2002 SUBARU IMPREZA WRX audio

Audio
5-6
DisplayControl mode
HB5036BA
Turn counterclockwiseTurn clockwise
BASBass controlFor less bassFor more bass
TRETreble controlFor less trebleFor more treble
BALBalance con- trolTo increase left speaker volume and decreaseright speaker volumeTo increase right speaker volume anddecrease left speaker volume
FA DFader controlTo increase rear speaker volume and decrease
front speaker volumeTo increase front speaker volume anddecrease rear speaker volume
VOLVolume con- trolFor less volumeFor more volume
FM/AM selection button (FM/AM)
Push the “FM/AM” button (4) when the radio is off to
turn on the radio. Push the
“FM/AM” button when the radio is on to
select FM1, FM2 or AM reception. Each time this
button is pressed, the band will change in the fol-
lowing order:

Audio
5-7
– CONTINUED –
FM1FM2
AM
The display indicates which one is currently selected. Stereo indicator
The stereo indicator “ST” will come on when an FM
stereo broadcast is received.
Manual tuning (TUNE)
Push the tuning button (3) marked “ ” to increase
the tuning frequency and press the tuning button
marked “
” to decrease it.
Each time the button is pressed, the frequency
changes 10 KHz in the AM waveband and 0.2 MHzin the FM waveband.
Constant pressure on the button causes a continu-
ous change in the frequency.
Automatic tuning (SCAN)
Press the “SCAN” button (1) to change the radio to
the SCAN mode. In this mode, the radio scans
through the radio band until a station is found. Theradio will stop at the station for five seconds while
displaying the frequency, after which scanning will
continue until the entire band has been scanned from the low end to the high end.
Press the
“SCAN” button again to cancel the SCAN
mode and to stop on any displayed frequency.
When the “SCAN” button is pressed for automatic
tuning, stations are scanned in the direction of low
frequencies to high frequencies only.
Automatic tuning may not function properly if the sta-
tion reception is weakened by distance from the sta-
tion or proximity to tall buildings and hills.
Selecting preset stations
Presetting a station with a preset button (5) allowsyou to select that station in a single operation. Up to
six AM, FM1 and FM2 stations each may be preset.
How to preset stations
1. Press the “FM/AM” selection button to select AM,
FM1 or FM2 reception.
2. Press the “SCAN” button (1) or tune the radio
manually until the desired station frequency is dis-played.
3. Press one of the preset buttons (5) for at least 2
seconds to store the frequency. The frequency of
the station will flash once on the display at this time.
If the button is pressed for less than 2 seconds, the
preceding selection will remain in memory.

Audio
5-8
NOTE If the connection between the radio and battery
is broken for any reason such as vehicle mainte-nance or radio removal, all stations stored in thepreset buttons are cleared. If this occurs, it is
necessary to reset the preset buttons.
Compact disc player operation
HG5008CB
(7) Eject button
(8) Disc slot
(9) DISC button
(10) Repeat/Random button
(11) Track selection buttons

Audio
5-9
– CONTINUED –
To play back a compact disc
n When CD is not in the player
Hold a disc with a finger in the center hole while
gripping the edge of the disc, then insert it in to the
slot (with the label side up) and the player will auto-
matically pull the disc into position.A single CD (8 cm/3 inch CD) may also be used
without any adapter.
NOTE Make sure to always insert a disc with the label
side up. If a disc is inserted with the label side down, it might be ejected or the player mightshut off. After the last song finishes, the player will
automatically return to track 1 (the first song onthe disc).
n When CD is in the player
Press the “DISC” button (9). The display will show
“CD” and the player will start playback.
NOTE
After the last song finishes, playback will auto-
matically return to track 1 (the first song on the disc).
To select a song from its beginning
n Forward direction
Briefly press the “
” button (11) to skip to the begin-
ning of the next track. Each time the button is
pressed, the indicated track number will increase.
n Backward direction
Briefly press the “ ” button (11) to skip to the begin-
ning of the current track. Each time the button is
pressed, the indicated truck number will decrease.
Fast forwarding and fast reverse
n Fast forwarding
Press the “
” button (11) continuously for more than
1 second to fast forward the disc.
Release the button to stop fast forwarding.
n Fast reverse
Press the “ ” button (11) continuously for more than
1 second to fast reverse the disc.
Release the button to stop fast reverse.
Repeat playback
Press the “RPT/RDM” button (10) and release it in
less than 2 seconds while a song is playing to play
the song repeatedly. The “RPT” indicator will come
on and the song will be played continuously. To can-

