2002 SUBARU IMPREZA WRX light

Seat, seatbelt and SRS airbags
1-20
2. After drawing out the seatbelt, pass it through the
belt guide as follows: First insert one edge of the
belt into the open gap in the comfort guide; then
slide the rest of the belt in, so that the whole belt fitsinside.
3. After confirming that the webbing is not twisted,
insert the connector (tongue) attached at the web- bing end into the buckle on the right-hand side until
a click is heard.
HB1033CA
If the belt stops before reaching the buckle, return
the belt slightly and pull it out more slowly. If the belt
still cannot be unlocked, let the belt retract slightly
after giving it a strong pull, then pull it out slowlyagain.4. Insert the center seatbelt tongue plate in the cen-ter seatbelt buckle marked
“CENTER” on the left-
hand side until it clicks.
HB1034BA

Seat, seatbelt and SRS airbags
1-25
– CONTINUED –
SUBARU dealer as soon as possible. When you sell your vehicle, we urge you to
explain to the buyer that it has seatbelt preten-sioners by alerting him to the contents of thissection.
WARNING
To obtain maximum protection, the occu-
pants should sit in an upright position with their seatbelts properly fastened. Refer to the
“Seatbelts” section in this chapter.
Do not modify, remove or strike the front
seatbelt retractor assemblies or surrounding
area. This could result in accidental activationof the seatbelt pretensioners or could makethe system inoperative, possibly resulting in
serious injury. Seatbelt pretensioners have no
user-serviceable parts. For required servicingof front seatbelt retractors equipped with seat-
belt pretensioners, see your nearest SUBARU
dealer. When discarding front seatbelt retractor
assemblies or scrapping the entire car due to
collision damage or for other reasons, consult
your SUBARU dealer.
System monitors
HG1016BA
A diagnostic system continually monitors the readi-
ness of the seatbelt pretensioner while the vehicle is
being driven. The seatbelt pretensioners share the
control module with the SRS airbag system. There-
fore, if any malfunction occurs in a seatbelt preten-
sioner, the SRS airbag system warning light will illu-
minate. The SRS airbag system warning light will
show normal system operation by lighting for about
6 seconds when the ignition key is turned to the
“ON” position.
The following components are monitored by the indi- cator: Front sub sensor (Right hand side)

Seat, seatbelt and SRS airbags
1-26
Front sub sensor (Left hand side)
Airbag control module (including impact sensors)
Seatbelt pretensioner (driver ’s side)
Seatbelt pretensioner (Passenger ’s side)
All related wiring
In the event of a malfunction indicated by any of fol-
lowing, the vehicle should be taken promptly to your
nearest SUBARU dealer to have the system
checked. Unless checked and repaired, the seatbelt
pretensioners and SRS airbag will not function reli-ably: Flashing or flickering of the indicator light.
No illumination of the warning light when the igni-
tion switch is first turned to the “ON” position.
Continuous illumination of the warning light.
Illumination of the warning light while driving.
System servicing
WARNING
When discarding a seatbelt retractor assem-
bly or scrapping the entire car damaged by a
collision, consult your SUBARU dealer. Tampering with or disconnecting the sys-
tem’ s wiring could result in accidental activa-
tion of the seatbelt pretensioner and/or SRS airbag or could make the system inoperative,
which may result in serious injury. The wiring
harnesses of the seatbelt pretensioner and
SRS airbag systems are covered with yellowinsulation and the connectors of the systemare yellow for easy identification. Do not use
electrical test equipment on any circuit related to the seatbelt pretensioner and SRS airbag
systems. For required servicing of the seat-
belt pretensioner, see your nearest SUBARU
dealer.
CAUTION
The front sub sensors are located in both front fenders and the SRS airbag control mod-
ule including the impact sensors is located
under the center console. If you need service or repair in those areas or near the front seat- belt retractors, we recommend that you have
an authorized SUBARU dealer perform thework.
NOTE If the front part of the vehicle is damaged in an
accident to the extent that the seatbelt preten-

Seat, seatbelt and SRS airbags
1-29
– CONTINUED –
WARNING
Children should be properly restrained at all times. Never allow a child to stand up, or tokneel on any seat. Unrestrained children willbe thrown forward during sudden stop or in
an accident and can be injured seriously.
Additionally, children standing up or kneelingon or in front of the front seat are exposed
another serious danger. Since the SRS airbag
deploys with considerable speed and force,the child could be injured or even killed.
HG1014BA
WARNING
Put children aged 12 and under in the rear seat properly restrained at all times. The SRSairbag deploys with considerable speed andforce and can injure or even kill children, es-
pecially if they are 12 years of age and under and are not restrained or improperly re-strained. Because children are lighter and
weaker than adults, their risk of being injured
from deployment is greater.
For that reason, be sure to secure ALL types of child restraint devices (including forward
facing child seats) in the REAR seats at all
times. You should choose a restraint devicewhich is appropriate for the child ’s age, height
and weight. According to accident statistics,children are safer when properly restrained in the rear seating positions than in the front seating positions.

