INSTRUMENTS AND CONTROLS
30
Cruise control indicator light
This indicator light comes on when the function is activated.
Battery charge warning light
This comes on each time the ignition is switched on.
If it comes on with the engine running, it is accompanied b y an audible signal and the message "Low battery
charge" on the multifunction display.
It indicates faulty operation of the charging circuit (loose b attery terminals, a cut or slack alternator belt, an alternator f ault).
Contact a PEUGEOT dealer.
Engine diagnostics warning light
This comes on each time the ignition is switched on.
If it comes on with the engine running, accompanied by an a udible signal and the message "Emission control
system problem" on the multifunction display, it indicates a malfunction in the emission control sy stem.
If it flashes with the engine running, accompanied by an a udible signal and the message "Catalytic converter faulty"on
the multifunction display, it indicates a malfunction in th e injection or ignition sy stem. There is a risk of damage to t he
catalytic converter (petrol engines only).
Contact a PEUGEOT dealer without delay.
Note: following prolonged operation of the vehicle at very low sp eed or at idle, you may, in exceptional circumstances, notice
emissions of water vapour at the exhaust on acceleration. This d oes not have any effect on the vehicle's performance or on
the environment.
Diesel preheat indicator light
This comes on each time the ignition is switched on.
In cold weather, wait until it goes out before trying th e starter.
18-11-2002

INSTRUMENTS AND CONTROLS31
Passenger air bag disarming indicator light
This comes on for a few seconds each time the ignition is switch ed on.
Illumination of this indicator light is accompanied by an au dible signal and the message"Passenger air bag
disarmed" on the multifunction display.
If the passenger air bag is disarmed, the indicator light comes on when the ignition is switched on and remains on.
In all cases, if the indicator light flashes, contact a PEUGEOT dealer.
Front, side and curtain air bags warning light
This warning light comes on when the ignition is switched o n.
Illumination of this warning light, with the engine run ning, is accompanied by an audible signal and the message
"Air bag fault" on the multifunction display, indicating a front, side or cu rtain air bag fault.
Contact a PEUGEOT dealer.
Driver's seat belt warning light
With the engine running, this indicator light comes on, acco mpanied by an audible signal at a speed above 6 mph
(10 km/h) and the message "Seat belt not fastened" on the multifunction display, if the driver's seat belt is no t
fastened.
Low fuel level warning light
This light comes on each time the ignition is switched on.
When the warning light comes on, accompanied by the message "Fuel level low"on the multifunction display,
there is enough fuel remaining to drive approximately 30 miles (50 km). The tank capacity is approximately 80 litres.
This light flashes to indicate a malfunction of the fuel gauge or cuttingoff of the fuel supply, if it is accompanie d by the
message "Fuel circuit neutralised" on the multifunction display.
Restore the supply (refer to the "Practical Information § Fuel Su pply CutOff" section) or contact a PEUGEOT dealer,
depending on the circumstances.
Note: some functions can be configured by your PEUGEOT dealer.
18-11-2002

Maximum
Minimum
Check the level with
the dipstick and top it
up.
The figure shown is
only correct if the vehicle has been
on stable, level ground, with the
engine stopped, for 10 minutes.
No oil
The message "Top
up the oil" appears
on the multifunction
display, accompa
nied by an audible signal.
It is essential to top up the oil to the
correct level, otherwise the engine
may be damaged.
Oil gauge fault
Flashing of the seg
ments indicates a
fault.
Check the level
using the dipstick.
Consult a PEUGEOT dealer. Control module display
After switching on the ignition, three
functions are shown in succession:
– service indicator (see correspond ing section),
– engine oil level indicator,
– total distance recorder (total and trip distances).
Note: the total and trip distances are
displayed for thirty seconds, when
the ignition is switched off, on open
ing the driver's door as well as on
locking and unlocking the vehicle.
It also displays the automatic gear
box positions and programmes
selected (see corresponding sec
tion).
Engine oil level
When the ignition is switched on, the
engine oil level is indicated for
approximately 10 seconds, after the
service information. Lighting rheostat
With the lights on,
press the button to
vary the intensity of
the lighting of the
control module, the
instrument panel, the
air conditioning dis
play and the multi–function display.
When the lighting reaches the mini
mum (or maximum) setting, release
it then press again to increase (or
reduce) the brightness.
As soon as the lighting is of the
brightness required, release the
button.
Trip recorder
zero reset
With the ignition on,
press the button.
INSTRUMENTS AND CONTROLS
34
18-11-2002

44
YOUR 807 IN DETAIL
GENERAL FUNCTIONS On/off
With the ignition key in the accessories or ignition position , press button Mto switch the set on or off.
The set can operate for 30 minutes without the vehicle ign ition being switched on.
Antitheft system
The audio system is coded in such a way that it can operate on ly on your vehicle. It would not function if fitted to another
vehicle.
The antitheft system is automatic and requires no action on your part.
ADJUSTING THE VOLUME
Press button Oto increase the volume, or button Nto decrease it.
Continuous pressure on buttons Oand Nallows a gradual adjustment of the volume.
AUDIO SETTINGS Press button G several times in succession to access the bass ( BASS), treble(TREB), loudness (LOUD),
fader (FAD) , balance ( BAL)and automatic volume correction.
Exit from audio mode is automatic after a few seconds without p ressing any button, or by pressing button G
after configuration of the automatic volume correction.
Note: bass and treble settings are specific to each source. It is possibl e to set them differently for radio, cas
sette (RB3) , CD (RD3) and CD changer.
18-11-2002

