2002 CHEVROLET MONTE CARLO Owners Manual

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-8 Remote Keyless Entry (If Equipped)
2
-12 Trunk
2
-16 Theft
2
-17 Content Theft-Deterrent (Option)
2
-18 Vehicle Customization Settings
2
-27 Passlock

2-27 New Vehicle ªBreak-Inº
2
-28 Ignition Positions
2
-29 Starting Your Engine
2
-32 Engine Coolant Heater (Option)
2
-33 Automatic Transaxle Operation
2
-37 Parking Brake
2
-38 Shifting Into PARK (P)
2
-40 Shifting Out of PARK (P)
2
-40 Parking Over Things That Burn2
-41 Engine Exhaust
2
-42 Running Your Engine While You're Parked
2
-43 Tilt Wheel
2
-43 Turn Signal/Multifunction Lever
2
-49 Exterior Lamps
2
-52 Interior Lamps
2
-54 Mirrors
2
-60 Accessory Power Outlet
2
-61 Auxiliary Power Connection (Power Drop)
2
-62 OnStar
System (If Equipped)
2
-66 Power Sunroof (Option)
2
-67 HomeLink
Transmitter (Option)
2
-70 The Instrument Panel -- Your
Information System
2
-72 Instrument Panel Cluster
2
-75 Warning Lights, Gages and Indicators
2
-87 Message Center
2
-95 Driver Information Center (DIC) (Option)

2-2
Windows
CAUTION:
Leaving children in a vehicle with the windows
closed is dangerous. A child can be overcome by
the extreme heat and can suffer permanent
injuries or even death from heat stroke. Never
leave a child alone in a vehicle, especially with the
windows closed in warm or hot weather.

2-3
Power Windows
Both doors have power window switches located on
the armrest. The switches on the driver's door armrest
control each of the windows when the ignition is in ON,
ACC, or when Retained Accessory Power (RAP) is
active. See ªRetained Accessory Power (RAP)º in
the Index.Express
-Down Window
The driver's window switch has an express
-down
feature. This switch is labeled AUTO. Tap the rear of
the switch, and the driver's window will open a small
amount. If the rear of the switch is pressed and held,
the window will go all the way down.
To stop the window while it is lowering, press the front
of the switch. To raise the window, press and hold the
front of the switch.

2-4
Keys
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate the power windows or other
controls or even make the vehicle move. Don't
leave the keys in a vehicle with children.

2-5
This key is used for the
ignition, the doors and all
other locks.
If you need a new key, contact your dealer for
assistance. In an emergency, contact Roadside
Assistance. See ªRoadside Assistanceº in the
Index for more information.
NOTICE:
Your vehicle has a number of features that can
help prevent theft. But you can have a lot of
trouble getting into your vehicle if you ever lock
your key inside. You may even have to damage
your vehicle to get in. So be sure you have an
extra key.
If your vehicle is equipped with the OnStar system with
an active subscription and you lock your keys inside the
vehicle, OnStar may be able to send a command to
unlock your vehicle. See ªOnStarº in the Index for
more information.

2-6
Door Locks
CAUTION:
Unlocked doors can be dangerous.

Passengers -- especially children -- can
easily open the doors and fall out of a
moving vehicle. When a door is locked,
the handle won't open it. You increase the
chance of being thrown out of the vehicle in
a crash if the doors aren't locked. So, wear
safety belts properly and lock the doors
whenever you drive.

Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.

Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock the vehicle.
From the outside, use your key or the optional remote
keyless entry transmitter. From the inside, use the
manual or power door locks.
To unlock either front door from the outside with the
key, insert the key and turn it toward the front of the
vehicle. To lock either front door from the outside with
your key, insert the key and turn it toward the rear of
the vehicle.
To lock the door from the inside, push the manual lock
lever forward. To unlock the door, pull the lever rearward.

2-7
Power Door Locks
A power door lock switch is
located on each front door
above the armrest.
Press the top part of the switch to unlock both doors, or
press the bottom part of the switch to lock both doors.
If your vehicle has the optional content theft
-deterrent
system and it is armed, the power door lock switches
will be disabled. You must use your remote keyless
entry transmitter (if equipped) or your key to unlock the
doors when the system is armed.
Programmable Automatic Power Door Locks
Programmable automatic power door locks are a standard
feature that is intended to provide enhanced security and
convenience by automatically locking and unlocking doors.
Programmable Modes
Mode 1: No automatic door lock or unlock.
Mode 2: Automatic all
-door lock when the transaxle is
shifted out of PARK (P); no automatic door unlock.
Mode 3: Automatic all
-door lock when the transaxle is
shifted out of PARK (P); automatic unlock for the driver's
door only when the transaxle is shifted into PARK (P).
Mode 4: Automatic all
-door lock when the transaxle
is shifted out of PARK (P); automatic all
-door unlock
when the transaxle is shifted into PARK (P).
Before your vehicle was shipped from the factory, it was
programmed to Mode 4. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, see ªVehicle Customization Settingsº
in the Index.
Disconnecting the vehicle's battery for up to a year will
not change any previously programmed modes.

2-8 Lockout Protection Feature
To protect you from locking your key in the vehicle,
this feature stops the power door locks from locking
when the key is in the ignition and a door is open.
If a power lock switch is pressed when a door is open
and the key is in the ignition, both doors will lock and
then the driver's door will unlock. A chime will sound
continuously until both doors are closed.
Leaving Your Vehicle
If you are leaving the vehicle, take your keys, open your
door and set the locks from inside. Then get out and
close the door.
Remote Keyless Entry (If Equipped)
If your vehicle has this feature, you can lock and unlock
your doors or unlock your trunk from about 3 feet (1 m)
up to 30 feet (9 m) away using the remote keyless entry
transmitter supplied with your vehicle.
Your remote keyless entry system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation
of the device.
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.

If you're still having trouble, see your dealer or a
qualified technician for service.
