2002 Acura TL 3.2 Owner's Manual

The air cleaner element should be
cleaned or replaced according to the
time and distance recommendations
in the maintenance schedule.Loosen the two bolts with a Phillips-
head screwdriver. Remove the air
cleaner housing cover by lif ting and
pivoting it out of the loops.
Loosen the f our bolts by using a
Phillips-head screwdriver and
remove the air cleaner housing
cover.
Clean the air cleaner element by
blowing compressed air through it in
the opposite direction to normal air
f low. If you do not have access to
compressed air (such as a service
station), ask your Acura dealer to do
this service.
Follow the replacement procedure
for removal and reinstallation.
The air cleaner element is inside the
air cleaner housing on the driver’s
side of the engine compartment.
To replace it:
1.
On Premium model
On Premium model On Type S
Maint enance
A ir Cleaner Element
Cleaning (Severe Conditions)
Replacement
238
B BOOL LTT S
S
L
LOOO OPP B
BO
OL LTT S
S
00/12/25 14:32:42 31S0K630_241

Caref ully clean the inside of the
air cleaner housing with a damp
rag.Align the tabs on the battery side
and reinstall the air cleaner
housing cover, then tighten the
two bolts.
Remove the old air cleaner
element. Place the new air cleaner element
in the air cleaner housing.Reinstall the air cleaner housing
cover, tighten the four bolts.
2. 3. 4.5.
On Premium model
On Type S
A ir Cleaner Element
Maint enance239
T Ty
ypp e
e S
S A
A
I
IRR C
CLLEE A
A N
NE ER
R
E
E L
LEE M
M E
EN
NT T
A
A
I
IRR C
CLLEE A
A N
NE ER
R
E
E L
LEE M
M E
EN
NT T
P
P
r
reem m i
iuu m
m m
mo
od
de
ell
00/12/25 14:32:51 31S0K630_242

Disconnect the wire connector
f rom the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a f lat-tipped
screwdriver. Remove the cover on
the f ront cylinder bank by pulling
it straight up.
Clean up any dirt and oil that have
collected around the ignition coils.
The spark plugs in your car are a
special platinum-tipped design f or
longer lif e. The spark plugs should
be replaced according to the time
and distance recommendations in
the maintenance schedule.
1.
2.3.
Replacement
Spark Plugs
Maint enance240
H H
O
OL LDD I
INNG G
C
CL LIIPP L
LO
OC CKK T
TA
A B
B
00/12/25 14:33:01 31S0K630_243

Put the new spark plug into the
socket; then screw it into the hole.
Screw it in by hand so you do not
crossthread it.Torque the spark plug. (If you do
not have a torque wrench, tighten
the spark plug two-thirds of a turn
af ter it contacts the cylinder head.)
Tightening torque:
Use a wrench to remove the
hexagonsocketheadcapbolt
holding the ignition coil. Remove
the ignition coil by pulling it
straight out.
Remove the spark plug with
a f ive-eighths inch (16 mm) spark
plug socket.
4.
5.
6. 7.
CONT INUED
Spark Plugs
Maint enance241
H H
E
EX
X A
AG
GO ONN S
SOOC CKKEET
T H
HE
EA
A D
D C
CAA P
P B
BOOL LTT
13 lbf·ft (18 N·m , 1.8 kgf·m)
00/12/25 14:33:11 31S0K630_244

´
µ
´
µ
Push the wire connector onto the
ignition coil. Make sure it locks in
place. Install the ignition coil. Reinstall
the hexagon socket head cap bolt. Repeat this procedure f or the
other f ive spark plugs.
Reinstall the cover on the front
cylinder bank while putting its
mounting clip in the hole on the
passenger’s side. Secure the cover
by turning the heads of the two
holding clips one-quarter turn
clockwise with a f lat-tipped
screwdriver.
Spark Plug Gap: Spark Plug Gap:NGK:
DENSO:
8. 11.
10.
9. NGK:
DENSO:
Specif ications:
Spark Plugs
Maint enance
Type S
Premium model
242
0.04 in (1.1 mm)
PKJ20CR-M11 PZFR6E-11
0.04 in (1.1 mm) PKJ16CR-L11
PZFR5F-11
0
0.1 mm
0
0.1 mm
Tighten the spark plugs caref ully. A
spark plug that is too loose can
overheat and damage the engine.
Overtightening can cause damage to
the threads in the cylinder head.
00/12/25 14:33:22 31S0K630_245

Check the battery terminals for
corrosion (a white or yellowish
powder). To remove it, cover the
terminals with a solution of baking
soda and water. It will bubble up and
turn brown. When this stops, wash it
of f with plain water. Dry of f the
battery with a cloth or paper towel.
Coat the terminals with grease to
help prevent f uture corrosion.
Check the condition of your car’s
battery monthly. You should check
the color of the test indicator window,
and f or corrosion on the terminals.
Remove the battery cover.
Check the battery condition by
looking at the test indicator window
on the battery.
The label on the battery explains the
test indicator’s colors. Battery posts,
terminals and related accessories
contain lead and lead compounds.
CONT INUED
WARNING:
Wash hands af ter handling.
Battery
Maint enance243
T T E
ES
ST T I
INND DI
ICCA A T
TO
OR R W
WI INND DO
OW W
00/12/25 14:33:31 31S0K630_246

µ
If the terminals are severely cor-
roded, clean them with baking soda
and water. Then use a wrench to
loosen and remove the cables f rom
the terminals. Always disconnect the
negative ( ) cable f irst and recon-
nect it last. Clean the battery termi-
nals with a terminal cleaning tool or
wire brush. Reconnect and tighten
the cables, then coat the terminals
with grease. If you need to connect the battery to
a charger, disconnect both cables to
prevent damage to the car’s
electrical system.
Battery
Maint enance244
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
mechanic do the battery
maintenance.
00/12/25 14:33:37 31S0K630_247

If your car’s battery is disconnected
or goes dead, the audio system will
disableitself.Thenexttimeyouturn
on the radio you will see ‘‘Code’’ in
the f requency display. Use the
Preset buttons to enter the five-digit
code (see page ).If your car’s battery is disconnected
or goes dead, all stored driving
positions will be lost. To store the
driving positions again, see the
storingprocedureonpage .
The Navigation System will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
Navigation System Owner’s Manual.
151
96
Cars with Navigation System
Battery
Maint enance245
Charging the battery with the cables
connected can seriously damage your
car’s electronic controls. Detach the
battery cables bef ore connecting the
battery to a charger.
