2001 SUBARU IMPREZA Owners Manual

11-2Specifications
These sp ec ific ations are sub jec t to c hang e without
notic e.
Dimensions
Overall leng th 172.2 in. (4,375 mm)
Overall wid th 67.1 in. (1,705 mm)
Overall heig ht 56.3 in. (1,430 mm)* 1
55.5 in. (1,410 mm)
Ground c learanc e 6.5 in. (165 mm)* 1
5.7 in. (145 mm)
Front tread 57.5 in. (1,460 mm), 57.9 in. (1,470 mm)*2
Rear tread 57.1 in. (1,450 mm), 57.5 in. (1,460 mm)*2
Wheelb ase 99.2 in. (2,520 mm)
* 1
: OUTBACK
* 2
: RS
Maximum load limits
Gross vehic le weig ht rating See the c ertific ation la b el attac hed
Gross axle weig ht rating to the d river ’s d oor jamb .
Engine
2500 c c Eng ine mod el EJ251
Eng ine typ e Horizontally op p osed , liq uid c ooled 4 c ylind er,
4 stroke g asoline eng ine
Eng ine d isp lac ement 149.9 c u in (2,457 c c )
Bore 3.92 in. (99.5 mm)
Stroke 3.11 in. (79.0 mm)
Comp ression ratio 10.0 : 1
Firing ord er 1 – 3 – 2 – 4

Specifications11-3
–
CONTINUED –
2200 c c
Eng ine mod el EJ222
Eng ine typ e Horizontally op p osed , liq uid c ooled 4 c ylind er,
4 stroke g asoline eng ine
Eng ine d isp lac ement 135.0 c u in (2,212 c c )
Bore 3.81 in. (96.9 mm)
Stroke 2.95 in. (75.0 mm)
Comp ression ratio 10.0 : 1
Firing ord er 1 — 3 — 2 — 4
Electrical system
Battery Typ e MT: 55D23L, AT: 75D23L
Reserve c ap ac ity MT: 99 min., AT: 118 min.
Cold c ranking amp ere MT: 356 amp ., AT: 520 amp .
Alternator 12V - 75A
Sp ark p lug s BKR6E-11 (NGK) RC10YC4, RC8YC4 (CHAMPION)
K20PR-U11 (NIPPONDENSO)
Sp ark p lug g ap 0.039 to 0.043 in. (1.0 to 1.1 mm) Capacities
2.5 Liter mod els Fuel tank 15.9 US g al (60 liter, 13.2 Imp g al)
Eng ine oil 4.2 US q t (4.0 liter, 3.5 Imp q t)
Transmission oil 3.7 US q t (3.5 liter, 3.1 Imp q t)
Automatic transmission fluid 9.8 US q t (9.3 liter, 8.2 Imp q t)
AT d ifferential g ear oil 1.3 US q t (1.2 liter, 1.1 I mp q t)
AWD rear d ifferential g ear oil 0.8 US q t (0.8 liter, 0.7 Imp q t)
Power steering fluid 0.7 US q t (0.7 liter, 0.6 Imp q t)
Eng ine c oolant 6.2 US q t (5.8 liter, 5.2 Imp q t)
2.2 Liter mod els Fuel tank 15.9 US g al (60 liter, 13.2 Imp g al)
Eng ine oil 4.2 US q t (4.0 liter, 3.5 Imp q t)

11-4Transmission oil (AWD) 3.7 US q t (3.5 liter, 3.1 Im
p q t)
Automatic transmission fluid 8.9 US q t (8.4 liter, 7.4 Imp q t)
AT d ifferential g ear oil 1.3 US q t (1.2 liter, 1.1 I mp q t)
AWD rear d ifferential g ear oil 0.8 US q t (0.8 liter, 0.7 Imp q t)
Power steering fluid 0.7 US q t (0.7 liter, 0.6 Imp q t)
Eng ine c oolant 6.2 US q t (5.8 liter, 5.2 Imp q t)
Tires
Typ e Steel b elted rad ial, Tub eless
Size Front and rear P195/60R15 P205/60R15*3
P205/55R16* 2
Sp are T135/70D16
Pressure Front 32 p si (2.2 kg /c m 2
, 220 kp a)
Rear 29 p si (2.0 kg /c m 2
, 200 kp a)
Sp are 60 p si (4.2 kg /c m 2
, 420 kp a)
Wheel size Front and rear 16 x 7JJ* 2
15 x 6JJ
Sp are 16 x 4T
Wheel alig nment Toe Front 0 0.12 in. (0 3 mm)
Rear 0 0.12 in. (0 3 mm)
Camb er Front –0 *4
, –0 25 ’* 5
Rear –0 55 ’, –1 10 ’* 2
* 2
: RS
* 3
: OUTBACK
* 4
: 2.2 liter
* 5
: 2.5 liter

Specifications11-5
–
CONTINUED –
Fuses and circuits
Fuse panel located behind the coin tray
HS0224
12 34 5 6
78 9Q WE TY UI OP
R
Fuse panel
Fuse ratingCircuit
115A Heater fan
215AHeater fan
3Emp ty
420AFront ac c essory p ower soc ket
Cig arette lig hter
Remote c ontrolled rear view mirrors
510ATail lig ht
Parking lig ht
615ASRS airb ag
715AFog lig ht
820AABS solenoid
915ARad io
Cloc k

11-6Fuse panel Circuit
Fuse rating
10Emp ty
1115AEng ine ig nition system
SRS airb ag
1210AIllumination b rig htness c ontrol
13Emp ty
1415AAT shift loc k unit
ABS c ontrol
Cruise c ontrol
1520AWind shield wip er and washer
Rear wind ow wip er and washer
1620ABrake lig ht
1715AAir c ond itioner
1815ABac kup lig ht
Turn lig ht
SRS airb ag system warning lig ht
1920ARear ac c essory p ower soc ket
Seat heater

Specifications11-7
–
CONTINUED –

Fuse panel located in the engine compartment
HS0225Fusible link FWD socket
A S
K L Z X
G H J
DF
Fuse panel
Fuse ratingCircuit
2020A Rad iator c ooling fan (Main)
2120ARad iator c ooling fan (Sub )
2220ARear wind ow d efog g er
2315AHazard warning flasher
Horn
2415APower d oor loc k
2510AAutomatic transmission c ontrol unit
2610AAlternator
2715AHead lig ht (rig ht sid e)
2815AHead lig ht (left sid e)
2920ALig hting switc h
3015ACloc k
Interior lig ht

11-8Bulb chart
Description Wattage Bulb No.
Head lig ht 12V-60/55W HB2 (H4)
Front turn sig nal 12V-27W 1156
Sid e marker/Parking 12V-3.8W 194
Sid e turn sig nal 12V-3.8W 194
Rear c omb ination lig ht
Brake/tail and Marker 12V-27/8W 1157
Turn sig nal 12V-27W 1156
Bac k-up 12V-27W 1156
Hig h mount stop lig ht (Sed an) 12V-18W 921
Hig h mount stop lig ht (Wag on) 12V-13W 912
Lic ense p late lig ht 12V-3.8W 194
Interior lig ht 12V-8W —
Fog lig ht 12V-55W H3

Specifications11-9
–
CONTINUED –
Vehicle identification
HG0196
1Chassis numb er
2 Emission c ontrol lab el
3 Vac uum hose p ip ing lab el
4 Vehic le id entific ation numb er p late
5 Tire p lac ard
6 Certific ation p late
7 Mod el numb er p late
