2002 CHEVROLET SILVERADO Owners Manual

6-84
Fuse Usage
B/U LP Backup Lamps, Automatic
Transmission Shift Lock
Control System
ATC Automatic Transfer Case
RR DEFOG Rear Window Defogger,
Heated Mirrors (Relay)
RR PRK Right Rear Parking Lamps
ECM B PCM
F/PMP Fuel Pump (Relay)
O2 A Oxygen Sensors
FUEL HT Fuel Heater, Glow Plug and Intake
Heater Controls
O2 B Oxygen Sensors
LR PRK Left Rear Parking Lamps
RR DEFOG Rear Window Defogger,
Heated Mirrors
HDLP Headlamps (Relay)
TRL PRK Parking Lamps Trailer Wiring
RT HDLP Right Headlamps
DRL Daytime Running Lamps (Relay)
HTD MIR Heated MirrorsFuse Usage
LT HDLP Left Headlamps
A/C Air Conditioning
AUX PWR Cigarette Lighter, Auxiliary
Power Outlets
SEO 2 Special Equipment Option Power,
Power Seats, Aux Roof Mnt Lamp
SEO 1 Special Equipment Option Power,
Aux Roof Mnt Lamp, Cell
Phone, OnStar


DRL Daytime Running Lamps
A/C A/C (Relay)
FOG LP Fog Lamps
FOG LP Fog Lamps (Relay)
RADIO Audio System, Instrument Cluster,
Climate Control System
CIGAR Cigarette Lighter, Auxiliary
Power Outlets
RT TURN Right Turn Signals
BTSI Automatic Transmission Shift
Lock Control System
LT TURN Left Turn Signals
FR PRK Front Parking Lamps,
Sidemarker Lamps

6-85
Fuse Usage
W/W PMP Windshield Washer Pump
HORN Horn (Relay)
IGN C Ignition Switch, Fuel Pump,
PRND321 Display, Crank
RDO AMP Not Used
HAZ LP Exterior Lamps, Hazard Lamps
EXP LPS Not Used
HORN Horn
CTSY LP Interior Lamps
RR WPR Not Used
TBC Body Control Module, Remote
Keyless Entry, Headlamps
Replacement Bulbs
Lamps Quantity Number
Low
-Beam Headlamps2 9006
High
-Beam
Headlamps2 9005
Daytime Running
Lamps (DRL)2 4157KLamps Quantity Number
Front Roof
Marker Lamps5 194
Front Parking and
Turn Lamp2 3157 A
Rear Marker Lamp,
Taillamp and
Stop Lamp2 3157
Taillamp and
Stop Lamp**2 1157
Rear Turn Lamp 2 3157
Rear Turn Lamp ** 2 1156
Back
-up Lamp2 3157
Back
-up Lamp **2 1156
Center High
-Mounted
Stoplamp2 912
Cargo Lamp 2 912
Fender Marker Lamps 4 194
* For any bulb not listed here, contact your dealer.
** Chassis Cab Models

6-86
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº in the Index for more information. All capacities are
approximate. When adding see the refrigerant charge label under the hood for charge capacity information and
requirements.
Engine Type VIN Code Spark Plug Gap
VORTEC 4300 V6 W 0.060 inches (1.52 mm)
VORTEC 4800 V8 V 0.060 inches (1.52 mm)
VORTEC 5300 V8 T 0.060 inches (1.52 mm)
VORTEC 6000 V8 U 0.060 inches (1.52 mm)
VORTEC 6600 V8 1 0.060 inches (1.52 mm)
VORTEC 8100 V8 G 0.060 inches (1.52 mm)
Wheels and Tires
Model Description Torque
C/K 1500 & C/K 2500 6 bolts (14 mm)
140 lb
-ft (190 N´m)
C/K 3500 8 bolts (14 mm)
140 lb
-ft (190 N´m)
Tire Pressure See the Certification/Tire label on the rear edge of the driver's door
or the incomplete vehicle document in the cab.