Seat, seatbelt and SRS airbags
1-39
– CONTINUED –
deployment force. The SRS airbags deploy with considerable
speed and force. Occupants who are out ofproper position when the SRS airbag deploys
could suffer very serious injuries. Becausethe SRS airbag needs enough space for de- ployment, the driver should always sit upright and well back in the seat as far from the steer-ing wheel as practical while still maintainingfull vehicle control and the front passengershould move the seat as far back as possibleand sit upright and well back in the seat. Do not place any objects over or near the
SRS airbag cover or between you and the SRS airbag. If the SRS airbag deploys, those ob-jects could interfere with its proper operationand could be propelled inside the car and
cause injury.
HG1002BA
WARNING
Put children aged 12 and under in the rear
seat properly restrained at all times. The SRS airbag deploys with considerable speed andforce and can injure or even kill children, es-
pecially if they are 12 years of age and underand are not restrained or improperly re- strained. Because children are lighter and
weaker than adults, their risk of being injured
from deployment is greater. For that reason, we strongly recommend thatALL children (including those in child seats
and those that have outgrown child restraint
devices) sit in the REAR seat properly re-

Seat, seatbelt and SRS airbags
1-59
– CONTINUED –
SRS airbag system monitors
A diagnostic system continually monitors the readi- ness of the SRS airbag system while the vehicle is
being driven. The SRS airbag system warning light
“AIRBAG” will show normal system operation by
lighting for about 6 seconds when the ignition key is
turned to the “ON” position.
HG1016BA
The following components are monitored by the indi- cator:Front sub sensor (Right hand side)
Front sub sensor (Left hand side)
Airbag control module (including impact sensors)
Frontal airbag module (Driver ’s side)
Frontal airbag module (Passenger ’s side)
Side airbag sensor (Driver ’s side — if equipped)
Side airbag sensor (Passenger ’s side — if
equipped) Side airbag module (Driver ’s side — if equipped)
Side airbag module (Passenger ’s side — if
equipped) Seatbelt pretensioner (Driver ’s side)
Seatbelt pretensioner (Passenger ’s side)
All related wiring
In the event of a malfunction indicated by any of fol-
lowing, the vehicle should be taken promptly to your
nearest SUBARU dealer to have the system
checked. Unless checked and repaired, the SRS
airbags will not function reliably: Flashing or flickering of the indicator light.
No illumination of the warning light when the igni-
tion switch is first turned to the “ON” position.
Continuous illumination of the warning light.
Illumination of the warning light while driving.

Keys and doors
2-7
– CONTINUED –
HB1000BC
A: LOCK/ARM button
Press to Lock all doors. Press and Hold to activate panic alarm.
B: UNLOCK/DISARM button
B1) Press once to Unlock driver ’s
door.
B2) Press a second time to Unlock all doors.
C: LED
Locking the doors
Briefly press the “LOCK/ARM” button (for less than
two seconds) to lock all doors (and rear gate on the
wagon). The horn will sound one time.
If any of the doors (or the rear gate) is not fully
closed, the horn will sound three times to alert you that the doors (or the rear gate) are not properly
closed. When you close the door, it will automaticallylock.
Unlocking the doors
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) to unlock the driver ’s door. The
horn will sound two times. To unlock all doors (and
rear gate on the wagon), briefly press the
“UNLOCK/DISARM” button a second time within 5
seconds.
Illuminated entry
The interior (dome) light will illuminate when the
“UNLOCK/DISARM” button is pressed. The light will
illuminate for approximately 30 seconds or until the
“LOCK/ARM” button is pressed. Once any of the
doors (or the rear gate on the wagon) is opened, this function will be canceled. The interior light mustbe set to the middle position in order for this func-
tion to operate. Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .
To deactivate it, press the “LOCK/ARM” button or

Keys and doors
2-12
operates by operating each transmitter. Deleting old transmitter codes
The control unit of the keyless entry system has four
memory locations to store transmitter codes, givingit the ability to operate with up to four transmitters.
When you lose a transmitter, the lost transmitter ’s
code remains in the memory. For security reasons,
lost transmitter codes should be deleted from the
memory.
To delete old transmitter codes, program four trans-
mitter codes into the system. If you have only one
current transmitter, program it four times. If you have
two current transmitters, program each one twice. If
you have three current transmitters, program two of
them once and the third one twice. This process will
leave only current transmitter codes in the system ’s
memory. NOTE
Make sure no one else is operating their keyless entry system within range of your vehicle whenprogramming transmitters. If someone else wereto operate their remote transmitter while you are programming your transmitters, it is possible that their transmitter code will be programmedinto your system, allowing them unauthorized
access to your vehicle. Security system (if equipped)
The security system helps to protect your vehicle
and valuables from theft. The horn sounds and the
parking lights flash if someone attempts to break
into your vehicle. The starter motor is also inter-
rupted to prevent starting the vehicle without a key.
The system can be armed and disarmed with the
remote transmitter.The system does not operate when the key is in-
serted into the ignition switch.
System operation
The security system will give the following alarm in-
dications when triggered: The parking lights will flash and the horn will
sound intermittently. In addition, the starter motor willnot operate. The alarm automatically resets after 30 seconds;
however, the alarm will reactivate if the vehicle is
tampered with again. The alarm will continue for sixtimes if any sensor continues to be activated.
The alarm is triggered by: Opening a door, the rear gate or trunk lid.
Application of physical shock to the vehicle (e.g.
