2001 GMC YUKON XL DENALI Owners Manual

3-2
Comfort Controls
Electronic Climate Control System
Fan Knob
The knob on the left side of the electronic climate
control panel regulates the fan speed. To manually
increase airflow, move the knob clockwise. To manually
decrease airflow, move it counterclockwise.
OFF: If the knob is in OFF, outside air will still enter
the vehicle, and will be directed based on the position
of the mode knob.
AUTO: If the knob is in AUTO, the fan speed will vary
as the system maintains the selected temperature.When both the fan knob and mode knobs are in the
AUTO position, the system will then automatically
maintain the desired cabin temperature as selected
by the temperature knob. Manual operation is
also available.
Temperature Knob
The middle knob on the control panel lets you select
the desired air temperature in your vehicle. This knob
will allow you to adjust the interior air temperature
independent of the function knob setting. Move the
knob clockwise toward 82 for warmer air. Move the
knob counterclockwise toward 66 for cooler air. When
the system is set for automatic operation, sensors will
control the fan speed.
Full Hot: If you turn the temperature knob past 82
F
(28
C), the system will go into the ªfull hotº mode.
The system will remain at that maximum heating setting
and the fan will blow at the speed the fan knob is set to.
If the fan is in AUTO, it will run at full speed.
Full Cold: If you turn the temperature knob past 66
F
(19
C), the system will go into the ªfull coldº mode.
The system will remain at that maximum cooling setting
and the fan will blow at the speed the fan knob is set to.
If the fan is in AUTO, it will run at full speed.

3-3
Mode Knob - Automatic Operation
The right knob on the control panel allows you to
choose the direction of air delivery. When the system
is set in AUTO mode, sensors will control the air
delivery mode. Air will come primarily from the floor
or instrument panel outlets, with some air directed to
the windshield to prevent fogging.
When the system is in AUTO mode, the air conditioning
light will turn on, and the recirculation and outside air
lights turn off. With the system in full auto control
(both the fan and mode knobs in AUTO), you still
have the ability to override any function. However,
continually overriding the outside air or the A/C
compressor will limit the ability of the system to
cool the vehicle quickly.
If you push a button for a function which is not
available, the light next to that button will flash
three times to alert you that it's not available.
To find your comfort zone, start with the 74
F (23
C)
setting and allow about 20 minutes for the system to
adjust the temperature if necessary.With the automatic setting, the air conditioning
compressor automatically cycles when needed to cool
the air. In cold weather, when the system senses the need
for heat, the airflow will be directed out of the floor
outlets. As the interior temperature approaches a desired
setting, the fan speed will decrease. To maintain interior
comfort, the airflow will adjust between the instrument
panel air outlets and floor outlets. On bright sunny days
in cool weather, the airflow may come out of the air
conditioning and floor outlets (bi
-level mode) to
maintain comfort and prevent stuffiness.
To avoid blowing cold air in cold weather, the system
will delay turning on the fan until warm air is available.
The length of delay depends on the outside air
temperature, engine coolant temperature or the time
since the engine was last started. As the coolant warms
up, the fan speed will gradually increase and air will
flow from the heater outlets, with some airflow to
the windshield to prevent fogging under most
normal conditions.
Be careful not to put anything over the solar sensor
located around the center of the instrument panel.
This sensor is used by the automatic system to
regulate temperature.

3-4
Mode Knob - Manual Operation
The right knob on the control panel allows you to
choose the direction of air delivery.
You can choose to set the climate control system
operations yourself, or let the system work for you
by placing the system in AUTO mode. See ªMode
Knob
- Automatic Operationº earlier in this section.
VENT: This setting directs most of the air through
the instrument panel outlets and a small amount through
the floor outlets.
BI-LEVEL: This setting delivers air through the
floor outlets as well as the instrument panel outlets.
HEATER: This setting directs most of the
warmed air through the floor outlets and some air
through the windshield defroster outlets.
BLEND: This setting divides airflow equally
between the heater floor outlet and the windshield
defroster outlets. The air conditioning compressor may
run to dehumidify the air to prevent window fogging.
DEFROST: This setting directs most air through
the windshield defroster outlets and some through the
outlets. The air conditioning compressor may run to
dehumidify the air to prevent window fogging.
OUTSIDE AIR: This setting should be used
for normal system operation and directs the system
to use outside air. Using outside air will limit stale air
odors and help to prevent excessively humid interior air
(from wet boots or clothing or maximum passenger
loads) from being redirected onto windows.
Pressing the outside air button will cancel the
recirculation button.
RECIRCULATION: This setting limits the
amount of outside air entering the vehicle to a very small
amount. This will be helpful to limit odors entering the
vehicle and will assist in reaching comfort in very hot
temperature conditions. Pressing recirculation will cause
the system to recirculate interior air continuously and
may cause the vehicle windows to fog if the passenger
compartment floor is excessively wet.

