2002 SUBARU IMPREZA Owners Manual

Keys and doors
2-12
operates by operating each transmitter. Deleting old transmitter codes
The control unit of the keyless entry system has four
memory locations to store transmitter codes, givingit the ability to operate with up to four transmitters.
When you lose a transmitter, the lost transmitter ’s
code remains in the memory. For security reasons,
lost transmitter codes should be deleted from the
memory.
To delete old transmitter codes, program four trans-
mitter codes into the system. If you have only one
current transmitter, program it four times. If you have
two current transmitters, program each one twice. If
you have three current transmitters, program two of
them once and the third one twice. This process will
leave only current transmitter codes in the system ’s
memory. NOTE
Make sure no one else is operating their keyless entry system within range of your vehicle whenprogramming transmitters. If someone else wereto operate their remote transmitter while you are programming your transmitters, it is possible that their transmitter code will be programmedinto your system, allowing them unauthorized
access to your vehicle. Security system (if equipped)
The security system helps to protect your vehicle
and valuables from theft. The horn sounds and the
parking lights flash if someone attempts to break
into your vehicle. The starter motor is also inter-
rupted to prevent starting the vehicle without a key.
The system can be armed and disarmed with the
remote transmitter.The system does not operate when the key is in-
serted into the ignition switch.
System operation
The security system will give the following alarm in-
dications when triggered: The parking lights will flash and the horn will
sound intermittently. In addition, the starter motor willnot operate. The alarm automatically resets after 30 seconds;
however, the alarm will reactivate if the vehicle is
tampered with again. The alarm will continue for sixtimes if any sensor continues to be activated.
The alarm is triggered by: Opening a door, the rear gate or trunk lid.
Application of physical shock to the vehicle (e.g.

Keys and doors
2-13
– CONTINUED –
breaking glass or forced entry). Note that there are
two alarm levels for shock: warning and alarm. In
warning mode, the alarm detects lower level vibra-
tions and triggers 2 warning chirps on the horn and
two flashes on the lights as a deterrent to would be
vandals. In alarm mode, higher levels of shock are
detected and the system will go into full alarm. Ignition switch being turned on while in armed
state. Arming the system
To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close all doors (and the rear gate on the wagon).
HB1000EC
1) Press to Arm the system.
2) Press to Disarm the system.
HG2017BA
Security system indicator light

Keys and doors
2-14
6. Briefly press the “LOCK/ARM” button (for less
than two seconds). All doors (and the rear gate on
the wagon) will lock, the horn will sound one time,the parking lights will flash one time and the indica-
tor light starts flashing slowly (approximately once
every two seconds).
If any of the doors (or the rear gate) is not fully
closed, the horn sounds three times, the parking
lights flash three times and the indicator light flashes
rapidly to alert you that the doors (or the rear gate)
are not properly closed. When you close the door,
the system will automatically arm and doors will au-
tomatically lock.
To arm the system using power door lockingswitches
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close the doors (and the rear gate on the wagon)but leave only the driver ’s door or the front passen-
ger’ s door open.
HB2024FB
6. Push the front side ( “LOCK” side) of the power
door locking switch to set the door locks.
7. Close the door. The horn will sound one time, the
parking lights will flash one time and the indicator
light will start flashing slowly (approximately once
every two seconds) to inform you that the system
has armed.
NOTE The system can be armed even if the engine
hood, the windows and/or moonroofs areopened. Always make sure that they are fully
closed before arming the system.

