2002 SUBARU IMPREZA WRX light

Keys and doors
2-13
– CONTINUED –
breaking glass or forced entry). Note that there are
two alarm levels for shock: warning and alarm. In
warning mode, the alarm detects lower level vibra-
tions and triggers 2 warning chirps on the horn and
two flashes on the lights as a deterrent to would be
vandals. In alarm mode, higher levels of shock are
detected and the system will go into full alarm. Ignition switch being turned on while in armed
state. Arming the system
To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close all doors (and the rear gate on the wagon).
HB1000EC
1) Press to Arm the system.
2) Press to Disarm the system.
HG2017BA
Security system indicator light

Keys and doors
2-14
6. Briefly press the “LOCK/ARM” button (for less
than two seconds). All doors (and the rear gate on
the wagon) will lock, the horn will sound one time,the parking lights will flash one time and the indica-
tor light starts flashing slowly (approximately once
every two seconds).
If any of the doors (or the rear gate) is not fully
closed, the horn sounds three times, the parking
lights flash three times and the indicator light flashes
rapidly to alert you that the doors (or the rear gate)
are not properly closed. When you close the door,
the system will automatically arm and doors will au-
tomatically lock.
To arm the system using power door lockingswitches
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close the doors (and the rear gate on the wagon)but leave only the driver ’s door or the front passen-
ger’ s door open.
HB2024FB
6. Push the front side ( “LOCK” side) of the power
door locking switch to set the door locks.
7. Close the door. The horn will sound one time, the
parking lights will flash one time and the indicator
light will start flashing slowly (approximately once
every two seconds) to inform you that the system
has armed.
NOTE The system can be armed even if the engine
hood, the windows and/or moonroofs areopened. Always make sure that they are fully
closed before arming the system.

Keys and doors
2-15
– CONTINUED –
Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The
driver’ s door will unlock, the horn will sound two
times, the parking lights will flash two times and the
indicator light will go off.
To unlock all doors (and the rear gate on the
wagon), briefly press the “UNLOCK/DISARM” button
a second time.
Emergency disarming
If you cannot disarm the system using the transmit-
ter (i.e. the transmitter is lost, broken or the transmit-
ter battery is too weak), you can disarm the system
without using the transmitter.
To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from the “LOCK” to the “ON” position three (3) times
within 5 seconds .
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .To deactivate it, press the
“LOCK/ARM” button or
“UNLOCK/DISARM” button.
The parking lights will also flash when the alarm is activated.
Unless a button on the remote is pressed, the alarm
will be deactivated after approximately 30 seconds. Valet mode
When you choose the valet mode, the security sys-
tem does not operate. In valet mode, the remotetransmitter is used only for locking and unlocking
the doors (and rear gate on the wagon) and panicactivation.
To enter the valet mode, open the driver ’s door and
keep the “UNLOCK/DISARM” button depressed for
more than two seconds . The indicator light repeat-
edly flashes two times while the system is in valet mode.
To exit valet mode, open the driver ’s door and keep
the “UNLOCK/DISARM” button pressed for more
than two seconds. The indicator will stop flashing.
Passive arming
When passive arming mode has been programmed
by the dealer, arming of the system is automatically
accomplished without using the remote transmitter.

Keys and doors
2-18
CAUTION
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
below or with the key once they have been
closed. Failure to lock the doors manually willresult in a higher security risk.
Disarming the system
To disarm the system, briefly press the “UNLOCK/
DISARM” button on the transmitter.
n Tripped sensor identification
If the horn sounds four times and the parking lights
flash four times when you disarm the system, this in-
dicates that the alarm was triggered. The number oftimes the indicator light flashes indicates what sen-
sor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to the “ON” position two
times. ( “LOCK” “ON” “LOCK” “ON”
“LOCK”)
3. The indicator light will start flashing. The indicator light provides the following indications.Flashing one time:
Any door, the rear gate or the
trunk lid has been opened.Flashing three times: The impact sensor in the sys-
tem’ s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person. Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
To exit this mode, close the door and turn the igni-
tion switch to the “ON” position.