3-5
Pressing the recirculation button will cancel outside
air operation. To return to normal system operation and
to prevent stale passenger compartment air, be sure to
return to the outside air position.
Recirculation will not be available in heater, blend or
defrost modes to help reduce window fogging. If the
recirculation button is pressed in theses modes, the
indicator light for recirculation will flash three times
indicating that forced outside air is activated and
recirculation is not available.
If the air conditioning system is activated and system
demand is high in situations such as city traffic, idling,
or very hot weather, the system will automatically
switch from outside air to recirculation. The indicator
light will not change. After demand on the system is
not so great, the system will return back to outside air. A/C: Press this button to turn the air
conditioning on and off. The system will cool and
dehumidify the air inside the vehicle when the A/C light
is on. When in AUTO, the A/C is automatically engaged
when necessary.
Air conditioning will be automatically disabled when
the outside temperature drops below a level at which air
conditioning is ineffective.
Rear Air Conditioning and Heating Systems
Your vehicle is equipped with a rear heating and air
conditioning system that can increase and decrease
airflow and temperature based on passenger needs.
Vehicles equipped with a sunroof will have the manual
control heating and air conditioning system. Vehicles
without a sunroof will be equipped with the Electronic
Climate Control System

3-6 Rear Air Conditioning and Rear Heater
(With Sunroof)
Your vehicle has the rear air conditioning and rear heater
system combination. Controls are provided to regulate
temperature, location and speed of the airflow.
Front ControlTo adjust the airflow speed, turn the fan knob located on
the left side to the desired setting.
To regulate the airflow location, adjust the right knob on
the control panel. Turn the knob clockwise for floor vent
airflow or counterclockwise for headliner vent airflow.
Generally, the upper vents are used for air conditioning
and the floor vents for heating. The knob can be set to
any blend setting.
To adjust the air temperature, turn the temperature knob
on the center of the control panel.
For warmer air, turn the knob clockwise toward red. For
cooler air, turn the knob counterclockwise toward blue.

3-7 Rear Air Conditioning and Heating Systems
with Electronic Climate Control System
Front Control
Rear ControlWith this system the rear passengers can control the
air temperature and airflow. The climate control has
three knobs.
To adjust the airflow speed, turn the fan knob located on
the left side of the control panel to the desired setting.
The system also has a front AUTO setting that can
automatically change the temperature of the rear seating
area based on information from the front control. An
OFF setting, located on the front climate control panel,
also allows the driver to turn off the rear passenger seat
controls from the front seat.
To adjust the air temperature on either control panel,
turn the temperature knob on the center of the control
panel. For warmer air, turn the knob clockwise toward
the red. Turn the knob counterclockwise toward the blue
for cooler air.
To regulate the air flow direction, adjust the right knob
on the control panel. Turn the knob clockwise for floor
vent airflow or counterclockwise for headliner vent
airflow. Generally, the upper vents are used for air
conditioning and the floor vents for heating. The knob
can be set to any blend setting.

3-8 Air Conditioning
On hot days, open the windows long enough to let hot
air inside escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
The A/C button, below the mode knob, allows the
air coming into your vehicle to be cooled. This setting
is useful for normal cooling on hot days. When you
use A/C with the recirculation button pushed in,
turn off recirculation as soon as the vehicle reaches a
comfortable interior temperature.
Using A/C with the recirculation setting active
allows the air inside your vehicle to be recirculated.
This setting helps to maximize your air conditioner's
performance and your vehicle's fuel economy.
This setting also cools air the fastest and can be used
to keep unwanted odors and/or dust from entering the
vehicle. When using the air conditioner, turn off the
recirculation setting and use the outside air setting after
the vehicle reaches a comfortable interior temperature.
When the right knob on the control panel is between
heater and defrost, the recirculation feature will not
function to reduce window fogging.Passenger Compartment Air Filter
Your vehicle is equipped with a passenger compartment
air filter, which filters outside air entering the vehicle.
For information on replacing the filter see ªPassenger
Compartment Air Filterº in the Index.
Heating
The heater works best if you keep your windows closed
while using it. On cold days, use the heater or vent/heat
setting with the temperature knob in the red area.
On cold days, approximately 32
F (
-0
C) or
lower, you may experience differences in how
the transmission shifts until the engine is warm.
This feature automatically reduces the time it takes for
the engine to reach normal operating temperature and
shortens the time it takes the heater to reach full output.
If you use the engine coolant heater before starting
your engine in cold weather, 20
F (
-8
C) or lower,
the heating system will produce warmer air faster to heat
the passenger compartment.
The use of an engine coolant heater also reduces the
time it takes for the engine to reach normal operating
temperature. For more information, see ªEngine Coolant
Heaterº in the Index.

3-9 Defogging and Defrosting
On cool, humid days, use defrost to keep the windshield
and side windows clear. Use defrost to remove fog or ice
from the windshield in extremely humid or cold
conditions. Use defrost with the temperature knob
toward the red area and the fan control turned all the
way to the right.
Rear Window Defogger
The lines running across the rear window are the
window defogger grids. The lines warm the glass.
To turn on the rear window
defogger, press this button
located next to the fan knob.The rear window defogger will only work if the ignition
is in RUN. For best results, clear the window of as much
snow or ice as possible first.
The defogger will shut itself off after several minutes.
If you need additional warming time, press the button
again. You can turn the defogger off at any time by
pressing the button.
The rear window defogger button will also activate the
heated outside mirrors.
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
