2002 FORD MUSTANG Owners Manual

Autoset memory preset
Autoset allows you to set strong radio stations
without losing your original manually set preset
stations. This feature is helpful on trips when you
travel between cities with different radio stations.
Starting autoset memory preset
1. Select a frequency using the AM/FM select
controls.
2. Press the AUTO
control.
3. When the first six
strong stations are
filled, the station
stored in memory
preset control 1 will start playing.
If there are less than six strong stations available on
the frequency band, the remaining memory preset
controls will all store the last strong station
available.
These stations are temporarily stored in the memory
preset controls (until deactivated) and are accessed
in the same manner as your original presets.
To deactivate autoset and return to your audio
system's manually set memory stations, press the
AUTO control again.
Setting the clock
To set the hour, press
and hold the CLK
control and press
SEEK:
²
to decrease
hours and
²
to increase
hours.
AUTO
CLK
AUTO
CLK
Entertainment Systems
25

To set the minute,
press and hold the CLK
control and press
TUNE:
²
to decrease
minutes and
²
to increase
minutes.
If your vehicle has a
separate clock, (other than the digital radio display),
the CLK control will not function in the above
manner.
The CLK control will
allow you to switch
between media display
mode (radio station,
stereo information,
etc.) and clock display
mode (time). When in
clock mode, the media information will display for 10
seconds, when the radio is turned on, and then
revert to clock information. Any time that the media
is changed, (new radio station, etc.), the media
information will again display for 10 seconds before
reverting back to the clock. In media mode, the
media information will always be displayed.
Tune adjust
The tune control works in radio mode.
AUTO
CLK
AUTO
CLK
Entertainment Systems
26

Tune adjust in radio mode
²Pressto move to
the next frequency
down the band
(whether or not a
listenable station is
located there). Hold the control to move through
the frequencies quickly.
²Press
to move to the next frequency up the
band (whether or not a listenable station is
located there). Hold for quick movement.
Tape/CD select
²To begin tape play
(with a tape loaded
into the audio
system) while in the radio or CD mode, press the
TAPE control. Press again during rewind or fast
forward to stop the rewind or fast forward
function.
²To begin CD play (if
CD(s) are loaded),
press the CD
control. The first track of the disc will begin
playing. If returning from radio or tape mode, CD
play will begin where it stopped last.
Press the CD control to toggle between single CD
and CD changer play (if equipped).
Do not insert any promotional (odd shaped or
sized) discs, or discs with removable labels into
the CD player as jamming may occur.
TAPE CD
TAPE CD
Entertainment Systems
27

Rewind
The rewind control
works in tape and CD
modes.
²In tape mode, radio play will continue until
rewind is stopped (with the TAPE control) or the
beginning of the tape is reached.
²In CD mode, pressing the REW control rewinds
the CD within the current track.
Fast forward
The fast forward
control works in tape
and CD modes.
²In the tape mode, tape direction will automatically
reverse when the end of the tape is reached.
²In CD mode, pressing the control fast forwards
the CD within the current track.
Tape direction select
Press SIDE 1±2 to play
the alternate side of a
tape.
Eject function
Press the EJ control to
stop and eject a tape.
Press the EJ control to
stop and eject a CD.
REW1
FF2
SIDE 1-23
EJ
EJ
Entertainment Systems
28

DolbyTnoise reduction
Dolbytnoise reduction
operates in tape mode.
Dolbytnoise reduction
reduces the amount of
hiss and static during tape playback.
Press the
control to activate (and deactivate)
the Dolbytnoise reduction.
Dolbytnoise reduction is manufactured under
license from DolbytLaboratories Licensing
Corporation. ªDolbytº and the double-D symbol
are registered trademarks of DolbytLaboratories
Licensing Corporation.
Compression adjust
Compression adjust
brings soft and loud
CD passages together
for a more consistent
listening level.
Press the COMP control to activate and deactivate
compression adjust.
Shuffle feature
The shuffle feature
operates in CD mode
(if equipped) and plays
all tracks on the
current disc in random order. If equipped with the
CD changer, the shuffle feature continues to the
next disc after all tracks on the current disc are
played.
Press the SHUFFLE control to start this feature.
Random order play will continue until the SHUFFLE
control is pressed again.
4
COMP5
SHUFFLE6
Entertainment Systems
29

Mute mode
Press the MUTE
control to mute the
playing media. Press
the MUTE control
again to return to the
playing media.
MACHTMP3 MUSIC SYSTEM
1. ON/OFF and volume
control
2. AM/FM control
3. Bass control
4. Treble control
5. Fade control
6. Balance control
7. Seek control
8. Scan control
9. Clock control
10. Tune/Directory
control11. CD control
12. MP3 directory control
13. Eject control
14. CD rewind control
15. CD fast forward
control
16. Shuffle control
17. Compression control
18. Track control
19. Repeat control
EJ
MUTE
Entertainment Systems
30

Volume/power control
Press the control to
turn the audio system
on or off.
Turn the control to
raise or lower the
volume.
If the volume is set above a certain level and the
ignition is turned off, the volume will come back on
at a ªnominalº listening level when the ignition
switch is turned back on.
AM/FM select
The AM/FM select control works in radio mode.
AM/FM select in radio mode
This control allows you
to select AM or FM
frequency bands. Press
the control to switch
between AM, FM1 or FM2 memory preset stations.
Bass adjust
The bass adjust control
allows you to increase
or decrease the audio
system's bass output.
Treble adjust
The treble adjust
control allows you to
increase or decrease
the audio system's
treble output.
Entertainment Systems
31

Speaker fade adjust
Speaker sound can be
adjusted between the
front and rear
speakers.
Speaker balance adjust
Speaker sound
distribution can be
adjusted between the
right and left speakers.
MP3 functions
Your audio system is equipped with MP3 capability
which allows you to listen to songs in MP3 flat file
mode and MP3 directory mode.
To engage MP3 flat file mode, insert an MP3 disc. If
an MP3 disc is already present in the player, press
the CD control. The MP3 icon will display while the
player is in MP3 mode.
While in MP3 flat file
mode, press the MP3
DIR control to enter
into MP3 directory
mode. The MP3 icon and the DIR icon will display
while the player is in directory mode.
Your MACHtMP3 player is also equipped with an
anti-shock buffer for MP3 discs.
Entertainment Systems
32
