Use a gauge to measure the air
pressure at least once a month. Even
tires that are in good condition may
lose one to two psi (10 to 20 kPa, 0.1
to 0.2 kgf /cm ) per month.
Remember to check the spare tire at
thesametimeyoucheckallthe
other tires.The following chart shows the
recommended cold tire pressures f or
most normal driving conditions and
speeds. Tire pressures f or high
speed driving are the same as f or
normal driving.
These pressures are also given on
thetireinformationlabelonthe
driver’s doorjamb. Thecompactsparetirepressureis:
If you check the pressure when the
tires are hot (the car has been driven
several miles), you will see readings
4 to 6 psi (30 to 40 kPa, 0.3 to 0.4
kgf /cm ) higher than the cold
reading. This is normal. Do not let
air out to match the specified cold
pressure. The tire will be
underinf lated.
Youshouldgetyourowntire
pressure gauge and use it whenever
you check your tire pressures. This
will make it easier f or you to tell if a
pressure loss is due to a tire problem
and not due to a variation between
gauges.
Check the pressure in the tires when
they are cold. This means the car
has been parked f or at least three
hours. If you have to drive the car
bef ore checking the tire pressure,
the tires can still be considered
‘‘cold’’ if you drive less than 1 mile
(1.6 km).
Tire Size Cold Tire Pressure
for Normal Driving
Front/Rear:
Recommended T ire Pressures f orNormal Driving
Tires
Maint enance254
60 psi (420 kPa , 4.2 kgf/cm)
30 psi (210 kPa , 2.1
kgf/cm
)
P225/55R16 94V
01/09/28 20:07:02 31SZ3660_257

Tubeless tires have some ability to
self -seal if they are punctured.
However, because leakage is of ten
very slow, you should look closely
for punctures if a tire starts losing
pressure.Every time you check inf lation, you
should also examine the tires f or
damage, f oreign objects, and wear.
Youshouldlookfor:
Bumps or bulges in the tread or
side of the tire. Replace the tire if
youfindeitherof theseconditions.
Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see f abric or cord.
Excessive tread wear. Your car’s tires have wear indicators
molded into the tread. When the
tread wears down to that point, you
will see a 1/2 inch (12.7 mm) wide
band running across the tread. This
shows there is less than 1/16 inch
(1.6 mm) of tread lef t on the tire. A
tire that is this worn gives very little
traction on wet roads. You should
replace the tire if you can see the
tread wear indicator in three or more
places around the tire.
Inspection
Tires
Maint enance255
I IN
ND DI
ICCA A T
TO
OR R L
LOOC CAA T
TI
IOON N M
MA
AR
RKKSS
T
T R
RE EA
A D
D W
WE EA
A R
R I
INND DI
ICCA A T
TO
OR RSS
01/09/28 20:07:12 31SZ3660_258

In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
The tires were properly balanced by
the factory. They may need to be
rebalanced at some time bef ore they
are worn out. Have your dealer
check the tires if you f eel a consis-
tent vibration while driving. A tire
should always be rebalanced if it is
removed f rom the wheel f or repair. To help increase tire lif e anddistribute wear more evenly, you
should have the tires rotated every
7,500 miles (12,000 km). Move the
tires to the positions shown in the
chart each time they are rotated.
Make sure the installer balances the
wheels when you have new tires
installed. This increases riding
comf ort and tire lif e. Your car’s
original tires were dynamic or ‘‘spin’’
balanced at the f actory. For best
results, have the installer perf orm a
dynamic balance.
Maintenance T ire Rotation
Tires
Maint enance256
( (
F
Fo o r
r N
No on
n-
-d
d i
irre ec cttiioo n
na
all
T
T i
irre es s a
ann d
d W
Wh he
eeellss) ) (
(
F
Fo o r
r D
D i
irre ec cttiioo n
na
all
T
T i
irre es s a
ann d
d W
Wh he
eeellss) )
F
Fr
roo n
nt
t F
Frroo n
nt
tImproper wheel weights can damage
your vehicle’s aluminum wheels. Use
only Genuine Acura wheel weights f or
balancing.
01/09/28 20:07:23 31SZ3660_259

