2002 Hyundai Grandeur ECO mode

FEATURES OF YOUR HYUNDAI 1- 3
B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to:
o Observe all regulations regarding
registration and insurance.
o Determine that acceptable fuel is
available.
B020A01S-GAT BREAKING IN YOUR NEW HYUNDAIDuring the First 2,000 Km (1,200Miles) No formal "break-in" procedure is re- quired with your new Hyundai. How- ever, you can contribute to the eco-nomical operation and durability of yourHyundai by observing the followingrecommendations during the first 2,000km (1,200 miles). B030A01Y-AAT KEYS For greater convenience, your Hyundai has two master keys and a sub key.The master keys will open all locks onyour vehicle. The sub key will only function in the ignition and the door locks.Leaving your sub key with a parkingattendant will ensure that your vehicle'strunk, trunk lid release, glove box com-partment and rear trunk access may not be unlocked in your absence. NOTE: Before leaving your sub key with a parking attendant, make sure thatthe lock levers of the rear seat back
HXG116
Master key Sub key
o Don't drive faster than 88 km/h (55
mph).
o While driving, keep your engine speed (rpm, or revolutions per minute) between 2,000 rpm and 4,000 rpm.
o Use moderate acceleration. Don't start, depress the accelerator pedal fully.
o For the first 300 km (200 miles), try to avoid hard stops.
o Don't lug the engine (in other words,
don't drive so slowly in too high agear that the engine "bucks": shift toa lower gear).
o Whether going fast or slow, vary
your speed from time to time.
o Don't let the engine idle longer than
3 minutes for a catalytic converterequipped engine.
o Don't tow a trailer during the first 2,000 km (1,200 miles) of opera-tion.

1- 52 FEATURES OF YOUR HYUNDAI
WARNING:
When the ignition switch is on and the windshield wiper switch is placed in the "AUTO" mode, pleaseuse caution in the following casesto avoid any hand injury:
o Do not touch the upper end of the windshield glass facing the rain sensor.
o Do not wipe the upper end of the
windshield glass with a cloth.
o Do not put pressure on the wind- shield glass. HXGS251
Rain Sensor
The rear window defroster is turned on by pushing in the switch. At the same time, the rear window defroster indica-tor light on the switch is turned on. Toturn the defroster off, push the switcha second time. The rear window de-froster automatically turns itself off af- ter about 20 minutes. To restart the defroster cycle, push in the switchagain after it has turned itself off.
B380A01HP-GAT REAR WINDOW DEFROSTER
SWITCH (If Installed)
B370A01A-AAT HAZARD WARNING SYSTEM
The hazard warning system should be used whenever you find it necessary tostop the car in a hazardous location.When you must make such an emer- gency stop, always pull off the road as far as possible.The hazard warning lights are turnedon by pushing in the hazard switch.This causes all turn signal lights toblink. The hazard warning lights will operate even though the key is not in the ignition.To turn the hazard warning lights off,push the switch a second time. HXGS217
HXG122
Manual A/Con Full automatic A/Con
!

1- 78 FEATURES OF YOUR HYUNDAI
NOTE:
o It should be noted that prolonged
operation of the heating system in " " mode will give rise tomisting of the windshield andside windows and the air withinthe passenger compartment will become stale. In addition pro- longed use of the air condition-ing with the " " mode selectedmay result in the air within thepassenger compartment becom-ing excessively dry.
o When the ignition switch is
turned "ON", the air intake con-trol will change to " " mode(regardless of switch position).This is normal operation.
HEF030
B670D01L-AAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, or windshield. Five symbols are used to represent Face, Bi-Level,Floor, Floor-Defrost and Defrost airposition.
Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents.
B670D03L
B670D02L

