2002 SUBARU IMPREZA WRX oil change

Seat, seatbelt and SRS airbags
1-23
– CONTINUED –
trim during driving, causing damage to the trim.
HG1025BA
Seatbelt maintenance
To clean the seatbelts, use a mild soap and luke-
warm water. Never bleach or dye the belts because
this could seriously affect their strength. Inspect the seatbelts and attachments including the
webbing and all hardware periodically for cracks,
cuts, gashes, tears, damage, loose bolts or worn
areas. Replace the seatbelts even if only minor dam-age is found.
CAUTION
Keep the belts free of polishes, oils, chemi-
cals and particularly battery acid. Never attempt to make modifications or
changes that will prevent the seatbelt from op-
erating properly.

3
3-1
– CONTINUED –
Ignition switch 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LOCK 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ACC 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ON 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
START 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key reminder chime 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key interlock release (AT vehicles only) 3-4 . . . . . .
Hazard warning flasher 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Meters and gauges 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer/Trip meter 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature gauge 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature indicator
(if equipped) 3-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning and indicator lights 3-9 . . . . . . . . . . . . . . . . . . . .
Seatbelt warning light and chime 3-9 . . . . . . . . . . . . . . .
SRS airbag system warning light 3-10 . . . . . . . . . . . . . . .
CHECK ENGINE warning light/ Malfunction indicator lamp 3-10 . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light
(for AT vehicles) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-13 . . . . . . . . . . . . . . . . . . . . .
Door open warning lights 3-13 . . . . . . . . . . . . . . . . . . . . . . . . Front-wheel drive warning light
(for AT vehicles – if equipped) 3-14 . . . . . . . . . . . . . . . .
Shift position indicator (AT vehicles) 3-14 . . . . . . . . . .
Turn signal indicator lights 3-14 . . . . . . . . . . . . . . . . . . . . . .
High beam indicator light 3-14 . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlights 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/low beam change (dimmer) 3-16 . . . . . . . . . . . . . . .
Headlight flasher 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime running light system 3-17 . . . . . . . . . . . . . . . . . . .
Turn signal lever 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-18 . . . . . . . . . . . . . . . .
Parking light switch 3-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-19 . . . . . . . . . . . . . . . . . .
Wiper and washer 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switches 3-21 . . . . . . .
Rear window wiper and washer switch
(if equipped) 3-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 3-24 . . . . . . . . . . . . . . . . . .
Mirrors 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside mirror 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheel 3-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instruments and controls

Maintenance and service
11-10
engine oil level reading may be in a range between the upper level and the notch mark. This is caused
by thermal expansion of the engine oil.
To prevent overfilling the engine oil, do not add any
additional oil above the upper level when the engineis cold. Changing the oil and oil filter
Change the oil and oil filter according to the mainte-
nance schedule in the “Warranty and Maintenance
Booklet”.
The engine oil and oil filter must be changed more
frequently than listed in the maintenance schedule
when driving on dusty roads, when short trips are
frequently made, or when driving in extremely cold
whether.
1. Warm up the engine by letting the engine idle for
about 10 minutes to ease draining the engine oil.
2. Park the vehicle on a level surface and stop the engine.
3. Remove the oil filler cap.
OM-H2283
1) Sealing washer
2) Drain plug
4. Drain out the engine oil by removing the drain
plug while the engine is still warm. The used oil
should be drained into an appropriate container and
disposed of properly.
WARNING
Be careful not to burn yourself with hot en- gine oil.