When shopping f or replacement
tires, you may find that some tires
are ‘‘directional.’’ This means they
are designed to rotate only in one
direction. If you use directional tires,
they should be rotated only front-to-
back.The tires that came with your car
were selected to match the perform-
ance capabilities of the car while
providing the best combination of
handling, ride comf ort, and long lif e.
Youshouldreplacethemwithradial
tires of the same size, load range,
speed rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall). Mixing radial and
bias-ply tires on your car can reduce
its braking ability, traction, and
steering accuracy. It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, then replace the two
f ront tires or the two rear tires as a
pair. Replacing just one tire can
seriously af f ect your car’s handling.
CONT INUED
Replacing T ires and Wheels
Tires
Maint enance257
Installing improper tires on your
car can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
01/09/28 20:07:29 31SZ3660_260

´
Tires that are marked ‘‘M S’’ or
‘‘All Season’’ on the sidewall have an
all-weather tread design. They
should be suitable f or most winter
driving conditions. Tires without
these markings are designed f or
optimum traction in dry conditions.
They may not provide adequate
perf ormance in winter driving.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
Wheels:
Tires:
See page f or inf ormation about
DOT Tire Quality Grading.
If you ever need to replace a wheel,
make sure you use an identical style
aluminum alloy wheel that originally
came on your Acura. Replacement
wheels are available at your Acura
dealer. The ABS and VSA system work by
comparing the speed of the wheels.
When replacing tires, use the same
size originally supplied with the car.
Tire size and construction can af f ect
wheel speed and may cause the
system to work inconsistently.314 Winter Driving
Wheels and T ires
Tires
Maint enance258
16x7JJ
P225/55R16 94V
01/09/28 20:07:38 31SZ3660_261

If you mount snow tires on your
Acura, make sure they are radial
tires of the same size and load range
as the original tires. Mount snow
tiresonallfourwheelstobalance
your car’s handling in all weather
conditions. Keep in mind the traction
provided by snow tires on dry roads
may not be as high as your car’s
original equipment tires. You should
drive cautiously even when the roads
areclear.Checkwiththetiredealer
f or maximum speed recommen-
dations.Because your Acura has limited tire
clearance, mount only SAE Class ‘‘S’’
cable-type traction devices on the
front tires. Use traction devices only
when required by driving conditions
or local laws. Make sure they are the
correct size f or your tires.
Metal link-type ‘‘chains’’ should not
be used. No matter how tight they
seem to be installed, they can come
into contact with the body and
suspension, causing serious damage.When installing cables, f ollow the
manuf acturer’s instructions and
mount them as tightly as you can.
Drive slowly with them installed. If
youhearthemcomingincontact
with the body or chassis, stop and
investigate. Make sure the cables are
installed tightly, and that they are
not contacting the brake lines or
suspension. Remove them as soon as
you begin driving on cleared roads.
Snow T ires
T ire Chains
Tires
Maint enance259
Traction devices that are the wrong
size or improperly installed can
damage your car’s brake lines,
suspension, body, and wheels. Stop
driving if they are hitting any part of
the car.
01/09/28 20:07:47 31SZ3660_262

Check the operation of your car’s
exterior lights at least once a month.
A burned out bulb can create an
unsaf e condition by reducing your
car’s visibility and the ability to
signal your intentions to other
drivers.
Lights
Maint enance260
F FRRO ON NTT F
FOOG G L
LIIGGH HT
T L
LO
OW W B
BEEA
A M
M H
HE
EA
A D
DL
LIIGGH HT
T
T
T U
UR RNN S
SIIGGN NAAL
L//
P
P A
A R
RKKIINNG G L
LIIGGH HT
T S
SI
IDD E
E M
M A
AR
RKKEER
R L
LIIGGH HT
T
H
H
I
IGGH H B
BEEA
A M
M H
HE
EA
A D
DL
LIIGGH HT
T
01/09/28 20:07:53 31SZ3660_263

Check the f ollowing:Headlights (low and high beam)
Fog lights
Parking lights
Taillights
Brake lights
Turn signals
Back-up lights
Hazard light f unction
License plate light
Side marker lights
High-mount brake light
Daytime running lights (Canadian
models)
If youfindanybulbsareburnedout,
replace them as soon as possible.
Refer to the chart on page to
determinewhattypeof replacement
bulb is needed. 313
Lights
Maint enance261
H H
I
IGGH H-
-M
M O
OUUNNTT B
BRRAA K
KEE L
LIIGGH HT
T
B
BA A C
CKK--U
UP P L
LIIGGH HT
T
L
LI
ICCE EN
NS SEE P
PL
LAA T
TE
E
L
LI IGGH HT
TS
S
S
STTO
OP P/
/T
T A
A I
ILL L
LIIGGH HT
TS
S
T
T
U
UR RNN S
SIIGGN NAAL
L L
LIIGGH HT
T
