2002 JEEP LIBERTY fused ignition switch

MULTI-FUNCTION SWITCH C1 - GRAY 10 WAY
CAV CIRCUIT FUNCTION
1 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
2 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 L305 20LB/WT LEFT TURN SWITCH SENSE
7 L309 20LG/WT HIGH BEAM RELAY CONTROL
8 Z12 18BK/TN GROUND
9 L324 20WT/LG HIGH BEAM SWITCH SENSE
10 L302 20LB/YL RIGHT TURN SWITCH SENSE
MULTI-FUNCTION SWITCH C2 - GRAY 8 WAY
CAV CIRCUIT FUNCTION
1 V21 20DB/RD REAR WIPER ON DRIVER
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 V20 18BK/WT WASHER MOTOR SENSE
4 V52 20DG/RD FRONT WIPER SWITCH MUX
5 F88 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
6- -
7 V10 18BR WASHER PUMP DRIVER
8- -
OUTPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
OVERHEAD MAP/READING LAMP (EXCEPT BASE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL REAR COURTESY LAMP CONTROL
3 M20 20BR COURTESY LAMPS LOAD SHEED
8Wa - 80 - 78 8W-80 CONNECTOR PIN-OUTSKJ

PASSENGER SEAT BELT SWITCH - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 R58 18GY (EXCEPT BASE) PASSENGER SEAT BELT SWITCH SENSE
1 R58 18DG (BASE) PASSENGER SEAT BELT SWITCH SENSE
2 R60 18LB (BASE) PASSENGER SEAT BELT SWITCH GROUND
2 R60 18VT (EXCEPT BASE) PASSENGER SEAT BELT SWITCH GROUND
POWER MIRROR SWITCH (EXCEPT BASE) - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 P75 20LB/WT LEFT MIRROR LEFT DRIVER
2 P71 20YL/DG LEFT MIRROR UP DRIVER
3 Z351 18BK/LG (RHD) GROUND
3 Z350 18BK/LG (LHD) GROUND
4 P110 18YL (FOLD) FOLDING MIRROR RETURN
5 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
6 P76 18OR/YL MIRROR COMMON DRIVER
7 P99 18GY (FOLD) FOLDING MIRROR FEED
8- -
9 P72 20YL/BK (FOLD) RIGHT MIRROR UP DRIVER
9 P72 18YL/BK (WITHOUT FOLD) RIGHT MIRROR UP DRIVER
10 P74 20DB (FOLD) RIGHT MIRROR LEFT DRIVER
10 P74 18DB (WITHOUT FOLD) RIGHT MIRROR LEFT DRIVER
POWER OUTLET - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F38 16RD/WT FUSED B(+)
1 F41 16PK/VT FUSED B(+)
2- -
2- -
3 Z3 16BK/OR GROUND
3 Z151 16BK/WT GROUND
POWER STEERING PRESSURE SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K10 18DB/OR POWER STEERING PRESSURE SWITCH SENSE
2 Z246 18BK/GY GROUND
8Wa - 80 - 80 8W-80 CONNECTOR PIN-OUTSKJ

POWER WINDOW MASTER SWITCH (MIDLINE/HIGHLINE) - LT. GRAY 14 WAY
CAV CIRCUIT FUNCTION
1- -
2 Q1 16YL POWER WINDOW SWITCH FEED
2 Q1 16YL POWER WINDOW SWITCH FEED
3- -
4 Q27 14RD/BK LEFT REAR WINDOW DRIVER DOWN
5 Q17 14DB/WT LEFT REAR WINDOW DRIVER UP
6 Q28 14DG/WT RIGHT REAR WINDOW DRIVER DOWN
7 Q18 14GY/BK RIGHT REAR WINDOW DRIVER UP
8- -
9 Q21 14WT LEFT FRONT WINDOW DRIVER DOWN
10 F81 12TN FUSED B(+)
11 Q11 14LB LEFT FRONT WINDOW DRIVER UP
12 Q12 14BR RIGHT FRONT WINDOW DRIVER UP
13 Q22 14VT/WT RIGHT FRONT WINDOW DRIVER DOWN
14 Z238 12BK/WT GROUND
POWERTRAIN CONTROL MODULE-C1 (2.4L) - BLACK 32 WAY
CAV CIRCUIT FUNCTION
1- -
2 F1 18DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 K4 18BK/LB SENSOR GROUND
5- -
6- -
7 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
8 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
9- -
10 K60 18YL/BK IDLE AIR CONTROL NO. 2 DRIVER
11 K40 18BR/WT IDLE AIR CONTROL NO. 1 DRIVER
12 K10 18DB/OR POWER STEERING PRESSURE SWITCH SENSE
13 - -
14 K77 18BR/WT TRANSFER CASE POSITION SENSOR INPUT
15 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
17 K7 18OR 5 VOLT SUPPLY
18 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
19 K39 18GY/RD IDLE AIR CONTROL NO. 3 DRIVER
20 K59 18VT/BK IDLE AIR CONTROL NO. 4 DRIVER
21 - -
22 A14 16RD/WT FUSED B(+)
23 K22 18OR/DB THROTTLE POSITION SENSOR SIGNAL
24 K41 18BK/DG OXYGEN SENSOR 1/1 SIGNAL
25 K141 18TN/WT OXYGEN SENSOR 1/2 SIGNAL
26 - -
27 K1 18DG/RD MANIFOLD ABOLUTE PRESSURE SENSOR SIGNAL
28 - -
29 - -
30 - -
31 Z107 14BK/DB GROUND
32 Z107 14BK/DB GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-81

