MOTOCRAFT PART NUMBERS
Component 2.0L SOHC I4
engine2.0L DOHC Zetec
engine
Air filter element FA-1643 FA-1643
Fuel filter FG-862 FG-862
Battery BXT-58 BXT-58
Oil filter FL-400±S FL-2005
PCV valve EV-244 EV-239A
Spark plugs* AGSF-34EE** AZFS-32FE**
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
** If a spark plug is removed for inspection, it must be reinstalled in the
same cylinder. If a spark plug needs to be replaced, use only spark plugs
with the same service part number suffix letter as shown on the engine
decal.
REFILL CAPACITIES
FluidFord Part
NameApplication Capacity
Brake fluid High
Performance
DOT 3 Motor
Vehicle Brake
FluidAll Fill to line on
reservoir
Engine coolant
1Motorcraft
Premium Engine
Coolant
(green-colored)
or Motorcraft
Premium Gold
Engine Coolant
(yellow-colored)Automatic
transaxles6.0L
(6.3 quarts)
Manual
transaxles5.0L
(5.3 quarts)
Maintenance and Specifications
195
R
Rear window defroster ...............41
Relays ................................121, 128
Remote entry system ...........65, 67
illuminated entry ......................69
locking/unlocking doors .....63, 66
opening the trunk .....................67
panic alarm ...............................67
replacement/additional
transmitters ...............................68
replacing the batteries .............67
S
Safety belts (see
Safety restraints) ............14, 75±79
Safety defects, reporting ..........147
Safety restraints ....................75±79
belt minder ...............................81
cleaning the safety
belts ...................................84, 154
extension assembly ..................80
for adults .............................76±78
for children .........................89±90
lap belt ......................................79
warning light and
chime .............................12, 14, 80
Safety seats for children ............91
Seat belts
(see Safety restraints) ...............75
Seats ............................................72
child safety seats ......................91
Servicing your vehicle ..............156
Spark plugs, specifications ......195,
198
Specification chart,
lubricants ...........................196, 198Speed control ..............................57
Speedometer ...............................17
Starting your vehicle ....97±98, 100
jump starting ..........................132
Steering wheel
controls ................................54, 57
tilting .........................................54
T
Tachometer .................................17
Temperature control
(see Climate control) .................37
Tires ...........................128, 191±192
changing ..........................128±129
checking the pressure ............192
replacing ..................................193
rotating ....................................192
snow tires and chains ............194
tire grades ...............................192
treadwear ................................191
Towing .......................................115
trailer towing ..........................115
wrecker ....................................137
Transaxle
automatic operation ...............105
fluid, refill capacities ..............195
lubricant specifications ..........198
Transmission
fluid, checking and adding
(automatic) .............................187
fluid, checking and adding
(manual) .................................189
lubricant specifications ..........196
Trip odometer .............................17
Trunk ...........................................64
remote release ....................62, 67
Turn signal ............................13, 46
Index
209
