2001 PONTIAC BONNEVILLE display

2-99
Automatic Door Locks
The door lock modes when shifting in and out of
PARK (P), can be changed through the DIC. You can
change these modes using different selections of the
following DIC displays:

AUTO DOOR LOCKS
- OFF/ON

UNLOCK
- OFF/ON

UNLOCK
- KEY OFF/PARK

DOOR TO UNLOCK
- DRIVER/ALL
If you choose OFF for AUTO DOOR LOCKS,
your door locks will operate normally with no
automatic feature.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and KEY OFF, your doors will lock every
time you shift out of PARK (P), and the doors will
unlock every time you stop and turn the ignition to OFF.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and PARK, your doors will lock every time
you shift out of PARK (P), and the doors will unlock
every time you stop and shift into PARK (P).If you choose ON for AUTO DOOR LOCKS, and OFF
for UNLOCK, your doors will lock every time you shift
out of PARK (P), and there will be no automatic door
unlock when shifting back into PARK (P).
If you choose ON for UNLOCK and DRIVER for
DOOR TO UNLOCK, only the driver's door will
automatically unlock when shifting into PARK (P) or
turning the key to OFF.
If you choose ON for UNLOCK and ALL for DOOR
TO UNLOCK, all doors will automatically unlock when
shifting into PARK (P) or turning the key to OFF.
To change modes do the following:
1. Move the arrow on the display between the
selections by pressing the RESET button.
2. Once you have made your selection, press the
SELECT button and your choice will be retained
in memory.
See ªAutomatic Door Locksº in the Index for more
information about this feature.

2-100
Window Lockout Personalization
The number of passenger windows locked out by the
window LOCK switch can be programmed through
the DIC.
If you choose R + PASS, all three passenger window
switches will be inactive when the window LOCK
switch is enabled.
If you choose REAR, only the two rear passenger
window switches will be locked out when the window
LOCK switch is enabled.
To change modes do the following:
1. Move the arrow on the display between R + PASS
and REAR by pressing the RESET button.
2. Once you have made your selection, press the
SELECT button. Your choice will be retained in memory.
For more information on this feature, see ªWindow
Lockº in the Index.Security Feedback
By choosing different combinations of these selections,
you can choose the type of transmitter activated
feedback when locking and unlocking your vehicle with
your transmitter. Each time you make a selection by
pressing the RESET button, press the SELECT button to
record your choice.

KEYLESS FEEDBACK
- OFF/ON

LIGHTS FEEDBACK
- OFF/ON

HORN FEEDBACK
- OFF/ON
If you choose ON for KEYLESS FEEDBACK you will
also need to choose LIGHTS and/or HORN FEEDBACK.
You can select the following modes:

If you choose OFF for KEYLESS FEEDBACK, you
will receive no security feedback when locking or
unlocking your vehicle.

If you choose ON for KEYLESS FEEDBACK and
ON for LIGHTS FEEDBACK, the exterior lamps
will flash twice when unlocking your vehicle and
once when locking your vehicle.

2-101

If you choose ON for KEYLESS FEEDBACK and
ON for HORN FEEDBACK, your horn will chirp
when locking and unlocking your vehicle.

If you choose ON for KEYLESS, LIGHTS and
HORN FEEDBACK, your exterior lamps will flash
twice at the first unlock button press, your exterior
lamps will flash twice and your horn will chirp once
at the second unlock button press, and the exterior
lamps will flash once and the horn will chirp once
when locking your vehicle.
For more information on this feature, see ªSecurity
Feedbackº in the Index.
Delayed Locking
The delayed locking feature, which delays the actual
locking of the vehicle, can be made active or inactive
through the DIC. When DELAYED LOCKING
-
OFF/ON appears on the display, use the RESET button
to toggle the arrow between OFF and ON. When you
have made your choice, press the SELECT button to
record your selection.
For more information on this feature, see ªDelayed
Lockingº in the Index.Perimeter Lighting Personalization
When the button with the unlock symbol on the
transmitter is pressed, the Daytime Running Lamps
(high
-beams at reduced intensity), parking lamps and
back
-up lamps will turn on if it is dark enough
according to the Twilight Sentinel.
You can control activation of this feature by choosing
OFF or ON when the PERIMETER LIGHTS choice is
displayed on the DIC. Make your choice by pressing the
RESET button and record your choice by pressing the
SELECT button. You will then be prompted to choose a
TIMEOUT period.
The PERIMETER LIGHTS TIMEOUT feature can be
changed to desired setting by using the RESET button to
toggle from 5 to 30 seconds. Each toggle will increase
the time by five seconds. Once the desired timeout is
displayed, press select to record your choice and move
on to the next personalization feature.
For more information on this feature, see ªPerimeter
Lightingº in the Index.

2-102
Memory Seat Recall (If Equipped)
This feature recalls the position of your seat. When this
feature is active, the memory seat and mirror positions
will be recalled for the identified driver when the remote
keyless entry transmitter is used to enter the vehicle.
You can program this feature to be active by choosing
ON when the SEAT RECALL choice appears, or
inactive by choosing OFF when the SEAT RECALL
choice appears on the DIC. Make your choices by
pressing the RESET button and store them to memory
by pressing the SELECT button.
You can also program this feature to recall your memory
seat position or the exit seat position.

