2002 FORD MUSTANG Owners Manual

Shuffle feature
The shuffle feature works in CD mode, MP3 flat file
mode and MP3 directory mode.
Shuffle feature in CD mode
The shuffle feature plays all tracks on the current
disc in random order.
²Press the SHUFFLE
control to engage
random play. SHF
and then ON will
briefly appear in the display. The player will then
begin random play.
²To select another
random track on the
disc, press
oron the SEEK
control.
²Press the SCN
control to scan
through random
tracks. The track
number will flash in the display. The shuffle
feature will remain enabled.
Press the SHUFFLE control again to disable the
shuffle function. SHF and then OFF will briefly
appear in the display.
Shuffle feature in MP3 flat file mode
The shuffle feature in MP3 flat file mode allows you
to play all the tracks on the MP3 disc in random
order.
²Press the SHUFFLE
control to engage
random play. SHF
and then ON will
briefly appear in the display. The player will then
begin random play.
Entertainment Systems
41

²To select another
random track on the
disc, press
oron the SEEK
control.
²Press SCN to scan
through random
tracks. The track
number will flash in
the display. The shuffle function will remain
enabled.
²Press SHUFFLE
again to disengage
the shuffle feature.
SHF and then OFF
will briefly display and the current track will
continue to play.
Shuffle feature in MP3 directory mode
The shuffle feature in MP3 directory mode allows
you to play all the tracks in the current directory in
random order.
²Press the SHUFFLE
control to engage
random play in the
current directory.
SHF and then ON will briefly appear in the
display. The player will then begin random play.
²To select another
random track in the
current directory,
press
oron
the SEEK control.
²Press the SCN
control to scan
through random
tracks in the current
directory. The track number will flash in the
display. The shuffle feature will remain enabled.
Entertainment Systems
42

To shuffle tracks in
another directory,
press
oron the
TUNE DIR control to select the desired directory.
The shuffle function still remains enabled.
Press the SHUFFLE control again to disengage the
SHUFFLE feature. SHUF and OFF will briefly
display and the current track will continue to play.
Compression feature
The compression feature works in CD, MP3 flat file
mode and MP3 directory mode.
Compression adjust
brings soft and loud CD
passages together for a
more consistent listening level.
Press the COMP control to activate compression
adjust. The compression icon (c) will illuminate in
the display while the compression function is
enabled.
Press the COMP control again to disengage the
feature.
MACHTTrack function
The MACHttrack function allows you to quickly
search through a large number of tracks or
directories on the MP3 disc. The function works in
MP3 flat file mode and MP3 directory mode.
Track function in MP3 flat file mode and MP3
directory mode
²Press the TRACK
control. TRAC will
appear in the
display.
²Rotate the volume
control to advance
or reverse through
the tracks.
Entertainment Systems
43

The MP3 icon will blink in the display while the
MACHttrack function is enabled.
When the desired track is reached, the selected
track will begin play after a two second delay.
To disengage the MACHttrack function, press the
TRACK control again.
Repeat track function
This function works in MP3 flat file mode or MP3
directory mode and allows you repeat the current
track on the MP3 disc.
Repeat track function in MP3 flat file mode and
MP3 directory mode.
Press the REPEAT
control to repeat the
current track. The
repeat icon will display
and the current track will continue to repeat until
the repeat function is disengaged.
Press the REPEAT control again to disengage the
feature.
Error messages
You may experience an error message for the
following situations:
²NO DISC when the CD control is pressed and
there is not a CD present.
²DISC ERR when there is a damaged or unreadable
disc. Such as, data discs containing no .mp3 files,
or for data discs containing more than 255 files or
directories.
²CD ERR for any other disc malfunction.
Saving and naming MP3 files
²Your MACHtMP3 music system supports discs
containing up to 255 files in 255 directories. Discs
containing more than 255 files will not play.
Entertainment Systems
44

²Always save MP3 files with the .mp3 extension.
The player recognizes an MP3 file by the .mp3
extension, so MP3 files saved with different
extensions will not be played.Never save a
non-MP3 file with the .mp3 extension as the
file will not play properly and damage may
occur to the player or your sound system.
²The player supports multi session discs. However,
be sure to import the previous session of the disc
before you add new files. If you do not import the
previous session, only the last session will be
played.
²When burning a disc, ensure that you
close/finalize the disc before playback, or the disc
may not play properly or an error message may
appear.
²The player supports DAM (Digital Automatic
Music) discs.
MACHT460 SOUND SYSTEM RADIO
(CD CHANGER COMPATIBLE)
LOADEJ
SHUFDSPMUTE
SELBAL BASS
FADE TREB
SCAN
PUSH ON
CD123456MENUAM
FM
SEEKREW FFDISC
TUNE
Entertainment Systems
45

MACHT1000 SOUND SYSTEM RADIO
(CD CHANGER COMPATIBLE)
MACH 1000TAUDIO SYSTEM
Your vehicle may be equipped with theMACH
1000taudio system. This system is equipped with a
rack of amplifiers in the trunk of the vehicle. Do not
store or rest items on the amplifier rack, as this
could cause damage to the amplifiers and void your
warranty.
TheMACH 1000taudio system is capable of
producing very high sound pressure levels. For your
listening comfort and protection, it is not
recommended to listen to theMACH 1000taudio
system at high volume levels for extended periods of
time.
Volume/power control
Press the control to
turn the audio system
on or off.
PUSH ON
Entertainment Systems
46

Turn the control to
raise or lower volume.
If the volume is set above a certain level and the
ignition is turned off, the volume will come back on
at a ªnominalº listening level when the ignition
switch is turned back on.
Speed sensitive volume
With this feature, radio volume changes
automatically and slightly with vehicle speed to
compensate for road and wind noise.
The recommended level for speed sensitive volume
is from level 1 through level 3. Level 0 turns the
speed sensitive volume off and level 7 is the
maximum setting.
To engage the speed
sensitive volume
feature, press and hold
the volume control for
five seconds (with the
radio on), then press:
²
to increase
volume
compensation.
²
to decrease or
shut off the volume
compensation.
The selected level will appear in the display.
VOL
PUSH ON
SEL
Entertainment Systems
47

Bass adjust
The bass adjust control
allows you to increase
or decrease the audio
system's bass output.
Press the BASS control. Use the SEL control to
increase or decrease the amount of bass.
Treble adjust
The treble adjust
control allows you to
increase or decrease
the audio system's
treble output.
Press the TREB control. Use the SEL control to
increase or decrease the amount of treble.
Speaker balance adjust
Speaker sound
distribution can be
adjusted between the
right and left speakers.
Press the BAL control. Use the SEL control to adjust
the sound between the speakers.
Speaker fade adjust
Speaker sound can be
adjusted between the
front and rear
speakers.
Press the FADE control. Use the SEL control to
adjust the sound between the front and rear
speakers.
Mute mode
Press the control to
mute the playing
media. Press the
control again to return to the playing media.
SELBASS
TREB
+
SELBASS
TREB
+
BAL
FADESEL+
BAL
FADESEL+
Entertainment Systems