POWERTRAIN CONTROL MODULE-C1 (3.7L) - BLACK 32 WAY
CAV CIRCUIT FUNCTION
1 K93 14TN/OR COIL ON PLUG DRIVER NO. 3
2 F1 18DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
3 K94 14TN/LG COIL ON PLUG DRIVER NO. 4
4 K4 18BK/LB SENSOR GROUND
5 K96 14TN/LB COIL ON PLUG DRIVER NO. 6
6 T41 18BK/WT (A/T) PARK/NEUTRAL POSITION SWITCH SENSE
7 K91 14TN/RD COIL ON PLUG DRIVER NO.1
8 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
9- -
10 K60 18YL/BK IDLE AIR CONTROL NO. 2 DRIVER
11 K40 18BR/WT IDLE AIR CONTROL NO. 1 DRIVER
12 K10 18DB/OR POWER STEERING PRESSURE SWITCH SENSE
13 T141 18 YL/RD (M/T) FUSED IGNITION SWITCH OUTPUT (START)
13 F45 18YL/BR (A/T) FUSED IGNITION SWITCH OUTPUT (START)
14 K77 18BR/WT TRANSFER CASE POSITION SENSOR INPUT
15 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
17 K7 18OR 5 VOLT SUPPLY
18 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
19 K39 18GY/RD IDLE AIR CONTROL NO. 3 DRIVER
20 K59 18VT/BK IDLE AIR CONTROL NO. 4 DRIVER
21 K95 14TN/DG COIL ON PLUG DRIVER NO. 5
22 A14 16RD/WT FUSED B(+)
23 K22 18OR/DB THROTTLE POSITION SENSOR SIGNAL
24 K41 18BK/DG OXYGEN SENSOR 1/1 SIGNAL
25 K141 18TN/WT OXYGEN SENSOR 1/2 SIGNAL
26 K241 18LG/RD OXYGEN SENSOR 2/1 SIGNAL
27 K1 18DG/RD MANIFOLD ABOLUTE PRESSURE SENSOR SIGNAL
28 - -
29 K341 18TN/WT OXYGEN SENSOR 2/2 SIGNAL
30 - -
31 Z107 14BK/DB GROUND
32 Z107 14BK/DB GROUND
POWERTRAIN CONTROL MODULE-C2 (GAS) - WHITE 32 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 K11 18WT/DB FUEL INJECTOR NO. 1 DRIVER
5 K13 18YL/WT FUEL INJECTOR NO. 3 DRIVER
6 K38 18GY (3.7L) FUEL INJECTOR NO. 5 DRIVER
7- -
8- -
9 K92 14TN/PK (3.7L) COIL ON PLUG DRIVER NO. 2
9 K17 18DB/TN (2.4L) IGNITION COIL NO. 2 DRIVER
10 K20 18DG GENERATOR FIELD
11 - -
12 K58 18BR/DB (3.7L) FUEL INJECTOR NO. 6 DRIVER
8Wa - 80 - 82 8W-80 CONNECTOR PIN-OUTSKJ

