DODGE TOWN AND COUNTRY 2002 Service Manual 8W-39 VEHICLE THEFT SECURITY SYSTEM
Component Page
Body Control Module......... 8W-39-2, 4, 7, 8, 9,
10, 11, 12, 13, 14, 15
Clockspring......................... 8W-39-6
Data Link Connector............

8W-39 VEHICLE THEFT SECURITY SYSTEM
Component Page
Body Control Module......... 8W-39-2, 4, 7, 8, 9,
10, 11, 12, 13, 14, 15
Clockspring......................... 8W-39-6
Data Link Connector................. 8W-39-4
Diagnostic Junction Port............... 8W-39-4
Driver Door Lock Switch........... 8W-39-12, 13
Engine Control Module................ 8W-39-3
Front Control Module............... 8W-39-4, 6
Front Intrusion Sensor................ 8W-39-5
Fuse 8............................. 8W-39-6
Fuse 14............................ 8W-39-2
Fuse 24............................ 8W-39-2
G102.............................. 8W-39-6
G200.............................. 8W-39-3
G300............ 8W-39-7, 8, 9, 10, 11, 12, 13, 14
G301............... 8W-39-7, 8, 9, 10, 11, 12, 13
G302............................. 8W-39-15
G400.......................... 8W-39-14, 15
High Note Horn..................... 8W-39-6
Hood Ajar Switch................... 8W-39-14
Horn Relay......................... 8W-39-6
Horn Switch........................ 8W-39-6
Ignition Switch.................... 8W-39-3, 4
Integrated Power Module.......... 8W-39-2, 4, 6
Left Cylinder Lock Switch.......... 8W-39-12, 13
Left Front Door Ajar Switch............ 8W-39-7
Left Front Door Lock Motor/Ajar
Switch......................... 8W-39-7, 8
Left Sliding Door Control Module..... 8W-39-9, 10Component Page
Left Sliding Door Latch Sensing Switch . . . 8W-39-9
Left Sliding Door Lock Motor.......... 8W-39-10
Left Sliding Door Lock Motor/Ajar
Switch.......................... 8W-39-11
Liftgate Ajar Switch................. 8W-39-15
Liftgate Cinch/Release Motor.......... 8W-39-15
Liftgate Cylinder Lock Switch.......... 8W-39-14
Low Note Horn...................... 8W-39-6
Message Center..................... 8W-39-2
Passenger Door Lock Switch........ 8W-39-12, 13
Power Liftgate Module............... 8W-39-15
Powertrain Control Module............. 8W-39-3
Rear Intrusion Sensor................. 8W-39-5
Remote Keyless Entry Module.......... 8W-39-2
Right Cylinder Lock Switch......... 8W-39-12, 13
Right Front Door Ajar Switch........... 8W-39-7
Right Front Door Lock Motor/Ajar
Switch......................... 8W-39-7, 8
Right Sliding Door Control Module.... 8W-39-9, 10
Right Sliding Door Latch Sensing
Switch........................... 8W-39-9
Right Sliding Door Lock Motor......... 8W-39-10
Right Sliding Door Lock Motor/Ajar
Switch.......................... 8W-39-11
Sentry Key Immobilizer Module....... 8W-39-2, 3
Siren.............................. 8W-39-4
Thatcham Alarm Indicator............. 8W-39-5
Thatcham Alarm Module............ 8W-39-4, 5
RS8W-39 VEHICLE THEFT SECURITY SYSTEM8W-39-1