Memory Position: Choose ON when the SEAT
RECALL choice appears and then choose MEMORY
when the RECALL POSITION choice appears.

Exit Position: Choose ON when the SEAT RECALL
choice appears and then choose EXIT when the
RECALL POSITION choice appears. The seat will
move when you enter the vehicle after unlocking it
with a remote keyless entry transmitter. This will
allow for easy entry.
For more information on this feature, see ªMemory Seat
and Mirrorsº in the Index.Parallel Park Assist (If Equipped)
The parallel park assist mirror, which tips the passenger
mirror while the vehicle is in REVERSE (R), can be
made active or inactive through the DIC. When TILT
MIRROR
- OFF/ON appears on the display, use the
RESET button to toggle the arrow between OFF and
ON. When you have made your choice, press the
SELECT button to record your selection. For more
information on this feature, see ªMirrorsº in the Index.
Driver ID
This feature displays the DRIVER ID, as identified by
the DIC. If this feature is ON, the DRIVER ID will be
displayed every time the ignition is turned on. If the
DRIVER ID is OFF, the DRIVER ID can be displayed
by pressing either a button on the remote keyless entry
transmitter or a memory seat button.

2-103
Head-Up Display (Option)
CAUTION:
If the HUD image is too bright, or too high in
your field of view, it may take you more time to
see things you need to see when it's dark outside.
Be sure to keep the HUD image dim and placed
low in your field of view.
If you have the optional Head-Up Display (HUD), you
can see some of the driver information also available on
your instrument panel cluster. The information may be
displayed in English or metric units and appears as
a reflection on the windshield. The HUD shows
the following:

Speedometer Reading

Turn Signal Indicators

High
-beam Indicator Symbol

CHECK GAGES Message (for low oil pressure,
high coolant temperature, low oil level, high/low
battery, brake, ABS and air bag.)

Low Fuel Warning Symbol

Radio Frequency and Playback Mode

2-104
HUD shows these images when they are lighted on the
instrument panel.
The speedometer may display a difference of 1.5 mph
(2.4 km/h) from the HUD image. This is normal.
When the ignition key is turned to ON, all possible
HUD images will come on, then the HUD will
operate normally.If you never look at your instrument panel cluster, you
may not see something important, such as a warning
light. So be sure to scan your displays and controls and
the driving environment just as you would in a vehicle
without HUD.
NOTICE:
Although the HUD image appears to be near
the front of the vehicle, do not use it as a parking
aid. The HUD was not designed for that purpose.
If you try to use it that way, such as in a
parking lot, you may misjudge distance
and run into something.

3-4
When the weather is cool or damp, operating in
RECIRC for extended periods of time may cause
fogging of the vehicle's windows. To clear the fog,
switch back to outside air by turning off RECIRC, select
either DEFOG or FRONT defrost mode and increase the
fan speed. To avoid refogging of the windows, minimize
your use of RECIRC under these conditions and turn the
A/C on to help dehumidify the air.
A/C Button
A/C: Press this button to turn the air conditioning
compressor on and off. The system will cool and
dehumidify the air inside your vehicle. If your comfort
control system is off, you can also turn it back on in
PANEL mode by selecting the A/C button.
Even though A/C is not selected, in FRONT defrost
mode the A/C compressor will run automatically at
temperatures over approximately 40
F (4
C) to improve
windshield clearing performance.
Electronic Climate Control System (Option)
Temperature Knob (Driver's Side)
The driver's side knob changes the temperature of the
air coming through the system on the driver's side.
Turn the knob toward the blue area to decrease the set
temperature. Turn the knob toward the red area to
increase the set temperature. When this knob is adjusted,
the word DRIVER will be displayed under the set
temperature. When the passenger's set temperature is
not active, this knob controls both the driver's and
passenger's side, and both DRIVER and PASS will be
displayed under the set temperature.

3-5
Temperature Knob (Passenger's Side)
The passenger's side knob changes the temperature of
the air coming through the system on the passenger's
side of the vehicle. Turn the knob toward the blue area
to decrease the set temperature. Turn the knob toward
the red area to increase the set temperature. When this
knob is adjusted, only the word PASS will be displayed
under the set temperature.
Fan Button
The button with the fan symbol allows you to manually
adjust the fan speed. Press the HIGH side to increase fan
speed and the LOW side to decrease fan speed.
Mode Button
Press this button to manually select the air delivery
mode to the floor, panel or windshield outlets. The
system will stay in the selected mode until the MODE or
AUTO button is pushed.Auto Button
Press the AUTO button to set the system to automatically
control the air delivery mode, fan speed, A/C and
RECIRC operations. Whenever you press AUTO, the
display will change to show the current driver set
temperature, automatic air delivery mode and fan speed.
After five seconds the display will change back to the
EXT (external) temperature outside the vehicle.
Display
In full AUTO mode, the electronic climate control system
display will show the outside temperature, labeled EXT for
external temperature, and AUTO. If you press the
MODE button to select an air delivery mode, the display
will change to also show you the current system mode.
If you press HIGH or LOW on the fan button, the
display will change to show the selected fan speed.
After five seconds, the display will change back to show
the EXT temperature and the selected manual setting.
