Rear lights Rear wing lights
1 - Direction indicators: PY 21 W (amber).
2 - Brake lights/side lights: P21/5 W.
 Detach the luggage net.
 Lift the boot carpet with the lifting hook. Secure this hook behindthe boot seal.
 Unclip the lower part of the silltrim, then dislodge it by pullingupwards.
 Remove the plastic retainer clipsecuring the side trim to the
floor.
Unclip the side trim.
 Remove the two butterfly nutssecuring the light.
 Remove the eyelet.
 Take out the lamp.
 Turn the lamp holder a quarterturn.
 Change the faulty bulb.
 Lock the bulb holder in place.When refitting it, ensure that thelamp is correctly positioned andsecured.
PRACTICAL INFORMATION
145Direction indicator repeaters:
WY 5 W (amber).
 Push the repeater forwards orbackwards and release the
assembly.
 Hold the connector and turn thetransparent cover a quarter turn.
 Change the bulb.
Amber coloured bulbs (direction indicators andside repeaters) must bereplaced with bulbs ofidentical specification and
colour.

15-07-2002
146PRACTICAL INFORMATION
Boot lid lights 1 - Reversing lights: P 21 W.
2 - Fog lamps: P 21 W.
 Remove the three plastic retain- er clips securing the cover trim(those nearest to the lamp).
 Move aside the trim.
Turn the bulb holder a quarterturn.
 Change the faulty bulb. Number plate lights:
W 5 W.
 Remove the transparent coverusing a screwdriver blade.
 Change the faulty bulb.

15-07-2002
PRACTICAL INFORMATION147
Correct Incorrect
Pliers A
CHANGING A FUSE The fuse boxes are located under the fascia panel and in the enginecompartment.
 The replacement fuses and pliersAare fixed to the inside of the fas-
cia panel fuse box cover.
Removing and fitting a fuse Before changing a fuse, you must establish the cause of the fault andhave it put right.  Use pliers A.
Always change a faulty fuse for one of the same rating. Fascia panel fuse box
 Loosen the screw a quarter turnwith a coin and tilt the cover toaccess the fuses.
Fuse no. Rating Functions R Replacement fuses.
1 30A Locking / deadlocking.
2 20A Radio amplifier.
3 30A Windscreen wash.
4 30A Rear window switches on rear doors.
5 15A Electronic immobiliser, monochrome screen or colour screen control unit, instrument panel, air conditioning control unit,
audio system / telephone.
6 10A Rear right brake light.

15-07-2002
The electrical system of your vehicle is designedto operate with standardor optional equipment. Before installing other
electrical equipment or acces- sories on your vehicle, contact a
PEUGEOT dealer. PEUGEOT will not accept respon- sibility for the cost incurred inrepairing your vehicle or for rectify-ing the malfunctions resulting fromthe installation of accessories notsupplied and not recommended byPEUGEOT and not installed inaccordance with its instructions, inparticular where the equipment in question consumes more than10 milliamperes. *Maxi fuses provide additional protection for electrical systems.All work must be carried out by
your PEUGEOT dealer.
PRACTICAL INFORMATION 149
Engine compartment fuses Fuse box
To access the fuses located in the engine compartment (next to the bat-tery) :
 remove the style cover and unclip
the cover.
After carrying out the work, close the cover very carefully and
replace the style cover.
Fuse N¡ Rating Functions 1* 70 A Built-in systems interface ( heated rear screen - heated exterior mirrors - windscreen wiper -screenwash - headlamp wash).
2* 50 A Fan.
3* 50/60 A ESP pump motor / ABS hydraulic unit.
4* 40 A Air conditioning blower.
5 20 A Horn - Horn control relay.
6 20 A Left front and rear heated seats.
7 20 A Right front and rear heated seats.
8* 70 A Built-in systems interface.
9* 30 A Passenger electric seat.

15-07-2002
Fuse N¡ RatingFunctions
10* 20 AAutomatic headlamp lighting control unit.
11* 70 A Built-in systems interface.
12* 70 A Ignition supply (+ve accessories / ignition controlled +ve).
13* 20 A Automatic headlamp lighting control unit.
14 15 A Double injection relay supply.
15* - Not used.
16* - Not used.
17* 30 A ESP hydraulic unit.
18 30 A Ignition supply (+ starter).
19 20 A Variable suspension control unit.
20 10 A Fan unit relay - Cruise control safety switch - Manual gearbox clutch switch - Manual gearbox reversing lights switch or automatic gearbox multi-function switch -
Automatic headlamp lighting control unit - Vehicle speed sensor - Coolant level sensor -
Water in diesel sensor - Power switch control unit relay.
21 5 A Automatic gearbox control unit - Automatic gearbox multi-function switch.
22 25 A ESP control unit.
23 15 A Diesel heating.
24 5 A Engine management control unit Ð Dual control control unit.
25 10 A Fuel pump.
26 30 A Driver's seat memory control unit.
27 25 A Double injection relay supply.
28 10 A Throttle housing de-icing resistor, Intake pilot solenoid valve - Flow meter - Piston de-activator injectionpump - Oil heating.
29 30 A Air pump, diesel additive control unit - Diesel additive injector.
30 - Cannot be used.
31 5 A Automatic gearbox shift lock.
32 10 A ESP or ABS control unit.
33 15 A Automatic gearbox control unit - Automatic gearbox multi-function switch (except reversing lights) - Automaticgearbox sequential control.
34 5 A Oxygen sensors - Exhaust gas recirculation solenoid valve, Exhaust gas recirculation throttle solenoid valve -
Turbo pressure regulation solenoid valve.
PRACTICAL INFORMATION
150