YOUR 807 IN DETAIL
56
GENERAL FUNCTIONS On/off
With the ignition switch in the accessories position or with the ignition on, press button C to switch the audio
function of the RT3 audio/telephone on or off.
Note: in the absence of an ignition key, press button C to switch the telematics system on or off.
The RT3 telephone can operate for 30 minutes without switc hing the vehicle ignition on.
Notes:
– the SIM card must be removed only after the audio/telephone h as been switched off,
– following automatic switching off of the audio/telepho ne after 30 minutes, it is possible to make a telephone call by pressing
button D,
– after the ignition has been switched off, the audio/te lephone can be switched on again by pressing buttons D, E, V or by
inserting a CD in the player.
Antitheft system
The RT3 audio/telephone is coded in such a way that it ca n operate only on your vehicle. If fitting it to another vehicle,
consult your PEUGEOT dealer for configuration of the system.
The system is automatic and requires no action on your part.
ADJUSTING THE VOLUME
Turn button Cclockwise to increase the volume of the audio/telephone or an ticlockwise to decrease it.
Note: the volume setting is specific to each source. It is possible to have different settings for radio, CD or CD changer.
AUDIO SETTINGS Press buttonUto access Bass,Treble ,Loudness ,Fader (front/rear balance), Balance(left/. right balance)
and Automatic volume adjustment settings.
Exit from audio mode is automatic after a few seconds without a ny action, or by pressing button J.
Note: bass and treble settings are specific to each source. It is possibl e to have different settings for radio,
CD or CD changer.
18-11-2002

YOUR 807 IN DETAIL
64
TELEPHONE MODE
This function is a GSM dualband telephone (800 and 1 800 MHz) incorporated in the RT3 audio system.
It is a ''hands free'' telephone. This function is provided by a microphone located next to the front courtesy light, the
speakers and a steering column control which allows access to most of the functions (because the audio/telephone control
panel buttons allow access to all the functions).
Display of the principal ''mobile'' type functions, as well as consultation of the indexes, is pro vided by the multi–function
display.
This function is active whatever position the ignition key is in.
Note: when the key is in the accessories position (1st notch), this funct ion will be interrupted after thirty minutes, when the
message ''Economy mode active'' appears on the multi–function display. If you are using the telephone at that time, you
will be able to finish your call.
Using the menus
Press the ''MENU'' button to display the general menu. Select thetelematicsapplication, validiate Telephone functions
to access the principal telephone functions, then the various menus, in order to reach the one required.
This menu allows you to access the following functions:
Network: allows you to select the network search mode and to see the ne tworks
available.
Duration of calls: allows you to consult the duration recorder of calls made and ze ro
reset.
SIM card security: allows you to use or modify the PIN code and to erase the list of
calls and minimessages (SMS).
Telephone options: allows you to configure the calls with entering of my number,
automatic answering after X rings and specification of ring opt ions.
Within each menu:
Move around and select a function by turning knob Gthen validate by pressing the knob.
Cancel an operation by means of the ''ESC''button.
18-11-2002

YOUR 807 IN DETAIL
66
Inputting the PIN code Input your PIN code using the alphanumeric keypad and validate by pressing knobGor button #
to access the network. Connection to the network is validated by the appearance of a symbol on
the screen.
Warning: if you make three errors in succession when inputting your PIN code, your SIM card
will be blocked. To unblock it, you will need to input t he PUK code. The PUK code will be suplied
to you by the person selling your SIM card (input of the PUK code allows for 10 errors in suc
cession; after this the SIM card becomes permanently unusable).
Note: the PIN code is required each time the ignition is switched o n, unless the PIN code has
been stored in the memory or protection by PIN code is not activat ed on the SIM card.
Cancelling of PIN code request
In the menu ''Telephone functions'' select''SIM card security'' , then''Process the PIN code'' , then validate the ''Can
cel'' function.
Warning: in this case, do not lose your SIM card. Losing it would mean a nyone who finds it would be able to make unlimited calls.
Telephone function screens
Not in use
This screen indicates the presence of voice messages or minimessages (SMS) no t lis
tened to, the cumulatve time in use since the last zero reset a nd the status of your tele
phone.
In use
This screen indicates the time elapsed since the start of the co nversation, as well as
the number* or name of the person to whom you are speaking (if recorded in the index)
and the status of your telephone.
*If this option and service are available.
18-11-2002

YOUR 807 IN DETAIL91
Memorising using the buttons M,
1 and 2
T
o memorise using the buttons located
on the side of the seat: Place the ignition key in the 'running'
position (2 nd
notch),
 Adjust your seat and mirrors,
 Press button M,then button 1
(first driving position) or button 2
(second driving position) within
four seconds.
An audible signal confirms that a
position has been memorised.
Memorising a new position cancels
the previous one.
Recalling a memorised position
Engine off Briefly press button 1 or 2to recall
the corresponding memorised
position.
Note: after recalling a memorised
position five times in succession, the
function will be cancelled until the
engine is started.
Engine running Keep button 1 or 2pressed down
until the end of setting of the cor
responding memorised position.
Memorising seat and mirror
positions
Four driving positions can be memo
rised:
– two, using
two remote control
keys (two users),
– two, using buttons M/1 and M/2.
Driving positions memorised by
the remote control key
When locking the doors, the remote
control key memorises the position
of the driver's seat and the exterior
mirrors.
When unlocking the doors, the dri
ver's seat and the exterior mirrors
resume the position memorised by
the remote control key if this has
changed in the meantime.
Each remote control key can
memorise a specific setting. Front heated seat controls
The front seats can be heated sepa
rately.
Use the adjustment controls located
on the side of each seat to select the
level of heating required :
0:
Off.
1: Low.
2: Medium.
3: High.
The seat temperature is controlled
automatically.
Note: the heated seats only operate
with the engine running.
