bly) plus the vehicle capacity weight. In addition, the total weight applied to each axle
(GAW) must never exceed the GAWR. The front and
rear GAWs can be adjusted by relocating luggageinside the vehicle.Even if the total weight of your luggage is lower than
the vehicle capacity weight, either front or rear GAW
may exceed the GAWR, depending on the distribu-
tion of the luggage.
If you carry heavy loads in the vehicle, you should
confirm that GVW and front and rear GAWs are with-
in the GVWR and GAWR by putting your vehicle on
a vehicle scale, found at a commercial weighing sta-tion.
Do not use replacement tires with a lower load range than the originals because they may lower the
GVWR and GAWR limitations. Replacement tires with a higher load range than the originals do not in-
crease the GVWR and GAWR limitations.
Roof rail and crossbar (if equipped)
HB8016BC
1) Crossbar kit
The roof rail is not designed to carry cargo by itself.
Cargo can be carried after securing the roof cross-
bar kit to the roof rail and installing the appropriate
carrying attachment. When installing the roof cross-
bar kit, follow the manufacturer ’s instructions.
When you carry cargo on the roof using the roof
crossbar kit and a carrying attachment, never ex-
ceed the maximum load limit explained below. You
should also be careful that your vehicle does not ex-
ceed the Gross Vehicle Weight Rating (GVWR) and
front and rear Gross Axle Weight Rating (GAWR). See the “Loading your vehicle ” section in this chap-

Driving tips
8-19
– CONTINUED –
ter for information on loading cargo into or onto your
vehicle. The maximum load limit of the cargo, cross-
bars and carrying attachment must not exceed 100
lb. (45 kg). Place the heaviest load at the bottom,
nearest the roof, and evenly distribute the cargo. Al-
ways properly secure all cargo.
CAUTION
For cargo carrying purposes, the roof rail
must be used together with a roof crossbar kit and the appropriate carrying attachment. Theroof rail must never be used alone to carry cargo. Otherwise, damage to the roof or paint
or a dangerous road hazard due to loss of car-go could result. When using the roof crossbar kit, make sure
that the total weight of the crossbars, carryingattachment and cargo does not exceed the
maximum load limit. Overloading may cause
damage to the vehicle and create a safety haz-ard.
Installing carrying attachments on the cross-bars
When installing any carrying attachment such as a
bike carrier, ski carrier, kayak carrier, cargo basket, etc. on the crossbars, follow the manufacturer
’s
instructions and make sure that the attachment is
securely fixed to the crossbars. Use only attach-
ments designed specifically for the crossbars. A set
of the crossbars is designed to carry loads (cargo
and attachment) of not more than 100 lb. (45 kg).
Before operating the vehicle, make sure that the car-
go is properly secured on the attachment.
NOTE Remember that the vehicle ’s center of gravity is
altered with the weight of the load on the roof, thus affecting the driving characteristics.
Drive carefully. Avoid rapid starts, hard cornering and abrupt stops. Crosswind effects will beincreased.
Removal and installation of the crossbars
The crossbars can be removed when you do not
use the roof to carry cargo.
n To remove the crossbar
1. Loosen and remove the T –30 torx head screw
from the top of each crossbar end support.
2. Rotate the lower clamp on the bottom of each
end support downward approximately 90 °.
3. Carefully raise the crossbar from roof rails.

Driving tips
8-20
nTo install the crossbar
Front crossbar:
Front crossbar has 100 LBS. Load Label on left-hand side.
HG8010BB