15-07-2002
PRACTICAL INFORMATION147
Correct Incorrect
Pliers A
CHANGING A FUSE The fuse boxes are located under the fascia panel and in the enginecompartment.
 The replacement fuses and pliersAare fixed to the inside of the fas-
cia panel fuse box cover.
Removing and fitting a fuse Before changing a fuse, you must establish the cause of the fault andhave it put right.  Use pliers A.
Always change a faulty fuse for one of the same rating. Fascia panel fuse box
 Loosen the screw a quarter turnwith a coin and tilt the cover toaccess the fuses.
Fuse no. Rating Functions R Replacement fuses.
1 30A Locking / deadlocking.
2 20A Radio amplifier.
3 30A Windscreen wash.
4 30A Rear window switches on rear doors.
5 15A Electronic immobiliser, monochrome screen or colour screen control unit, instrument panel, air conditioning control unit,
audio system / telephone.
6 10A Rear right brake light.

15-07-2002
PRACTICAL INFORMATION
148
Fuse no. Rating Functions
7 10 A Switches, rear lighter illumination, front courtesy light, rear courtesy light, rear lighter, number plate lighting, headlamp height adjustment.
8 10 A Diagnostic connector, headlamp height adjustment control unit, HF locking receiver,
passenger compartment air temperature sensor, HF tyre under-inflation receiver.
9 20 A Headlamp wash.
10 20 A Glove box lighting, front lighter, front and rear courtesy light, electrochrome interior mirror,electric exterior mirrors.
11 5 A Control unit for automatic lighting of headlamps, air bags control unit, safety relay for automatic lighting of headlamps.
12 30 A Rear window switches on driver's pad, rear windows.
13 30 A Windscreen wiper.
14 15 A Not used.
15 15 A Driver's door pad, passenger's door pad.
16 15 A Rear lighter.
17 5 A Heated exterior mirrors.
18 15 A Rear left brake light, additional brake light.
19 10 A Parking assistance control unit, navigation control unit.
20 15 A Alarm siren, monochrome screen or colour screen control unit, HF receiver, audio system /telephone, monochrome or colour navigation control unit, diesel additive control unit.
21 15 A Dignostic connector, caravan socket, trailer sidelights relay.
22 15 A Diesel additive control unit, driver's seat memory control unit, driver's door pad, passenger's door pad.
23 30 A Driver's window, passenger's window, sunroof safety auto-reverse, passenger window swit-ch on driver's door pad andpassenger's door pad.
24 10 A Rear fog lamp.
25 40 A PARC shunt.
26 40 A Heated rear screen, radio aerial amplifier.

15-07-2002
PRACTICAL INFORMATION151
CHANGING A WINDSCREEN WIPER BLADE Placing the wiper blades in the maintenance position  Less than one minute after switch-
ing off the ignition, activate thewindscreen wiper stalk to positionthe blades in the centre of thewindscreen (maintenance posi-tion).
Replacing a blade  Lift the arm, then unclip the bladeand remove it.
 Fit the new blade and fold downthe arm.
To park the blades, switch on theignition and operate the wind-screen wiper stalk.
REMOVING A MAT When removing a mat on the driver's or passenger's side, push back theseat as far as possible and removethe clips.
To remove a rear mat, push the cor- responding front seat forward andremove the clip. On refitting, position the mat and press firmly to refit the securing clips.
LOAD REDUCTION When driving, certain functions (heated rear screen, heating systemfor passenger compartment of diesel
vehicles, etc.) may be switched off
temporarily, depending on the levelof battery charge. Reactivation of the functions on standby is automatic, as soon as thebattery permits.
A flat battery prevents the engine from starting.
ECONOMY MODE FUNCTION After the engine has stopped, certain
functions (windscreen wiper, electricwindows, sunroof, rear electric blind,electric seats, audio equipment, tele-phone etc) can only be used for thir-ty minutes, to prevent discharging
the battery.
Once the thirty minutes are over, the message
"Economy mode active"
appears on the multiÐfunction dis-play and the active functions are put
on standby. These functions are automaticallyreactivated next time the vehicle isdriven. Note:
if the telephone is being used
when economy mode starts, it will still be possible to finish the call.