FEATURES OF YOUR HYUNDAI 1- 87
Exhaust gas cutoff mode :
Air enters the vehicle from the outside. But if exhaust gas enters the vehiclefrom the outside, the exhaust gas cut-off mode ( ) is automatically con-verted to the ( ) mode, to prevent exhaust gas from entering the vehicle. NOTE:
o It should be noted that prolonged operation of the heating system in recirculation mode ( ) willgive rise to misting of the winds-hield and side windows and the air within the passenger com- partment will become stale. Inaddition, prolonged use of theair conditioning with the recircu-lation mode ( ) selected may result in the air within the pas- senger compartment becomingexcessively dry. B980D01Y-AAT Heating and Cooling System Off Press the "OFF" button to stop the operation of the heating and coolingsystem.o When the ignition switch is turned
"ON", the air intake control willchange to ( ) mode (regardless
of switch position). This is normaloperation. The air intake control operates in "AUTO" mode when turning the ignition to the ON po-sition if the "AUTO" mode wasused before shutting off the en-gine.
CAUTION:
If the windows fog up with the Re-circulation or A.Q.S mode selected, set the air intake control to the Fresh air position or A.Q.S controlto "OFF".
!
B980E01L-GAT Air Flow Control
HXG505J
This is used to direct the flow of air. Air can be directed to the floor, dashboardoutlets, or windshield. Four symbolsare used to represent Face, Bi-Level, Floor and Floor-Defrost air position.

FEATURES OF YOUR HYUNDAI 1- 89
!
CAUTION:
o Replace the filter every 20,000 km (12,000 miles) or once a year. If the car is being driven in severeconditions such as dusty, rough roads, more frequent air filter in- spections and changes are re-quired.
o When the air flow rate is suddenly decreased, it must be checked atauthorized dealer.
Floor-Defrost Level
When selecting the "Floor-Defrost"mode, the indicator light will come on and the air will be discharged through the windshield defrost vents, the floorvents, side defroster nozzle side venti-lator .
B980C01Y-GAT Defrost Switch When the "Defrost" button is pressed, the " " mode will be automaticallyselected and the air will be dischargedthrough the windshield defrost vents.To assist in defrosting the air condi- tioning will operate if ambient tempera- ture is higher than 3.5°C and automati-cally turns off if the ambient tempera-ture drops below 3.5°C. B980C01L
B760A01L-GAT AIR FILTER (FOR EVAPORATOR AND BLOWER UNIT)
B760A01Y
Inside of a vehicle
Evaporator core
Filter
BlowerOutside air
Inside air
The air filter is located in front of the evaporator unit behind the glove box.It operates to decrease pollutants fromentering the car and to filter the air.To replace the air filter, refer to the page6-18.

1- 94 FEATURES OF YOUR HYUNDAI
B940B02L-GAT
1. POWER ON-OFF/VOLUME
CONTROL KNOB
The radio unit may be operated when the ignition key is in the "ACC" or "ON"position. Press the button to switch thepower on. The display shows the radiofrequency in the radio mode, the tape direction indicator in the tape mode, or CD track in the CD AUTO CHANGERmode. To switch the power off, pressthe button again. VOLUME Control Rotate the knob clockwise to increase the volume and turn the knob counter- clockwise to reduce the volume.
2. BASS/BALANCE Control BASS Control Knob Press to pop the knob out. To increase the bass, rotate the knob clockwise,while to decrease the bass, rotate the knob counterclockwise. 4. TUNE (Manual) Select Button Press the (+) side or (-) side to in- crease or to decrease the frequency.With the button held down for 0.5 sec.or more, the frequency selection willincrease or decrease rapidly. SEEK Operation (Automatic Channel Selection) Press the TUNE select button 1 sec. or more. When the (+) side is pressed, theunit will automatically tune to the nexthigher frequency and when
the (-) side
is pressed, it will automatically tune to the next lower frequency. 5. PRESET STATION Select
Buttons
Six (6) stations for AM, FM and FM2 respectively can be preset in the elec-tronic memory circuit.
BALANCE Control Further pull the popped-up knob. Ro- tate the knob clockwise to emphasizeright speaker sound. (Left speakersound will be attenuated) When thecontrol knob is turned counterclock- wise, left speaker sound will be em- phasized (Right speaker sound will beattenuated). 3. TREBLE/FAD Knob TREBLE Control Knob Press to pop the knob out and turn to the left or right for the desired treble tone. FAD (Fader Control) Knob Further pull the popped-up knob. Turn the control knob clockwise to empha-size rear speaker sound. (Front speaker sound will be attenuated) When the control knob is turned coun-terclockwise, front speaker sound willbe emphasized. (Rear speaker soundwill be attenuated)