Driving tips
8-21
– CONTINUED –
F) Front of vehicle
1) T30 torx head screw
2) Front arrow label
3) Front crossbar
4) 100LBS load label
5) Lower clamp
6) Roof rail end support
7) Joint line
8) 3 inches (76 mm)
9) Front arrow label
1. Before placing the crossbar on the roof rails,
make sure that the T-30 torx head screw is
removed from the top of each crossbar end support.
2. Rotate the lower clamp on the bottom of each
end support downward approximately 90 °.
3. With the front direction arrow label on the top
right side of the crossbar pointing toward the front of
the vehicle, carefully place the crossbar across the
top of the vehicle so that the crossbar end supports
rest on the top of the roof rails approximately 3
inches (76 mm) rearward from the seam (joint)
between the front roof rail support and the roof rail.
4. Rotate (raise) the lower clamp up to the bottom of
the roof rail and loosely tighten the T-30 torx head
screw with the torx wrench provided, through the
top of the end support and into the threaded insert
in the lower clamp on each end of the crossbar. NOTE It may be necessary to squeeze the lower clamp and the end support together to compress thepads and gain a better alignment of the pieces
while trying to start the screw. Use care not tocrossthread the screw in the insert.
5. Adjust the alignment of the crossbar on the roof
rails, and if available, use a T-30 torx
bit and
torque wrench and tighten the T-30 torx head
screws to 30 to 35 inch lbs. (3.4 to 4.0 N-m, 0.35 to
0.41 kg-m) of torque (or tighten securely with thetorx wrench provided).

Driving tips
8-22
Rear crossbar:
HG8011BB
F) Front of vehicle
1) T30 torx head screw
2) Front arrow label
3) Rear crossbar
4) 0 inch (0 mm)
5) Roof rail end support
6) Joint line
7) Front arrow label
Install the rear crossbar in the same manner as the
front crossbar. NOTE The rear crossbar should be positioned just in front of the rear seam (joint) between the rear roof rail support and the roof rail.
CAUTION
Do not carry cargo on the roof when the crossbars are removed. Luggage on the roofwill be thrown forward or backward in sudden
stops or rapid accelerations, resulting in a dangerous road hazard.
NOTE
Before each use of the roof crossbar, make sure
the four T-30 crossbar clamp screws have been

Driving tips
8-23
– CONTINUED –
checked, and retightened if necessary to 35 inch
lbs. (4.0 N-m, 0.41 kg-m), as outlined in Step #5above. Trailer hitch (if equipped) The trailer hitch is designed to tow a Class 1 rated
load. A maximum of
2,000 lbs. (906 kg) gross trailer
weight and a maximum of 200 lbs. (90 kg) gross
tongue weight are permissible for the trailer hitch.
When you tow a trailer, follow the instructions in the next section “Trailer towing ”.
WARNING
Never exceed the maximum weight specified
for the trailer hitch. Exceeding the maximum weight could cause an accident resulting inserious personal injuries. Permissible trailerweight changes depending on the situation.Refer to the next section “Trailer towing ” for
possible recommendations and limitations. Trailer brakes are required when the towing
load exceeds 1,000 lbs. (453 kg). Be sure yourtrailer has safety chains and that each chainwill hold the trailer ’s maximum gross weight.
Towing trailers without safety chains could create a traffic safety hazard if the trailer sepa- rates from the hitch due to coupling damageor hitch ball damage. Be sure to check the hitch pin and safety pin

Driving tips
8-24
for positive locking placement before towing a
trailer. If the ball mount comes off the hitch re-
ceiver, the trailer could get loose and create atraffic safety hazard.Use only the ball mount supplied with this
hitch. Use the hitch only as a weight carrying
hitch. Do not use with any type of weight dis- tributing hitch.
Connecting a trailer
1. Remove the receiver cover from the hitch receiv-
er tube. Then insert the ball mount into the hitch re- ceiver tube.
2. Insert the hitch pin into the hole on the hitch re-
ceiver tube so that the pin passes through the ballmount.
HB8018BA
3. Insert the safety pin into the hitch pin securely.
HB8019BA

Driving tips
8-25
– CONTINUED –
4. Pull the ball mount to make sure it does not come
off the hitch receiver.
HB8020AA
5. Use only a hitch ball that is appropriate for the
ball mount and your trailer. The hitch ball must be
securely installed on the ball mount.
6. Connect your trailer to the hitch ball.
7. Connect the trailer and the hitch with safetychains that will hold the trailer ’s maximum gross
weight. The chains should cross under the trailer
tongue to prevent the tongue from dropping onto the
ground in case it should disconnect from the hitch
ball. Allow sufficient slack in the chains taking tight –
turn situations into account; however, be careful not
to let them drag on the ground.
HB8020BC
1) Hitch ball installation point
2) Hooks for safety chains
WARNING
Do not connect safety chains to improper positions such as those shown in the follow- ing picture.