POWERTRAIN CONTROL MODULE-C3 (GAS) - LT. GRAY 32 WAY
CAV CIRCUIT FUNCTION
26 K226 18DB/WT FUEL LEVEL SENSOR SIGNAL
27 D21 18PK SCI TRANSMIT
28 - -
29 D32 18LG SCI RECEIVE (PCM)
30 D25 18YL/VT PCI BUS
31 - -
32 V37 18RD/LG SPEED CONTROL SWITCH SIGNAL
RADIATOR FAN MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C25 12YL RADIATOR FAN RELAY OUTPUT
2 Z212 12BK/OR GROUND
RADIATOR FAN RELAY - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 C24 12DB/PK FUSED B(+)
2 C25 12YL RADIATOR FAN RELAY OUTPUT
3 Z212 18BK/OR GROUND
4 K173 18LG RADIATOR FAN RELAY CONTROL
RADIO C1 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 F89 18OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
3 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
4- -
5- -
6- -
7 X54 18VT RIGHT FRONT DOOR SPEAKER (+)
8 X56 18DB/RD RIGHT FRONT DOOR SPEAKER (-)
9 X55 18BR/RD LEFT FRONT DOOR SPEAKER (-)
10 X53 18DG LEFT FRONT DOOR SPEAKER (+)
11 Z9 16BK GROUND
12 M1 20PK FUSED B(+)
13 X16 18LG (PREMIUM) ANTENNA RELAY OUTPUT
14 D25 18YL/VT PCI BUS
15 - -
16 - -
17 - -
18 X51 18BR/YL LEFT REAR SPEAKER (+)
19 X57 18BR/LB LEFT REAR SPEAKER (-)
20 X58 18DB/OR RIGHT REAR SPEAKER (-)
21 X52 18DB/WT RIGHT REAR SPEAKER (+)
22 Z9 16BK GROUND
8Wa - 80 - 84 8W-80 CONNECTOR PIN-OUTSKJ

RADIO C2 - 10 WAY
CAV CIRCUIT FUNCTION
1 X40 20WT/RD AUDIO OUT RIGHT
2 Z30 20WT/BK GROUND
3 Z9 20BK/DB GROUND
4 D25 20YL/VT PCI BUS
5 X112 20RD IGNITION SWITCH OUTPUT
6 X41 20WT/DG AUDIO OUT LEFT
7 Z17 20BK GROUND
8- -
9- -
10 X160 20YL B(+)
RADIO C3-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
RADIO CHOKE (PREMIUM) - GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 F60 16DG/RD FUSED B(+)
2 X13 16BK/RD RADIO CHOKE OUTPUT
3 X16 18LG ANTENNA RELAY OUTPUT
4 Z140 16BK/LG GROUND
REAR POWER OUTLET - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F41 16PK/VT FUSED B(+)
2- -
3 Z151 16BK/WT GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-85

RIGHT COURTESY LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL COURTESY LAMP DRIVER
RIGHT CURTAIN AIRBAG - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R76 18YL/DB RIGHT CURTAIN SQUIB LINE 2
2 R74 18YL/BR RIGHT CURTAIN SQUIB LINE 1
RIGHT CYLINDER LOCK SWITCH (EXCEPT BASE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 P37 18LG DOOR LOCK SWITCH GROUND
2 G72 18DG/OR (LHD) RIGHT CYLINDER LOCK SWITCH MUX
2 G73 18LG/OR (RHD) RIGHT CYLINDER LOCK SWITCH MUX
RIGHT DOOR LOCK SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 P36 20PK/VT DOOR LOCK SWITCH MUX
2 Z351 18BK/LG GROUND
3 F89 20OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 P37 20LG DOOR LOCK SWITCH GROUND
RIGHT FOG LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z142 18BK/WT GROUND
B L39 18LB FOG LAMP RELAY OUTPUT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-87

RIGHT HEATED SEAT ASSEMBLY (HIGHLINE) - LT. GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 F98 16RD/WT PASSENGER HEATED SEAT FEED
2 Z238 16BK/WT GROUND
3 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
4 P142 20TN/DB PASSENGER HEATED SEAT TEMPERATURE SENSOR
GROUND
RIGHT HEATED SEAT SWITCH (HIGHLINE) - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 P140 20VT/BK RIGHT SEAT HIGH HEAT LED DRIVER
3 P134 20TN/LG RIGHT SEAT HEATER SWITCH MUX
4 P138 20VT/LG RIGHT SEAT LOW HEAT LED DRIVER
5 Z238 20BK/WT GROUND
6- -
7- -
8- -
RIGHT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X84 18TN/BK (PREMIUM) AMPLIFIED HIGH RIGHT FRONT SPEAKER (+)
1 X54 18VT (BASE) RIGHT FRONT SPEAKER (+)
2 X86 18OR/RD (PREMIUM) AMPLIFIED HIGH RIGHT FRONT SPEAKER (-)
2 X56 18DB/RD (BASE) RIGHT FRONT SPEAKER (-)
RIGHT LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z142 18BK/WT GROUND
2 L13 18BR/YL HEADLAMP ADJUST SIGNAL
3 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
8Wa - 80 - 90 8W-80 CONNECTOR PIN-OUTSKJ