Keys and doors
2-21
– CONTINUED –
nOperating the driver ’s window
HG2008DB
1) Open
2) Automatically open
3) Close
AUTO switch: This switch has two functions.
1. Push the switch down until it clicks and release it,
and the window will fully open. To stop the window
halfway, pull the switch up lightly.
2. Push the switch down lightly and hold it. The win- dow will open as long as the switch is held. Pull the switch up lightly and hold it. The window willclose as long as the switch is held. n
Operating the passengers ’ windows
HG2008CA
To open the passengers ’ windows, push the ap-
propriate switch down and hold it until the window
reaches the desired position. To close the window,
pull the switch up and hold it until it reaches the de-
sired position.

Keys and doors
2-23
– CONTINUED –
Trunk lid (Sedan)
WARNING
To prevent dangerous exhaust gas from en-
tering the vehicle, always keep the trunk lid
closed while driving. Help prevent young children from locking
themselves in the trunk. When leaving the ve-
hicle, either close all windows and lock all doors or cancel the inside trunk lid release. Also make certain that the trunk is closed.
On hot or sunny days, the temperature in thetrunk could quickly become high enough to
cause death or serious heat-related injuries
including brain damage, particularly for small children.
To open and close the trunk lid from outside
HGF012CA
To open the trunk lid from outside, insert the key and
turn it clockwise. To close the trunk lid, lightly pressthe trunk lid down until the latch engages.

Keys and doors
2-25
– CONTINUED –
Trunk lid release handle
The trunk lid release handle is a device designed to
open the trunk lid from inside the trunk. In the event
children or adults become locked inside the trunk,the handle allows them to open the lid. The handle islocated on the inside of the trunk lid.
To open the trunk lid from inside the trunk, press the
yellow handle downward as indicated by the arrow on the handle.
HBS070BA
This operation unlocks the trunk lid. Then, push up the lid.
The handle is made of material that remains lumi-
nescent for approximately an hour in the dark trunk
space after it is exposed to ambient light even for a short time.
WARNING
Never allow any child to get in the trunk and
play with the release handle. If the driver starts the vehicle without knowing that a child
is inside the trunk and the child opens the lidusing the release handle, the child could fallout and be killed or seriously injured.
CAUTION

Do not close the lid while gripping the re-
lease handle. The handle may be damaged. Do not use the handle as a hook to fasten
straps or ropes to secure your cargo in the trunk. Such use may result in damage of the handle. Load the trunk so that cargo can not strike
the release handle. If the cargo hits the handlewhile the vehicle is being driven, the handlemay be pushed down and the trunk lid may open. That may cause cargo to fall out of the trunk, which could create a traffic safety haz-ard.

3
3-1
– CONTINUED –
Ignition switch 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LOCK 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ACC 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ON 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
START 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key reminder chime 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key interlock release (AT vehicles only) 3-4 . . . . . .
Hazard warning flasher 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Meters and gauges 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer/Trip meter 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature gauge 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature indicator
(if equipped) 3-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning and indicator lights 3-9 . . . . . . . . . . . . . . . . . . . .
Seatbelt warning light and chime 3-9 . . . . . . . . . . . . . . .
SRS airbag system warning light 3-10 . . . . . . . . . . . . . . .
CHECK ENGINE warning light/ Malfunction indicator lamp 3-10 . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light
(for AT vehicles) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-13 . . . . . . . . . . . . . . . . . . . . .
Door open warning lights 3-13 . . . . . . . . . . . . . . . . . . . . . . . . Front-wheel drive warning light
(for AT vehicles – if equipped) 3-14 . . . . . . . . . . . . . . . .
Shift position indicator (AT vehicles) 3-14 . . . . . . . . . .
Turn signal indicator lights 3-14 . . . . . . . . . . . . . . . . . . . . . .
High beam indicator light 3-14 . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlights 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/low beam change (dimmer) 3-16 . . . . . . . . . . . . . . .
Headlight flasher 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime running light system 3-17 . . . . . . . . . . . . . . . . . . .
Turn signal lever 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-18 . . . . . . . . . . . . . . . .
Parking light switch 3-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-19 . . . . . . . . . . . . . . . . . .
Wiper and washer 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switches 3-21 . . . . . . .
Rear window wiper and washer switch
(if equipped) 3-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 3-24 . . . . . . . . . . . . . . . . . .
Mirrors 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside mirror 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheel 3-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instruments and controls