FEATURES OF YOUR HYUNDAI 1- 95
CLASSIC JAZZ ROCK DEFEAT

HOW TO PRESET STATIONS Six AM and twelve FM stations may be programmed into the memory of theradio. Then, by simply pressing theband select button and/or one of thesix station select buttons, you may recall any of these stations instantly. To program the stations, follow thesesteps:
o Press band selector to set the band
for AM, FM and FM2.
o Select the desired station to be
stored by seek, scan or manual tuning.
o Determine the preset station select button you wish to use to accessthat station.
o Press the station select button for
more than two seconds. A selectbutton indicator will show in the dis-play indicating which select buttonyou have depressed. The frequencydisplay will flash after it has been stored into the memory. You should then release the button, and pro-ceed to program the next desiredstation. A total of 18 stations can beprogrammed by selecting one AMand two FM station per button. o When completed, any preset station
may be recalled by selecting AM,FM or FM2 band and the appropriatestation button.
6. BAND Selector Pressing the button changes the AM, FM1 and FM2 bands. The mode se-lected is shown on the display.
7. EQ Button Press the EQ button to select the CLASSIC, JAZZ, ROCK and DEFEAT MODE for the desired tone quality.Each press of the button changes thedisplay as follows; 8. Best Station Memory Button
(BSM) (If installed)
When the BSM button is pressed fortwo seconds or longer, the six chan-nels from the highest field intensity areselected next and stored in memory.The stations selected are stored in the sequence frequency from the first pre- set key.
9. SCAN Button (If installed) When the scan button is pressed, the frequency will increase and the receiv-able stations will be tuned in one after another, receiving each station for 5 seconds. To stop scanning, press thescan button again.

FEATURES OF YOUR HYUNDAI 1- 97
B940D01L-GAT
1. FF/REW Button
o Fast forward tape winding starts
when the FF button is pressed during PLAY or REW mode.
o PLAY starts when the FF button is
pressed again during FF mode.
o Tape rewinding starts when the
REW button is pressed during PLAYor FF mode.
o PLAY starts when the REW button pressed again during REW mode.
2. AUTO MUSIC SELECT Button Press the button to find the starting point of each song in a prerecordedmusic tape. The quiet space betweensongs (must have at least a 4 sec. gap)can be accepted by the AUTO MUSIC SELECT button.
o Pressing the will play the begin- ning of the next music segment.
o Pressing the will start replay at the beginning of the music just lis- tened to.
o To stop FF or REW action, press the button again. 3. TAPE PROGRAM Button This allows you to play the reverse side of the tape by merely pressing theprogram button. An arrow will appear inthe display to show tape direction.
4. EJECT button
o When the EJECT button is pressed
with a cassette loaded, the cassette will eject.
o When the EJECT button is pressed during FF/REW mode, the cassettewill eject.
5. EQ Button Press the EQ button to select the CLASSIC, JAZZ, ROCK and DEFEATMODE for the desired tone quality.Each press of the button changes thedisplay as follows; 6. DOLBY Button If you get background noise during tape PLAY, you can reduce this consider-ably by merely pressing the DOLBYbutton. If you want to cancel the DOLBYfeature, press the button again.
CLASSIC JAZZ ROCK DEFEAT
