2002 CHEVROLET SILVERADO Owners Manual

3-15
In addition to the four stations already set, up to three
more stations may be preset on each band by pressing
two adjoining pushbuttons at the same time and by
performing the following steps:
1. Tune in the desired station.
2. Press SET. SET will appear on the display.
3. Press two adjoining pushbuttons at the same time,
within five seconds. Whenever you press the same
two pushbuttons, the station you set will return.
4. Repeat the steps for each pair of pushbuttons.Setting the Tone (Bass/Treble)
BASS: Slide this lever up or down to increase or
decrease bass.
TREB (Treble): Slide this lever up or down to increase
or decrease treble. If a station is weak or noisy, you may
want to decrease the treble.
Adjusting the Speakers (Balance/Fade)
BAL (Balance): Turn the control ring behind the
upper knob to move the sound to the left or right
speakers. The middle position balances the sound
between the speakers.
FADE: Turn the control ring behind the lower knob to
move the sound to the front or rear speakers. The middle
position balances the sound between the speakers.

3-16 AM-FM Stereo with Compact Disc Player
and Automatic Tone Control (If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
The knob is capable of turning continuously.SCV (Speed
-Compensated Volume): With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Each notch on the
control ring allows for more volume compensation at
faster vehicle speeds. Then, as you drive, SCV
automatically increases the volume, as necessary, to
overcome noise at any speed. The volume level should
always sound the same to you as you drive. If you don't
want to use SCV, turn the control all the way down.
RECALL: Pressing this button will display the station
being played or it will display the clock. Clock display
is available with the ignition turned off.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display will show your selection.
TUNE: Press this knob lightly so it extends. Turn it to
choose radio stations. Push the knob back into its stored
position when you're not using it.

3-17
SEEK : Press the right or left arrow to seek to the
next station or previous station and stay there. The radio
will seek to stations with a strong signal only. The sound
will mute while seeking.
To scan stations, press and hold either SEEK arrow for
two seconds until SCAN appears on the display. The
radio will scan to a station, play for a few seconds, then
go on to the next station. Press either SEEK arrow again
to stop scanning. The radio will scan to stations with a
strong signal only. The sound will mute while scanning.
P.SCAN (Preset Scan): Press this button to scan
through your favorite stations stored on your
pushbuttons. P.SCAN will appear on the display. The
radio will scan to the first preset station stored on your
pushbuttons, play for a few seconds, then go on to the
next station. Press this button again or one of the
pushbuttons to stop scanning. The channel number
(P1 through P6) will appear with the frequency. The
radio will scan preset stations with a strong signal only.
The sound will mute while scanning.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to select the setting you prefer.
5. Press and hold one of the six pushbuttons. The sound
will mute. When it returns, release the pushbutton.
Whenever you press that numbered pushbutton, the
station you set will return and the tone you selected
will be automatically selected for that pushbutton.
6. Repeat the steps for each pushbutton.

3-18
Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob clockwise to increase treble and
counterclockwise to decrease treble. If a station is weak
or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
AUTO TONE: This feature allows you to choose
bass and treble equalization settings designed for
country/western, jazz, talk, pop, rock and
classical stations.
Each time you press the AUTO TONE button, this
feature will switch to one of these program types.
To return the bass and treble to the manual mode, either
press and release the AUTO TONE button until the
display goes blank or press and release the BASS or
TREB knobs and turn them until the display goes blank.Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press this knob lightly so it extends.
Turn the knob clockwise to adjust sound to the right
speakers and counterclockwise to adjust sound to the left
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. Wait a few seconds and the disc
should play. CD and a CD symbol will also appear on
the display. Anytime you are playing a CD, the letters
CD will be next to the CD symbol.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.
1 PREV (Previous): Press this pushbutton to search for
the previous track. If you hold this pushbutton or press it
more than once, the disc will advance further. Sound is
muted in this mode.