Keys and doors
2-15
– CONTINUED –
Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The
driver’ s door will unlock, the horn will sound two
times, the parking lights will flash two times and the
indicator light will go off.
To unlock all doors (and the rear gate on the
wagon), briefly press the “UNLOCK/DISARM” button
a second time.
Emergency disarming
If you cannot disarm the system using the transmit-
ter (i.e. the transmitter is lost, broken or the transmit-
ter battery is too weak), you can disarm the system
without using the transmitter.
To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from the “LOCK” to the “ON” position three (3) times
within 5 seconds .
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .To deactivate it, press the
“LOCK/ARM” button or
“UNLOCK/DISARM” button.
The parking lights will also flash when the alarm is activated.
Unless a button on the remote is pressed, the alarm
will be deactivated after approximately 30 seconds. Valet mode
When you choose the valet mode, the security sys-
tem does not operate. In valet mode, the remotetransmitter is used only for locking and unlocking
the doors (and rear gate on the wagon) and panicactivation.
To enter the valet mode, open the driver ’s door and
keep the “UNLOCK/DISARM” button depressed for
more than two seconds . The indicator light repeat-
edly flashes two times while the system is in valet mode.
To exit valet mode, open the driver ’s door and keep
the “UNLOCK/DISARM” button pressed for more
than two seconds. The indicator will stop flashing.
Passive arming
When passive arming mode has been programmed
by the dealer, arming of the system is automatically
accomplished without using the remote transmitter.

Keys and doors
2-16
Note that in this mode, DOORS MUST BE MANUAL-
LY LOCKED. To enter the passive mode
HB2036BA
1. Remove the side sill cover on the driver ’s side.
1)Open the driver ’s door.
2)Remove the clip by prying the edge with screw-
driver.
3)Remove the side sill cover by pulling it up.
HB2038BC
1) Connector for SRS airbag system (yel- low)
2) Blue (1P)
2. Connect the blue (1 pole) connector.
3. Turn the ignition switch from the “LOCK” to the
“ON” position.
4. Install the side sill cover.
To place the system in active arming mode (remote
required for activation), disconnect the white con-
nector.

Keys and doors
2-17
– CONTINUED –
WARNING
Do not disconnect or tamper with any yellow connector and/or any harness covered withyellow insulation and/or tape.Doing so could result in accidental inflation of the SRS airbag or could make the SRS airbag
system inoperative, which may result in seri-
ous injury.
Arming the system
1. Turn the ignition switch to the “ON” position.
HB2031BC
1) ON 2) LOCK 2. Turn the ignition switch from
“ON” to “LOCK”
position and remove the key from the ignition switch.
HB2024DB
3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with theinside door lock levers.
5. Close the doors. The system will automatically
arm after one minute.
In the passive mode, the system can also be armed
with the remote transmitter or with the power door
locking switches. If the remote transmitter or power
door lock switch is used to lock the vehicle, arming
will take place immediately regardless of whether ornot the passive mode has been selected.

Keys and doors
2-18
CAUTION
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
below or with the key once they have been
closed. Failure to lock the doors manually willresult in a higher security risk.
Disarming the system
To disarm the system, briefly press the “UNLOCK/
DISARM” button on the transmitter.
n Tripped sensor identification
If the horn sounds four times and the parking lights
flash four times when you disarm the system, this in-
dicates that the alarm was triggered. The number oftimes the indicator light flashes indicates what sen-
sor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to the “ON” position two
times. ( “LOCK” “ON” “LOCK” “ON”
“LOCK”)
3. The indicator light will start flashing. The indicator light provides the following indications.Flashing one time:
Any door, the rear gate or the
trunk lid has been opened.Flashing three times: The impact sensor in the sys-
tem’ s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person. Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
To exit this mode, close the door and turn the igni-
tion switch to the “ON” position.

Keys and doors
2-19
– CONTINUED –
Child safety locks
Each rear door has a child safety lock that prevents
the doors from being opened even if the inside door
handle is pulled.
HG2006BB
1) Lock 2) Unlock
When the child safety lock lever is in the lock posi-
tion, the door cannot be opened from inside regard-less of the position of the inner door handle lock
lever. The door can only be opened from the out-side.
WARNING
Always use the child safety lock whenever a child rides in the rear seat. Serious injurycould result if a child accidentally opened thedoor and fell out.