6-87 Cooling System Capacity
After refill, the level must be rechecked. See ªCooling Systemº in the Index.
Engine Transmission Quantity
VORTEC 4300 V6 Automatic 12.6 quarts (11.9 L)
VORTEC 4300 V6 Manual 12.9 quarts (12.2 L)
VORTEC 4800 V8 Automatic 13.4 quarts (12.7 L)
VORTEC 4800 V8 Manual 13.7 quarts (13.0 L)
VORTEC 5300 V8 Automatic 13.4 quarts (12.7 L)
VORTEC 5300 V8** Automatic 14.9 quarts (14.1 L)
VORTEC 6000 V8 Automatic 14.8 quarts (14.0 L)
VORTEC 6000 V8* Automatic 14.4 quarts (13.6 L)
VORTEC 6000 V8 Manual 15.2 quarts (14.4 L)
VORTEC 6000 V8* Manual 14.8 quarts (14.0 L)
VORTEC 8100 V8 Manual 21.1 quarts (20.0 L)
VORTEC 8100 V8 Automatic 20.7 quarts (19.6 L)
* Vehicles equipped with the optional engine oil cooler.
** Vehicles equipped with the optional air conditioner.

6-88 Engine Oil with Filter Capacity
After refill, the level must be rechecked. Add enough engine oil so that the fluid is within the proper operating range.
See ªEngine Oilº in the Index.
Engine VIN
Quantity with Filter

VORTEC 4300 V6 W 4.5 quarts (4.3 L)
VORTEC 4800 V8 V 6.0 quarts (5.7 L)
VORTEC 5300 V8 T 6.0 quarts (5.7 L)
VORTEC 6000 V8 U 6.0 quarts (5.7 L)
VORTEC 8100 V8 G 6.5 quarts (6.1 L)

Oil filter should be changed at every oil change.

6-89 Fuel Tank Capacity
Type Quantity
Short Bed 26.0 U.S. gallons (98 L)
Long Bed 34.0 U.S. gallons (128 L)
Chassis Cab
(Pickup
Box Delete)34.0 U.S. gallons (128 L)
Chassis Cab 3500 27.0 U.S. gallons (102 L) (front)
23.0 U.S. gallons (87 L) (rear)
Chassis Cab 3500
(California)24.0 U.S. gallons (90 L) (front)
23.0 U.S. gallons (87 L) (rear)
Chassis Cab 3500 27.0 U.S. gallons (102 L) (front)
Chassis Cab 3500
(California)27.0 U.S. gallons (102 L) (front)
Chassis
Cab 3500HD23.0 U.S. gallons (87 L) (front)
18.0 U.S. gallons (68 L) (rear)
Chassis
Cab 3500HD23.0 U.S. gallons (87 L) (front)
Air Conditioning
Refrigerant Capacity
If you do your own service work, you'll need the proper
service manual. See ªDoing Your Own Service Workº in
the Index for additional information. It is recommended
that service work on your air conditioning system be
performed by a qualified technician.
Air Conditioning
Refrigerant R
-134a 1.76 lbs (0.8 kg). . . . . . . . . . . .
Use Refrigerant Oil, R134a Systems

6-90
Normal Maintenance Replacement Parts
Replacement part numbers listed in this section are based on the latest information available at the time of printing,
and are subject to change. If a part listed in this manual is not the same as the part used in your vehicle when it was
built, or if you have any questions, please contact your GM dealer.
These specifications are for information only. If you have any questions, see the service manual for the chassis or
refer to the body manufacturer's publications.
VIN Code W V T U G
Oil Filter* PF47 PF59 PF59 PF59 PF454
Engine Air Cleaner/Filter*
A1519C
A1519C
A1519C
A1518C A1518C
Passenger Compartment
Air Filter Kit**52485513 52485513 52485513 52485513 52485513
PCV Valve* CV769C CV948C CV948C CV948C
Spark Plugs
41
-932*PTJ14R15***
/PZTR5A15

PTJ14R15***
/PZTR5A15

PTZ16R15***
/PZTR5A15

PTJ14R15***


Fuel Filter* GF626 GF626 GF626 GF626 GF626
Wiper Blades** 15153642 15153642 15153642 15153642 15153642
Wiper Blade Type ITTA ITTA ITTA ITTA ITTA
Wiper Blade Length 22 inches
(56.0 cm)22 inches
(56.0 cm)22 inches
(56.0 cm)22 inches
(56.0 cm)22 inches
(56.0 cm)
*ACDelco

part number
**GM part number
***Denso part numberA1518C high-capacity air cleaner filter may
be substituted.
 NGK part number