3-19
2 RDM (Random): Press this pushbutton to play the
tracks on the disc in random order. RANDOM will
appear on the display. Press this pushbutton again to
return to normal play.
3 NEXT: Press this pushbutton to search for the next
track. If you hold this pushbutton or press it more than
once, the disc will advance further. The next track
number will appear on the display. Sound is muted in
this mode.
REV 4 (Reverse): Press and hold this pushbutton to
return rapidly to a favorite passage. You will hear the
disc play at high speed while you press this pushbutton.
This allows you to listen and find out when the disc is
at the desired passage. Release this pushbutton to
resume playing.
FWD 6 (Forward): Press and hold this pushbutton
to advance rapidly within a track. You will hear the disc
play at high speed while you press this pushbutton.
This allows you to listen and find out when the disc is
at the desired passage. Release this pushbutton to
resume playing.
SEEK : The right arrow is the same as NEXT, and
a the left arrow is the same as PREV. If the right or left
arrow is held or pressed more than once, the player will
continue moving forward or backward through the disc.RECALL: Press this button to see what track is
playing. Press it again within five seconds to see how
long the CD has been playing that track. Elapsed time
is displayed in minutes and seconds. The track number
will also appear when a new track begins to play.
Press this button again to return to the time display.
AM FM: Press this button to listen to the radio when
playing a CD. The CD symbol will still display but the
word CD will be replaced with either AM, FM1 or FM2.
If the radio is turned off, the disc stays in the player and
will resume playing at the point where it stopped.
CD AUX (Auxiliary): Press this button to play a
CD when listening to the radio. When a disc is playing,
the letters CD and the CD symbol will appear on the
display. If the radio is turned off, the disc stays in
the player and will resume playing at the point where
it stopped.
EJECT: Press this button to eject the disc from the
player and play the radio. When the same or a new disc
is inserted, the disc will start playing on track one. If a
compact disc is left sitting in the opening for more than
a few seconds, the player will pull the CD back in. The
radio will continue playing. When the ignition is off,
press this button to load a CD.

3-20
Compact Disc Messages
ERR (Error): If this message appears and the disc
comes out, it could be for one of the following reasons:

If you're driving on a very rough road. When the
road becomes smooth the disc should play.

If it's very hot. When the temperature returns to
normal, the disc should play.

The disc is upside down.

It is dirty, scratched or wet.

The air is very humid. (If so, wait about an hour and
try again.)

If the CD is not playing correctly, for any other
reason, try a known good CD.
Press RECALL to make ERR go off of the display.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.Remote Cassette Tape Player (If Equipped)
If your vehicle has this feature it is located in the center
console extension.
Your tape player is built to work best with tapes that
are up to 30 to 45 minutes long on each side. Tapes
longer than that are so thin they may not work well
in this player.
To load a cassette tape with the ignition off, first press
EJECT on the remote player. Then, insert the cassette
tape. The tape will play if the ignition is on but the radio
is off.

3-21
Once the tape is playing, use the control knobs for
VOL, AUTO TONE, BAL, FADE, BASS and TREB
just as you do for the radio. A lighted tape symbol
shows when a cassette tape is in the player. A lighted
arrow will also appear and show the direction of play
when a tape is active.
The player automatically senses if the cassette tape is
metal or CrO
2 and adjusts for best playback sound.
Anytime a cassette tape is inserted, the top side is
selected for play first.
Primary Radio Controls
The following functions are controlled by the
main radio:
1 PREV (Previous): Press this pushbutton or the left
SEEK arrow (in the opposite direction that the lighted
tape direction arrow points) to search for the previous
selection. A minimum three
-second blank gap is needed
for the player to stop at the beginning of the selection.
The tape direction arrow will blink during the SEEK
operation and the sound is muted in this mode.3 NEXT: Press this pushbutton or the right SEEK arrow
(in the direction that the lighted tape direction arrow
points) to search for the next selection. The tape
direction arrow will blink during SEEK operation and
the sound is muted in this mode.
REV 4 (Reverse): Press this pushbutton to rapidly
reverse the tape. The tape will rapidly reverse to the
beginning of the cassette or until you press this
pushbutton again. The radio plays the last selected
station during reverse operation.
5: Press this pushbutton to turn Dolby NR on
and off. Dolby NR is active when a tape is inserted in
the remote cassette. The double
-D symbol will appear
on the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
FWD 6 (Forward): Press this pushbutton to rapidly
advance the tape. The tape will rapidly advance to the
end of the cassette or until you press this pushbutton
again. The radio plays the last selected station during
forward operation.

3-22
AM FM: Press this button to listen to the radio
when a tape is playing. The inactive tape will remain
in the player.
CD AUX (Auxiliary): Press this button to play a
tape when listening to the radio. The lighted arrow will
appear next to the symbol and show the direction of
play when a tape is active.
Remote Cassette Tape Player Controls
The following functions are controlled by the remote
cassette tape player:
PROG (Program): Press this button on the remote
player to go from one side of the tape to the other.
EJECT: Press this button on the remote player to
remove the tape. EJECT can be used with either the
ignition or radio off. Also, you must press EJECT before
loading a cassette with the radio off to allow loading.Theft-Deterrent Feature (If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. It works by using a secret code to disable all radio
functions whenever battery power is removed.
The THEFTLOCK feature for the radio may be used or
ignored. If ignored, the system plays normally and the
radio is not protected by the feature. If THEFTLOCK is
activated, your radio will not operate if stolen.
When THEFTLOCK is activated, the radio will display
LOC to indicate a locked condition anytime battery
power has been interrupted. If your battery loses power
for any reason, you must unlock the radio with the secret
code before it will operate.
