2002 CHEVROLET MONTE CARLO Owners Manual

2-65

Route Support: An advisor can provide
directions or guidance to most places you want
to go. In addition they can help you locate gas
stations, rest areas, ATM's, hospitals, hotels, stores,
eateries and more.

Ride Assist: An advisor can locate transportation
in the event that you are unable to drive.

Concierge Services: The concierge advisor can
obtain tickets, reservations, or help with vacation/trip
planning and other unique items or services.
OnStar System Limitations
Complete limitations can be found on the Subscriber
Services Agreement. In order to provide you with
excellent service, calls with the OnStar Center may
be monitored or recorded.
OnStar service is :

available in the 48 contiguous United States, Alaska,
Hawaii and Canada;

available when the vehicle is within the operating
range of a cellular provider;
subject to limitations caused by atmospheric
conditions, such as sever weather or topographical
conditions, such as mountainous terrain;

subject to cellular carrier equipment limitations.
Global positioning locating capabilities will not be
available if satellite signals are obstructed.
OnStar will not function if the vehicle's battery is
discharged or disconnected. It may also be inoperative
if the vehicle is in an accident and the OnStar or vehicle
electrical system components are damaged.
OnStar is the communication link between you and
existing governmental roadside providers. OnStar will
receive your call and use reasonable effort to contact an
appropriate provider. OnStar cannot promise that the
providers will respond in a timely manner or at all.
Assist Handle
An assist handle above the passenger door can be used
when getting out of your vehicle.
Garment Hooks
For your convenience, garment hooks are attached to the
rear trim near the headliner in the vehicle.

2-66
Power Sunroof (Option)
Your vehicle may have an express-open sunroof. It
includes a sliding and tilting glass panel and a sunshade.
The switch for this feature is located on the overhead
console if the vehicle is equipped with a Driver
Information Center (DIC). If the vehicle is not equipped
with a DIC, the sunroof switch is located on the roof
panel headliner.
To open the power
sunroof, press the
switch to the rear
twice and the
power sunroof
will fully open.
DIC Version Shown
The switch works only when the ignition is in ACC or
ON or when Retained Accessory Power (RAP) is active.Open/Express
-Open: To activate the express-open
feature, push the switch rearward. You can stop the
power sunroof before it is completely open by pushing
the switch forward.
Vent: Your sunroof also has a vent feature. It can
be activated from the closed sunroof position by
pushing the switch once rearward. To close, push
and hold the sunroof switch forward. When using
this feature the sunshade should be fully opened
in the rearward position.
The sunshade can be opened manually by sliding it
rearward or automatically by opening the power
sunroof. You will need to close the sunshade
manually by sliding it forward.
Close: To close the sunroof, push the switch forward
and hold until the sunroof motor stops, or release the
switch when the desired position has been reached.

2-67
HomeLink Transmitter
(Option)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the HomeLink Transmitter
Do not use the HomeLink Transmitter with any garage
door opener that does not have the ªstop and reverseº
feature. This includes any garage door opener model
manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.
It is recommended that a new battery be installed in
your hand
-held transmitter for quicker and more
accurate transmission of the radio frequency.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. Decide which one of the three channels (one of the
three HomeLink buttons) you want to program.
2. Press and hold the desired button on HomeLink
through Step 3.
3. When the HomeLink indicator light begins to blink
slowly, (this may take up to 30 seconds), hold the
hand
-held transmitter about 1 to 3 inches (3 to 8 cm)
from HomeLink and then press and hold the
transmitter button on the hand
-held transmitter.
Continue to hold both buttons until the indicator
light on HomeLink begins to flash rapidly
(this may take up to 90 seconds).

2-68
If you have trouble programming HomeLink, make
sure that you have followed the directions exactly as
described and that the battery in the hand
-held
transmitter is not weak. If you still cannot program it,
move the hand
-held transmitter to the left or right or
forward or backward or flip it upside down. HomeLink
may not work with older garage door openers that do
not meet current Federal Consumer Safety Standards.
If you cannot program the transmitter after repeated
attempts, refer to ªTraining a Garage Door Opener
with Rolling Codesº later in this section. or contact the
manufacturer of HomeLink at 1
-800-355-3515, or
on the internet at www.homelink.com.
Be sure to keep the original hand
-held transmitter in
case you need to erase and reprogram HomeLink.
Training a Garage Door Opener with a
ªRolling Codeº Feature (If Equipped)
If you have not previously programmed the hand-held
transmitter to HomeLink, see ªProgramming the
HomeLink Transmitterº listed previously. If you have
completed this programming already, you now need to
train the garage door opener motor head unit to
recognize HomeLink.1. Find the ªLearnº or ªSmartº button on the
garage door opener motor head unit. The exact
location and color will vary by garage door opener
brand. If you have difficulty finding the Learn or
Smart button, refer to your garage door opener
owner's manual or contact the manufacturer of
HomeLink at 1
-800-355-3515, or on the
internet at www.homelink.com.
Because of the steps involved, it may be helpful
to have another person assist in programming
the transmitter.
2. Press the Learn or Smart button on the garage door
opener motor head unit. An indicator light will begin to
flash when the motor head unit enters the training mode.
Following this step, you have 30 seconds to start Step 3.
3. Return to HomeLink in your vehicle and firmly
press and release the programmed HomeLink button
three times.
The rolling garage door opener should now recognize
the HomeLink. You may either use HomeLink or the
hand
-held transmitter to open the garage door.
If after following these instructions, you still have
problems training the garage door opener, contact the
manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.

2-69
Canadian Programming
Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after two seconds. In this case, you
should press and hold the HomeLink button
(see Steps 2 and 3 under Programming the HomeLink
Transmitter) while you press and repress (cycle) your
hand
-held transmitter every two seconds until
HomeLink is trained
Operating the HomeLink Transmitter
Press and hold the appropriate button on HomeLInk for
at least a half of a second. the indicator light will come
on while the signal is being transmitted.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons on HomeLink until the indicator
light begins to flash (approximately 20 seconds).
Release both buttons.
Resetting Defaults
To reset HomeLInk to default settings, hold down the
two outside buttons on HomeLink until the indicator
light begins to flash (approximately 20 seconds).
Continue to hold the buttons until the HomeLink
indicator light turns off and then release both buttons.
Accessories
Accessories for HomeLink are available from the
manufacturer. If you would like additional information
contact the manufacturer at 1
-800-355-3515, or
on the internet at www.homelink.com.

2-70
The Instrument Panel -- Your Information System

2-71
The main components of your instrument panel are listed here:
A. Instrument Panel Fuse Block
B. Turn Signal/Multifunction Lever
(behind steering wheel)
C. Audio Steering Wheel Controls (If Equipped)
D. Instrument Panel Cluster
E. Hazard Warning Flasher Button
F. Audio System
G. Air Vent
H. Exterior Lamps ControlI. Remote Trunk Release
J. Tilt Steering Wheel Lever
K. Hood Release
L. Cruising Steering Wheel Controls (If Equipped)
M. Ignition Switch
N. Automatic Transaxle Shift Lever
O. Climate Controls
P. Glove Box

2-72
Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know how fast
you're going, about how much fuel is in your tank and many other things you need to drive safely and economically.
3400 V6 Engine Cluster: United States version shown; Canada similar
