2002 SUBARU IMPREZA Owners Manual

Maintenance and service
11-64
Wagon
HGB013BA
1. Using a Phillips screwdriver, remove the upper
and lower screws that secure the side cover of the
rear combination light assembly.
HGB014BA
2. Remove the upper and lower screws. Then, slide
the rear combination lamp assembly to the rear and
remove it from the vehicle.

Maintenance and service
11-65
– CONTINUED –
HGB015CB
1) Tail/stop light
2) Rear turn signal light
3) Backup light
4) Rear side marker light
3. Remove the bulb holder from the rear combina-
tion light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it
and turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Close the cover and latch the lock.
7. Reinstall the rear combination light assembly and
its side cover.
License plate light
HGF012FA
1. Remove the mounting screws using a phillips
screwdriver.
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.

Maintenance and service
11-66
Room light, spot light and cargo area light
HSA005BA
HBB029BA
HB0386
1) Bulb
1. Remove the lens by prying the edge of the lens
with a regular screwdriver.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the lens.

Maintenance and service
11-67
– CONTINUED –
Trunk light
HG2009DA
1. Remove the cover by pulling it out.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the cover.
High mount stop light
SedanOM-H2350
1. Remove the high mount stop light cover by pry-
ing the edge with a screwdriver.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the cover.

Maintenance and service
11-68
Wagon
HBB028BA
1. Remove the mounting screw covers by prying
the edge with a screwdriver.
2. Remove the mounting screws using a phillips
screwdriver and then remove the high mount stop
light cover.
3. Remove the bulbs from the socket by pushing it
and turning counterclockwise. Install a new bulb.
4. Reinstall the cover.
5. Tighten the mounting screws then reinstall the covers. NOTE
Other bulbs may be difficult to replace. Have your
SUBARU dealer replace these bulbs if necessary.

12
12-1
– CONTINUED –
Specifications 12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 12-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical system 12-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities 12-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 12-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel alignment 12-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and circuits 12-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located behind the coin tray 12-6 . . . . . .
Fuse panel located in the engine compartment 12-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb chart 12-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle identification 12-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications

Specifications
12-2
Specifications
These specifications are subject to change without notice. Dimensions
in (mm)
Item
SedanWagon
2.5-liter2.0-liter (Turbo)2.5-liter2.0-liter (Turbo)
RSWRXTSOUTBACK SPORTWRX
Drive systemAWD
Transmission typeATMTATMTATMTATMTATMT
Overall length173.4 (4405)
OverallidthSedan68.1 (1730)–widthWagon–66.7 (1695)67.3 (1710)66.7 (1695)
Overall heightWithout roofrail56.7 (1440)57.7 (1465)58.0 (1475)57.7 (1465)
With roofrail–58.5 (1485)58.9 (1495)58.5 (1485)
Wheel base99.4 (2525)
TreadFront58.5 (1485)57.7 (1465)57.5 (1460)57.7 (1465)
Rear58.1 (1475)58.3 (1480)57.3 (1455)
Ground clearance* 15.9 (150)6.1 (155)5.9 (150)6.3 (160)6.1 (155)
*1: Measured with vehicle empty
AT : Automatic transmission MT : Manual transmission

Specifications
12-3
– CONTINUED –
Engine
Engine model
EJ251
(2.5-liter, SOHC, non-turbo)EJ205
(2.0-liter, DOHC, turbo)
Engine typeHorizontally opposed, liquid cooled 4 cylinder, 4-stroke gasoline engine
Displacement cu in. (cc)149.9 (2,457)121.7 (1,994)
Bore × Stroke in. (mm)3.92 × 3.11 (99.5 × 79.0)92.0 × 75.0 (3.62 × 2.95)
Compression ratio10.0 : 18.0 : 1
Firing order1 – 3 – 2 – 4
Electrical system
Battery type
di tEurope modelMT12V-48AH (55D23L)and capacity (5HR)ATWith 2.5-liter engine12V-52AH (75D23L)(5HR)With 2.0-liter engine12V-52AH (65D23L)
Alternator2.5-liter engine12V – 75A
2.0-liter engine12V – 75A
Spark plugs2.5-liter engineBKR6E-11 (NGK)
BKR5E-11 (NGK)
RC10YC4 (Champion)
2.0-liter turbo enginePFR6G (NGK)
AT : Automatic transmission MT : Manual transmission
