6- 30 DO-IT-YOURSELF MAINTENANCE
G270C01L-GAT
LUGGAGE COMPARTMENT LIGHT
1. Open the trunk lid.
2. Remove the luggage compartment
light cover on the rear package tray panel with a blade screwdriver. G270E01L
Screwdriver
2. To replace the back-up light, take
out it from the bulb holder and install the new bulb. G270C01L
G270J01L-GAT
BACK UP LIGHT
1. Remove the trunk lid trim.
Back-up light
3. To replace the rear combinationlight (stop/tail light and rear turn signal light), take out it from the bulb holder and install the newbulb.
Stop/ Tail light
G270B02L
Rear turn signal light
DO-IT-YOURSELF MAINTENANCE 6- 35
FUSE RATING
25A 20A10A15A10A10A10A15A10A10A15A 10A 10A 10A20A10A 15A 10A15A10A10A15A10A20A 10A 10A 10A 10A10A10A 10A 10A PROTECTED COMPONENTS
Power seat
Seat warmerEPS controls
ETS relay
(HID) Head lights, DRL controls, AQS sensor
Blower & A/C controls
Turn & Hazard controlsNot used
Cruise switch, Instrument cluster
Head light leveling switch, Rain sensor, IMS controls
Rain sensor relay, Wiper & Washer controls
Home link connector, Left (Right) vanity lights, Sunroof, Blower & A/C controls,Electronic chrome mirrorNot used
Audio
Front (Rear) cigarette lighter, Accessory socket
IMS controls, Driver door module, RheostatNot used
Rear for light relay
Stop lights, Left (Right) personal lights, Left (Right) rear door lights
Door warning & Ignition key illumination, Courtesy lightsInstrument clusterSRS controls
Automatic transaxle controls, Back-up light switch, Vehicle speed sensor
Fuel filler door & Trunk lid opener, Driver (Assister) door module
Multipurpose check connector, Audio, lmmobiilizer controls, Trip computers, Digital
clock, Blower & A/C controls, Instrument cluster
Left (Right) inside lights, (HID) Head lights, Fog light relay, Right HID turn signal light,Right rear combination light
Stop light failure relay
Immobilizer controls, TCS switch, Trip computers, Instrument cluster
ETACM, Hazard switch, Auto light sensor
Antenna, Blower & A/C controls, Left (Right) outside mirror motor & Folding motor
(HID) Head lights, Front (Rear) cigarette lighters, Left (Right) license lights, Left HID
Turn signal light, Left rear combination lightBurglar alarm relay, Transaxle range switch, Start relay, ETS controlsDESCRIPTION P/SEAT
S/HTR EPSETS
H/LP
A/CON SW HAZARDSPARE
CRUISE IMS
WIPER
ETACS
SPARE AUDIO
C/LIGHTER MIRRORSPARE
RR FOG
STOP LP
ROOM LP
A/BAG IND A/BAGB/UP
T/LID
D/CLOCK
RH TAILSPARE
CLUSTER T/SIG
RR HTD IND
LH TAIL
START
G200D01L-GAT
Instrument Panel Junction Box
G200D01L
10- 2 INDEX
A Accessory Box .......................................................... 1-68
Air Bag .......................................................... 1-31 ~ 1-38
Air Cleaner Fil ter ....................................................... 6-11
Air Conditioning
Care ....................................................................... 6-17
Operation ..................................................... 1-83, 6-17
Switch ..................................................................... 1-82
Antenna ..................................................... 1-115 ~ 1-116
Ashtray ...................................................................... 1-56 Audio Remote Control Switch ................................... 1-75
Automatic Heating and Cooling Control System
................................................................... 1-84 ~ 1-89
B
Battery ............................................................. 2-16, 6-23Bi-Level Heating ........................................................ 1-80
Brake Anti-lock brake system .......................................... 2-11Checking the brakes .............................................. 6-15
Fluid ....................................................................... 6-15
Pedal clearance ..................................................... 6-21
Pedal freepl ay ........................................................ 6-20
Practices .................................................... 2-13 ~ 2-14
Breaking-In your New Hyundai ................................... 1-3
Bulbs wattage ........................................................... 6-33 C Care of Cassette Tapes
........................... 1-114 ~ 1-115
Cassette Tape Player Operation (H940B, H940A) ........................................... 1-96 ~1-97, 1-104 ~ 1-105
Catalytic Converter ..................................................... 7-3
CD Auto changer ...................................................... 1-69
CD Auto changer (H940B, H940A)
....................................... 1-98 ~ 1-100, 1-109 ~ 1-111
Child-Protector Rear Door Lock ................................. 1-7
Child Restraint S ystem ................................. 1-23 ~ 1-29
Cigarette Lighter ....................................................... 1-55
Clock ......................................................................... 1-53
Clutch
Checking fluid ........................................................ 6-16
Pedal freepl ay ........................................................ 6-20
Combination Light Headlight flasher .................................................... 1-50
Headlight swi tch ..................................................... 1-48
High-beam swi tch .................................................. 1-49
Lane change si gnal ................................................ 1-48
Turn signal oper ation............................................. 1-48
Compact Disc Player Operation (H940A) . 1-106 ~ 1-108 Cooling Fans ............................................................. 6-24
Corrosion protection Cleaning the interior ....................................... 4-5 ~ 4-6
Protecting your Hyundai from corrosion ........ 4-1 ~ 4-6Washing and waxing ...................................... 4-3 ~ 4-5
Cruise Control ............................................... 1-72 ~ 1-74
