
fortable level.
4. Set the fan speed control dial to the desiredspeed. NOTE
Warm air also comes out from the right and left
air outlets. To stop warm air flow from these out- lets, turn the corresponding knob clockwise.
Heating
HG4025AA

Climate control
4-7
– CONTINUED –
To direct warm air toward the floor:
1. Set the air inlet selection lever to the “”
position
2. Set the air flow control dial to the “
” position.
3. Set the temperature control dial to the most com-
fortable level.
4. Set the fan speed control dial to the desired speed. NOTE
Warm air also comes out from the right and left
air outlets. To stop warm air flow from these out-lets, turn the corresponding knob clockwise.
Bi-level heating
HG4026AA
This setting allows you to direct air of different tem-
peratures from the instrument panel and foot outlets.
The air from the foot outlets is slightly warmer than
from the instrument panel outlets.
1. Set the air inlet selection lever to the “
”
position.
2. Set the air flow control dial to the “
” position.
3. Set the temperature control dial to the desired
temperature level.
4. Set the fan speed control dial to the desiredspeed.
Setting the temperature control dial fully turned to
the red area or blue area decreases the temperature
difference between the air from the instrument panel
outlets and the air from the foot outlets.