Audio
5-10
cel the repeat mode, press the button again. Then the “RPT” indicator goes out, and normal playback
mode is restored.
Random playback
Press the “RPT/RDM” button (10) and hold it in for
more than 2 seconds while a disc is being played
back to play all songs on the disc in a random order. The “RDM” indicator will come on and all songs on
the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RDM” indicator goes out, and normal
playback mode is restored.
To eject a disc from the player
When a disc is being played back or when a disc is
in the player, press the eject button “
” (7). The
disc will be ejected.
The disc may be removed even when the ignitionswitch is in the “LOCK” position.
NOTE
Avoid driving the vehicle with a CD sticking out,
because vibration might make it fall out.
CD changer control (If optional in- dash CD changer is connected)
An optional CD changer can be connected to this
audio unit. See your SUBARU dealer for more
information.

Audio
5-11
– CONTINUED –
HG5008DB
(12) Track selection buttons
(13) DISC button
(14) Repeat/Randam button
(15) Disc selection button

Audio
5-12
To start playback
When the “CD” button (13) is pressed, the CD
changer will start playback. The display shows the
current disc number, track number and the elapsed
time during playback. NOTE If a disc is in the player, the “DISC” button is
used to change from CD player operation to DISC changer operation. Each time the “DISC”
button is pressed, the operating mode will
change alternately. At the end of the disc, the player automatically
continues with the next disc. After playback on the last disc finishes, play-
back will automatically return to the first disc. If you have loaded fewer than 6 discs, any mis-
sing disc is automatically skipped.
Selection of a desired disc
You can select a desired disc from among the discs
contained in the magazines only by pressing the
corresponding number one of the disc select but-
tons. If you are to listen to the 7th disc in the double
magazine (12 discs), for example, it is selected firstby selecting “M2” (“M2” means 2nd magazine) with
the “DISC” button and then pressing the “1” button
of the disc select buttons. All other discs in the mag- azines can also be selected in a similar way.
NOTE No disc change takes place if the button corre-
sponding to the magazine slot in which no disc is loaded is pressed. If the direct disc button corresponding to the
disc now in playback is pressed again, the disc will be replayed from its beginning.
To select a song from its beginning
n Forward direction
Briefly press the “
” button (12) to skip to the begin-
ning of the next track. Each time the button is
pressed, the indicated track number will increase.
n Backward direction
Briefly press the “ ” button (12) to skip to the begin-
ning of the current track. Each time the button is
pressed, the indicated track number will decrease.
Fast forwarding and fast reverse
n Fast forwarding
Press the “
” button (12) continuously for more than
1 second to fast forward the disc.
Release the button to stop fast forwarding.
If you continue fast forwarding to the end of the disc,

Audio
5-13
– CONTINUED –
the CD changer will automatically stop fast forward-
ing and start playback beginning with the first track
on the current disc.
n Fast reverse
Press the “ ” button (12) continuously for more than
1 second to fast reverse the disc.
Release the button to stop fast reverse.
If you continue fast reverse to the beginning of the disc, the CD changer will automatically stop fast
reverse and start playback beginning with the first
track on the current disc.
Repeat playback
Use this to play a certain track repeatedly. During
playback, press the “RPT/RDM” button (14) and re-
lease it in less than 2 seconds. The “RPT” indicator
will come on and the song will be played continu-
ously. To cancel the repeat mode, press the buttonagain. Then the “RPT” indicator goes out, and nor-
mal playback mode is restored.
Random playback
Use this to play the tracks on the disc in random or-
der. During playback, press the “RPT/RDM” button
(14) and hold it in for more than 2 seconds. The
“RDM” indicator will come on and all songs on the
disc will be played in a random order. To cancel the random mode, press the button again.
Then the
“RDM” indicator goes out, and normal
playback mode is restored.