Maintenance and service
11-45
– CONTINUED –
Installing the wheel cover
HGA013BA
Align the valve with the valve hole in the cover, then fit the cover on the wheel by tapping your hand
evenly around the circumference of the cover. NOTE When any of the wheels is removed and replaced for tire rotation or to change a flat tire, always
check the tightness of the wheel nuts after driv-ing approximately 600 miles (1,000 km). If anynut is loose, tighten it to the specified torque. Aluminum wheels (If equipped)
Aluminum wheels can be scratched and damaged
easily. Handle them carefully to maintain their ap-
pearance, performance, and safety.
When any of the wheels is removed and replaced
for tire rotation or to change a flat, always check the
tightness of the wheel nuts after driving approxi-mately 600 miles (1,000 km). If any nut is loose,
tighten it to the specified torque. Never apply oil to the threaded parts, wheel nuts,
or tapered surface of the wheel. Never let the wheel rub against sharp protrusions
or curbs. Be sure to fit tire chains on uniformly and com-
pletely around the tire, otherwise the chains mayscratch the wheel. When wheel nuts, balance weights, or the center
cap replaced, be sure to replace them with genuine
SUBARU parts designed for aluminum wheels.

Index
14-2
A
ABS (Anti-lock Brake System) 7-22. . . . . . . . . . . . . . . . . . . .
ABS system self-check 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 3-12, 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ACC 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessory power socket 6-7 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner compressor shut-off when
engine is heavily loaded 4-11 . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner operation 4-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air filtration system (if equipped) 4-12 . . . . . . . . . . . . . . . . .
Air flow selection 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
All AWD models except OUTBACK SPORT 8-8 . . .
Aluminum wheels (If equipped) 11-45 . . . . . . . . . . . . . . . . . .
Antenna system 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming the system 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest (if equipped) 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtray 6-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light (for AT vehicles) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio set 5-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic/Emergency Locking Retractor (A/ELR) 1-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission fluid 11-24 . . . . . . . . . . . . . . . . . . . . . . B
Battery
11-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-13 . . . . . . . . . . . . . . . . . . . . . . . .
Braking 7-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking tips 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Breaking-in of new brake pads and linings 11-36 . . .
Built in CD changer operation 5-22 . . . . . . . . . . . . . . . . . . . .
Bulb chart 12-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CCapacities 12-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets (if equipped) 6-14 . . . . . . . .
Cassette player operation 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . .
Catalytic converter 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD changer control (If optional in-dash CD
changer is connected) 5-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Center and side ventilators 4-3 . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center visor 6-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a flat tire 9-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-10 . . . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Index
14-4
Engine12-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 11-7 . . . . . . . . . . . . . . . . . . .
Engine coolant 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust gas (Carbon monoxide) 8-3 . . . . . . .
Engine hood 11-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 11-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine overheating 9-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior care 10-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
F
Fastening the seatbelt 1-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flat tires 9-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat (if equipped) 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FM reception 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-19 . . . . . . . . . . . . . . . . . . . . .
Folding down the rear seat – Wagon 1-9 . . . . . . . . . . . .
Fore and aft adjustment 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (AT vehicles) 11-26 . . . . . . . . . .
Front fog light (if equipped) 11-61 . . . . . . . . . . . . . . . . . . . . . . .
Front seatbelt pretensioners 1-24 . . . . . . . . . . . . . . . . . . . . . . .
Front seats 1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-58 . . . . . . . .
Front-wheel drive warning light
(for AT vehicles – if equipped) 3-14 . . . . . . . . . . . . . . . .
Fuel 7-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel economy hints 8-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel filler lid and cap 7-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel requirements 7-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located behind the coin tray 12-6 . . . . . . .
Fuse panel located in the engine compartment 12-8 .
Fuses 11-51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and circuits 12-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
G
Glove compartment 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR and GAWR (Gross Vehicle Weight
Rating and Gross Axle Weight Rating) 8-17 . . . . .
H
Hazard warning flasher 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight flasher 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlights 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headrest adjustment (if equipped) 1-10 . . . . . . . . . . . . . .
Head restraint adjustment 1-5 . . . . . . . . . . . . . . . . . . . . . . . . .
Heater operation 4-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High beam indicator light 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . .
High/low beam change (dimmer) 3-16 . . . . . . . . . . . . . . . .
High mount stop light 11-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hose and connections 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to jump start 9-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
