2002 SUBARU IMPREZA WRX headrest

1
1-1
– CONTINUED –
Front seats 1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fore and aft adjustment 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining the seatback 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat cushion height adjustment
(driver’ s seat) 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraint adjustment 1-5 . . . . . . . . . . . . . . . . . . . . . . .
Seat heater (if equipped) 1-6 . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats 1-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest (if equipped) 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding down the rear seat – Wagon 1-9 . . . . . . . . . . .
Headrest adjustment (if equipped) 1-10 . . . . . . . . . . . . .
Seatbelts 1-11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt safety tips 1-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Locking Retractor (ELR) 1-12 . . . . . . . . . .
Automatic/Emergency Locking Retractor (A/ELR) 1-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt warning light and chime 1-13 . . . . . . . . . . . . . . .
Fastening the seatbelt 1-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt maintenance 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front seatbelt pretensioners 1-24 . . . . . . . . . . . . . . . . . . . .
System monitors 1-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System servicing 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions against vehicle modification 1-27 . . . . .
Child restraint systems 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing child restraint systems with seatbelt 1-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of child restraint systems by use of lower and tether anchorages 1-32 . . . . . . . . . Top tether anchorages 1-35
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbag
(Supplemental Restraint System airbag) 1-38 .
Vehicle with driver ’s and front passenger ’s
SRS airbags and lap/shoulder restraints 1-38 . . . .
SRS frontal airbag 1-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS side airbag (if equipped) 1-51 . . . . . . . . . . . . . . . . . . .
SRS airbag system monitors 1-59 . . . . . . . . . . . . . . . . . . . .
SRS airbag system servicing 1-60 . . . . . . . . . . . . . . . . . . . .
Precautions against vehicle modification 1-61 . . . . .
Seat, seatbelt and SRS airbags

Seat, seatbelt and SRS airbags
1-10
Secure skis and other lengthy items properly
to prevent them from shooting forward and
causing serious injury during a sudden stop.
HB1022BA
HB1023BA
Unlock the seatback by pulling the release knob and then fold the seatback down. Headrest adjustment (if equipped)
HS1013CA
To raise the headrest, pull it up. To lower it, push the
head rest down while depressing the release buttonon the top of the seatback.

Seat, seatbelt and SRS airbags
1-36
Wagon: There is an anchorage for the center seat-
ing position at the rear end of the ceiling, and
anchorages for each of the two window-side seating
positions on the rear wall of the cargo area.
To hook the top tether
n Sedan
HGS035BB
F: Front of vehicle
1) Top tether hook
2) Upper anchorage
Fasten the top tether hook of the child restraint sys-
tem to the appropriate upper anchorage.
Tighten the top tether securely. n
Wagon
HGS031BA
1. Remove the headrest at the seating position
where the child restraint system has been installed with the seatbelt or lower anchorages; lift up the
headrest while pressing the release button. Store the
headrest in the cargo area. Avoid placing the head-
rest in the passenger compartment to prevent it from
being thrown around in the passenger compartment
in a sudden stop or a sharp turn.

Seat, seatbelt and SRS airbags
1-37
– CONTINUED –
HGS032BB
Center
F: Front of vehicle
1) Top tether hook
2) Upper anchorage
HGS033BB
Window-side
F: Front of vehicle
1) Top tether hook
2) Upper anchorage
2. Fasten the top tether hook of the child restraint
system to the appropriate upper anchorage.
3. Tighten the top tether securely.
CAUTION
Always remove the headrest when mounting a
child restraint system with a top tether. Other- wise, it may happen that the top tether cannot
be fastened tightly.

Appearance care
10-6
wear prematurely. Regular cleaning with a soft,
moist, natural fiber cloth should be performed
monthly, taking care not to soak the leather or allowwater to penetrate the stitched seams.A mild detergent suitable for cleaning woolen fab-
rics may be used to remove difficult dirt spots, rub-
bing with a soft, dry cloth afterwards to restore the
luster. If your SUBARU is to be parked for a long
time in bright sunlight, it is recommended that the
seats and headrests be covered, or the windows
shaded, to prevent fading or shrinkage.
Minor surface blemishes or bald patches may be
treated with a commercial leather spray lacquer. You will discover that each leather seat section will de-
velop soft folds or wrinkles, which is characteristic of
genuine leather. Synthetic leather upholstery
The synthetic leather material used on the SUBARU may be cleaned using mild soap or detergent and
water, after first vacuuming or brushing away loose
dirt. Allow the soap to soak in for a few minutes and
wipe off with a clean, damp cloth. Commercial foam-type cleaners suitable for synthetic leather materials
may be used when necessary. NOTE Strong cleaning agents such as solvents, paint
thinners, window cleaner or gasoline must neverbe used on leather or synthetic interior materials.

Index
14-4
Engine12-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 11-7 . . . . . . . . . . . . . . . . . . .
Engine coolant 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust gas (Carbon monoxide) 8-3 . . . . . . .
Engine hood 11-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 11-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine overheating 9-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior care 10-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
F
Fastening the seatbelt 1-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flat tires 9-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat (if equipped) 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FM reception 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-19 . . . . . . . . . . . . . . . . . . . . .
Folding down the rear seat – Wagon 1-9 . . . . . . . . . . . .
Fore and aft adjustment 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (AT vehicles) 11-26 . . . . . . . . . .
Front fog light (if equipped) 11-61 . . . . . . . . . . . . . . . . . . . . . . .
Front seatbelt pretensioners 1-24 . . . . . . . . . . . . . . . . . . . . . . .
Front seats 1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-58 . . . . . . . .
Front-wheel drive warning light
(for AT vehicles – if equipped) 3-14 . . . . . . . . . . . . . . . .
Fuel 7-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel economy hints 8-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel filler lid and cap 7-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel requirements 7-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located behind the coin tray 12-6 . . . . . . .
Fuse panel located in the engine compartment 12-8 .
Fuses 11-51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and circuits 12-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
G
Glove compartment 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR and GAWR (Gross Vehicle Weight
Rating and Gross Axle Weight Rating) 8-17 . . . . .
H
Hazard warning flasher 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight flasher 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlights 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headrest adjustment (if equipped) 1-10 . . . . . . . . . . . . . .
Head restraint adjustment 1-5 . . . . . . . . . . . . . . . . . . . . . . . . .
Heater operation 4-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High beam indicator light 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . .
High/low beam change (dimmer) 3-16 . . . . . . . . . . . . . . . .
High mount stop light 11-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hose and connections 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to jump start 9-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
